- Page 1 BBLAB014A0 English / Espanol ñ / Francais ç www.parrotuncle.com...
-
Page 2: Safety Information
BBLAB014A0 Installation & Operating Instructions for the Parrot Uncle Owner's Installation, Manual WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER Safety Information 1. To reduce the risk of electric shock, the electricity has been WARNING: TO reduce the risk of personal injury, turned off at the circuit breaker or fuse box before begin. -
Page 3: Fan-Motor Assembly
BBLAB014A0 Installation & Operating Instructions for the Parrot Uncle Owner's Installation, Manual WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER Blade screw (16PCS) Plastic wire nut (4PCS) Mounting screws (2PCS) Screws (2PCS) Washer (2PCS) Mounting bracet 4.5" ball/downrod assembly Hanging Pin “R”... - Page 4 BBLAB014A0 Installation & Operating Instructions for the Parrot Uncle Owner's Installation, Manual WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER Securely attach the hanger bracket to the outlet box using the screws and washers provided in the hardware bag.
- Page 5 BBLAB014A0 Installation & Operating Instructions for the Parrot Uncle Owner's Installation, Manual WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER Slide downrod into the coupling on top of the motor. Install the hanging pin by aligning the holes in the coupling with holes in the downrod.
- Page 6 BBLAB014A0 Installation & Operating Instructions for the Parrot Uncle Owner's Installation, Manual WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER Outlet box WHITE (AC IN N) BLACK (AC IN L) BLUE (FOR LIGHT) BLUE (FOR LIGHT) WHITE (TO MOTOR N)
- Page 7 BBLAB014A0 Installation & Operating Instructions for the Parrot Uncle Owner's Installation, Manual WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER Securely attach and tighten the canopy cover over the screws in the mounting bracket utilizing the key slot twist-lock feature.
- Page 8 BBLAB014A0 Installation & Operating Instructions for the Parrot Uncle Owner's Installation, Manual WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER Remove the three screws in the switch housing. Connect the wires from motor to the wires from the light kit by using the 9-pin molex plug. Assemble the light kit to the switch housing and securely tighten all three screws.
-
Page 9: Operating Your Fan
BBLAB014A0 Installation & Operating Instructions for the Parrot Uncle Owner's Installation, Manual WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER OPERATING YOUR FAN Turn on the power and check the operation of the fan. Fan Speed: “ ”Turn on the fan and turn speed up. - Page 10 BBLAB014A0 Installation & Operating Instructions for the Parrot Uncle Owner's Installation, Manual WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER...
- Page 11 BBLAB014A0 Installation & Operating Instructions for the Parrot Uncle Owner's Installation, Manual WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER WIRING SCHEMATIC DIAGRAM FOR RECEIVER WIRING SCHEMATIC DIAGRAM FOR RECEIVER Blue Black wire Black wire Light live-wire Power supply live-wire...
- Page 12 BBLAB014A0 Installation & Operating Instructions for the Parrot Uncle Owner's Installation, Manual WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER SIZE OF PRODUCT 2.1" 2.7" 9.8" 5.0" 14.6" 3.0"...
-
Page 13: Troubleshooting Guide
Measurements should be within 1/8 inch. b) If all deviation are less than 1/8 inch and the fan continues to wobble, please contact Customer Service Support@Parrot Uncle. com to order a complimentary Blade Balancing Kit -If all deviation are less than 1/8 inch and the fan continues to wobble, please contact Customer service Support@Parrot Uncle. -
Page 14: After Installation
BBLAB014A0 Installation & Operating Instructions for the Parrot Uncle Owner's Installation, Manual WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER AFTER INSTALLATION Wobble The fan blades have been adjusted in the factory to minimize any wobble Note: ceiling fans tend to move during operation due to the fact that they are mounted on a rubber grommet. - Page 15 BBLAB014A0 120Vac...
- Page 28 120Vac...
