Digital Watchdog MEGApix Ai DWC-XSDJ08Mi User Manual page 42

Set up - Network Set up
SNMP Settings
1
2
3
4
5
6
7
8
9
10
11
SNMPv1/SNMPv2 - Select the SNMPv1/SNMPv2 option and type the names of Read and Write communities.
1
SNMP trap can be used to check for operational thresholds or failures periodically defined in the MIB.
SNMP Trap - Turn on or turn off the SNMP trap.
2
SNMPv3 contains a higher cryptographic security level, allowing you to set the Authentication and Encryption
passwords.
Mode - Select either Read or Read/Write mode.
3
Activation - Select the mode to turn on or turn off.
4
Read/Write name - Define Read name and Write name.
5
Security Level - Select no auth, no priv/auth, or priv.
6
Authentication Algorithm - Select MD5 or SHA as the authentication method.
7
Authentication Password - The authentication password is an encryption method for authentication and is
8
between 8 and 30 digits long.
Private-Key Algorithm - Select DES or AES as the encryption algorithm.
9
Private-Key Password - An information protection password is private encryption and is between 8 to 30 digits
10
long.
Click 'Apply' to save all settings.
11
