Digital Watchdog MEGApix Ai DWC-XSDJ08Mi User Manual page 25

Set up - Video & Audio Set up
Audio Configuration (Audio Input)
1
2
3
4
5
6
7
8
Audio - Select to turn the audio input on or off from the camera.
1
Source - Select the audio input source. The camera has a built-in microphone as well as an audio input
2
support. The camera's built-in microphone is selected by default.
Codec - Select the audio input codec.
3
Currently, the camera supports codec G.711 ulaw.
Volume - Select the audio input volume from 0 to 10.
4
Sample Rate - Select the audio input sample rate.
5
Currently, the camera supports 8000 Hz.
Audio out > Audio Alarm - Select the audio output from the two available alarm options.
6
Audio out > Volume - Select the audio output volume from 0 to 10.
7
Click 'Apply' to save all changes.
8
25
