Set up - Event Set up
Motion Detection Configuration
1
2
3
4
5
Activation Areas - The camera supports up to four (4) separate motion detection zones. At least one zone
1
must be activated to detect motion in the camera's view. Check the box next to the zone you want to activate.
Click the preview screen and click and drag the edges of the detection zone to adjust the size and position of
the camera's view.
Sensitivity - Define the sensitivity of motion detection. If a high value is selected, it will detect very small
2
motion, while it becomes relatively insensitive when a low value is selected.
Color - Identify the detection zone on the preview according to the color of the zone.
3
Status - Event Alert Icon(
4
Click 'Apply' to save all settings.
5
Click 'Cancel' to return to the previous setting.
) appears if 'Motion Detection' is activated and motion is being detected.
52
