SITE PREPARATION GUIDE
NCR P1532 POS ( 7734)
Release 1.0
BCC5–0000–5061
Issue B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P1532 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for NCR P1532

Summary of Contents for NCR P1532

  • Page 1 SITE PREPARATION GUIDE NCR P1532 POS ( 7734) Release 1.0 BCC5–0000–5061 Issue B...
  • Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
  • Page 3 Audience This book is written for end users, hardware installer/service personnel, system integrators, and field engineers. Notice: This document is NCR proprietary information and is not to be disclosed or reproduced without consent. Safety Requirements The NCR P1532 POS conforms to all applicable legal requirements. To view the...
  • Page 4 Warning: DO NOT connect or disconnect any serial peripherals while the terminal is connected to AC power. This can result in system or printer damage. Grounding Instructions In the event of a malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock.

  • Page 5: Table Of Contents

    Table of Contents NCR P1532 POS Site Preparation Introduction Customer Responsibilities Third Party Peripheral Certification LAN Communications Environmental Requirements Barometric Pressure Temperature Humidity POS Dimensions 7734 Terminal with MSR 7734 Terminal with MSR on Table Top Tilt Stand Countertop Envelope through Tilt Angle (20° to 127°) 7734 Terminal with Integrated Biometrics Countertop Envelope through Tilt Angle (20°...
  • Page 6 Cable Routing Power Protection Revision Record Issue Date Remarks July 2016 First Issue Mar 2017 Added the following updates: • Added 7734 Terminal with Biometrics/2n1 Sign-In Countertop Envelope through Tilt Angle dimensions • Updated Terminal Weight and Shipping Weight...

  • Page 7: Ncr P1532 Pos Site Preparation

    Introduction This chapter provides the information necessary to prepare a site to NCR specifications prior to installing an NCR P1532 POS terminal. Prepare the site properly before installing the terminal. This is a contractual document. It contains important warnings and confers important legal rights and obligations.
  • Page 8 • a customer has been notified that a full or partial consultancy service is available and/or that NCR is willing to undertake a preliminary or final site survey and • the customer shall have entered into a formal contract with NCR for provision of the same.

  • Page 9: Customer Responsibilities

    • Provide and install floor coverings and environment systems that limit or control static electricity build-up and discharge In general, keep the NCR equipment area free from dust, smoke, lint, and other particles. Avoid locating the equipment near other machines that generate ink, carbon,...

  • Page 10: Third Party Peripheral Certification

    Third party peripherals must be certified with the POS terminal or a potential ESD issue can occur. Third party peripherals include any electrically powered devices connected to the POS terminal that is not an NCR branded product or a certified solution advocated by NCR. Examples of third party products include printers, external CD- ROM drives, cash drawers, cigarette boxes, pin pad devices, etc.

  • Page 11: Environmental Requirements

    Site Preparation Environmental Requirements Barometric Pressure The terminal operates within the following barometric pressure conditions: • Maximum operating altitude: 3,000 m (9,843 ft.) • Operating range of pressure: 105 to 69 kPa (15.2 to 10.0 lb./in.) Temperature The terminal operates over the temperature ranges shown below. Avoid continuous operation at, near the indicated temperature extremes, or in locations where the temperature changes beyond the restrictions.

  • Page 12: Pos Dimensions

    Site Preparation POS Dimensions 7734 Terminal with MSR 7734 Terminal with MSR on Table Top Tilt Stand...

  • Page 13: Countertop Envelope Through Tilt Angle (20° To 127°)

    Site Preparation Countertop Envelope through Tilt Angle (20° to 127°) 7734 Terminal with Integrated Biometrics Countertop Envelope through Tilt Angle (20° to 127°)

  • Page 14: 7734 Terminal With 2N1 Sign-In Countertop Envelope Through Tilt Angle (20° To 127°)

    Site Preparation 7734 Terminal with 2n1 Sign–In Countertop Envelope through Tilt  Angle (20° to 127°) Pole Mount Envelope through Tilt Angle (20° to 127°)

  • Page 15: P-Series Mount Envelope Through Tilt Angle (3° To 111°)

    Site Preparation P–Series Mount Envelope through Tilt Angle (3° to 111°) C730 Customer Display on Extension Arm (7734–F461)

  • Page 16: C730 Customer Display With Touch/Msr On Extension Arm (7734-F462)

    Site Preparation C730 Customer Display with Touch/MSR on Extension  Arm (7734–F462) C730 Customer Display with Touch/MSR/Scanner on Extension  Arm (7734– F463)

  • Page 17: Wall Mount Dimensions

    Site Preparation Wall Mount Dimensions Mounting Height The mounting height of the terminal should be appropriate for the majority of users. Based on the recommendation of the ADA (America Disability Association), It is recommended that the system is approximately 1220 mm (48 in.) from the floor to the center of the display when the user is in the standing position.

  • Page 18: Power Supply Dimensions

    Site Preparation Power Supply Dimensions...

  • Page 19: Terminal Weight

    Site Preparation Terminal Weight Component lbs. 15" 7734 Terminal with Table Top Tilt Stand 6.44 15" 7734 Terminal with Integrated Biometrics with Table Top Tilt Stand 7.25 15" 7734 Terminal with 2n1 Sign-In with Table Top Tilt Stand 7.25 Shipping Weight and Dimensions Component lbs.

  • Page 20: Airflow Requirements

    Site Preparation Airflow Requirements Do not block the air vents on the terminal or peripherals. These vents are necessary for cooling. Do not place the terminal in an enclosed area where sufficient ventilation is not available. Leave at least 100 mm (4 inches) of clearance from air vents. When the terminal is wall-mounted, the rear cover must have at lease 6 mm (0.25 in.) clearance from the wall.

  • Page 21: Electrical Requirements

    AC Store Wiring Requirements The customer must provide suitable AC power for the terminals, associated equipment, and devices. We recommend a dedicated unswitched power line dedicated to the NCR equipment installation. Refer to the NCR Workstation and Peripherals AC Wiring Guide (BSTO-2115-53) for store AC wiring requirements.
  • Page 22 Site Preparation Cable Routing Peripheral cable connectors are located on the front panel at the bottom of the terminal head. The cables are routed out the opening and down through the Table Top Tilt Stand. For more information, refer to the Cable Routing section in the Installing the Terminal chapter.
  • Page 23 NCR offers Power Conditioners and UPS Systems that will protect electronic equipment and reduce downtime and extend the life of the Hospitality POS Solution. These power stability systems combine a surge diverter and noise filter with a highly efficient low–...
