Multiplayer Terminal STORK
User Manual
USER MANUAL
GAMING MACHINE
Rev.1.2
16.11.2016
The manufacturer retains its right to make changes on the product and
the documentation without prior notice.
2016, Euro Games Technology Ltd.
1
www.egt-bg.com
©2016, Euro Games Technology Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STORK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EGT STORK

Summary of Contents for EGT STORK

  • Page 1 Multiplayer Terminal STORK User Manual USER MANUAL GAMING MACHINE Rev.1.2 16.11.2016 The manufacturer retains its right to make changes on the product and the documentation without prior notice. 2016, Euro Games Technology Ltd. www.egt-bg.com ©2016, Euro Games Technology Ltd.
  • Page 2 Multiplayer Terminal STORK User Manual Revision History: Rev.1.0. First version of the document. Rev.1.1. Added information about mCore game platform. Rev.1.2. Update document. 2016, Euro Games Technology Ltd.
  • Page 3 This instruction manual provides you with all the necessary information for proper and safe use of the hardware and software product.  This instruction manual relates to the Multiplayer terminal Stork with an m-Core (Exciter) control platform.  The table of contents at the beginning of the manual and in every section shows where the information is located.

  • Page 4: Table Of Contents

    Hardware Configuration with G e n e r a l d e s c r i p t i o n automatic electronic components Stork ® ....Roulette......3.2 mCore ……………...…………..20 Configuration with Live 3.3 Keyboard controller ……....27 Wheel Connection Kit……...

  • Page 5: Introduction

    Multiplayer Terminal STORK User Manual 1. INTRODUCTION 1.1. General Description………………………………………………..………… 1.2. Technical Data and Dimensions……………………………...…………….. 1.3. General Conditions for Use……………………………………...………….. 1.4. Transport…………………………………………………………..………….. 2016, Euro Games Technology Ltd.

  • Page 6: General Description

    Keno (bingo) and roulette, and to be connected to a jackpot system. The multiplayer STORK terminal could also be part of a server based system (SBG) that widens its gaming abilities to a new extend and makes possible the play on an installed bingo machine.

  • Page 7: Technical Data And Dimensions

    2 х 6.3 А Fuse: Consumption: 125 W Place of Identification Details: Situated identification plate is on the right side of the gaming place . (fig.І.2.). Fig.1.2. Identification sign and situation in the multiplayer terminal STORK. 2016, Euro Games Technology Ltd.
  • Page 8 Multiplayer Terminal STORK User Manual 1.2.2. Dimension. Weight: 80 kg Height: 1105 mm / 1108 mm Width: 716mm Depth: 674 mm 2016, Euro Games Technology Ltd.

  • Page 9: General Conditions For Use

    Multiplayer Terminal STORK User Manual 1.3. GENERAL CONDITIONS FOR USE Multiplayer terminal STORK is designed and constructed in a way that keeps its efficiency in the following conditions: Temperature of the environment of 0С° to +30С°; Humidity of 0% to 85%;...
  • Page 10 Multiplayer Terminal STORK User Manual 2016, Euro Games Technology Ltd.

  • Page 11: Instalation And Exploatation

    Multiplayer Terminal STORK User Manual 2. INSTALLATION AND EXPLOATATION 2.1. Visual Inspection…………………………………..……………………..…….. 2.2. Installation………………………………………….……………………..…….. 2.3. Safety and Precaution ………….…………………..………………...……….. 14 2016, Euro Games Technology Ltd.
  • Page 12 Multiplayer Terminal STORK User Manual 2.1. VISUAL INSPECTION Prior to installation the multiplayer terminal is checked for damages cased by transportation. Note! The manufacturer is not responsible for damage caused during transport; damage incurred during loading raztovarna activity; breaking the nature of the cargo for fragile loads, as well as due to incorrect strengthening.
  • Page 13 User Manual II.3. SAFETY AND PRECAUTION Multiplayer terminal STORK is realized as a device, having a class I protection against electrical damages according to the requirements, defined in EN 60335-1. The multiplayer terminal can only be plugged in a bipolar contact with protection grounding of the electrical installation.
  • Page 14 Multiplayer Terminal STORK User Manual 2016, Euro Games Technology Ltd.

  • Page 15: Hardware

    Multiplayer Terminal STORK User Manual 3. HARDWARE General description of components Stork ® ..........16 3.2 mCore ……………...…………..............20 3.3 Keyboard controller ……................27 3.4 Controller for electronic keys ..............27 3.5 Mechanical counters.................. 40 3.6 Power suppy unit …................... 42 3.7 Loudspeakers.....................

  • Page 16: G E N E R A L D E S C R I P T I O N O F

    ® STORK Fig. III.1.1 Multiplayer terminal STORK - overview at closed doors 17*, 18* - The type and shape of the keyboard and front panel depend on the type of software, and for which they are intended. Indications species can not meet you purchased.
  • Page 17 Multiplayer Terminal STORK User Manual Fig. III.1.2 Multiplayer terminal STORK ® - overview at opened doors DESCRIPTION OF COMPONENTS Top Lighting Module 15. Metal tubular column Decorative lighting top 16. Armrest I Button Reader- Socket 17. Keyboard Panel Information Monitor 18.
  • Page 18 Multiplayer Terminal STORK User Manual Multiplayer terminal STORK® is divided into 5 main parts: (fig. III.1.3). 1 – Corpus; 2 – Door Bill Validator; 3 – Step; 4 – Metal tubular column 5 – Corpus Monitor. Fig. III.1.3. Multiplayer terminal STORK - main parts...
  • Page 19 Multiplayer Terminal STORK User Manual III.1.1. Corpus: The corps is the main part of the terminal , where all electronic components are located. The access to this part is limited by means of a mechanical locking systems and it can be controlled even if the multiplayer terminal power is switched off.
  • Page 20 Multiplayer Terminal STORK User Manual 3.2. Game Platform Type: mCORE Intended use: mCORE is a specialized platform, designed for the construction of modern video games and game systems. PX 300 has one main connector, through which it connects with mCORE Backplane.
  • Page 21 Multiplayer Terminal STORK User Manual Resetting of the memory of the gaming platform: The resetting of the memory (NVRAM) of the gaming platform is carried out with NVRAM Clear Cfast Card. To carry out resetting of the memory (NVRAM) of...
  • Page 22 User Manual The settings should be accordance with the documents submitted and approved by the client and EGT. To make sure that the facility is set and no omissions, you can make a check in the menu Settings / Not Set Parameters whether other menus that are not configured.
  • Page 23 Multiplayer Terminal STORK User Manual Type: Exciter I Specialized game platform designed and developed by Euro Games Technology Ltd. Gaming platform is responsible for all processes in the machine by calculating profits, adjust the speed of rotation of the wheel and launch the ball at random,...
  • Page 24 Multiplayer Terminal STORK User Manual Resetting of the game platform of the gaming place: The resetting of the memory (NVRAM) of the gaming platform is carried out with the aid of 4 Dip micro Switches. To carry out resetting of the memory (NVRAM) of the gaming platform, it is necessary to perform the following operations: a) Turn off the power of the gaming machine;...
  • Page 25 Multiplayer Terminal STORK User Manual Fig.3.2.1. Choosing № of the gaming place Fig.3.2.2. Waiting of the platform resetting process 2016, Euro Games Technology Ltd.
  • Page 26 Multiplayer Terminal STORK User Manual Fig.3.2.3. Set the time and date Fig.3.2.4. Gaming platform is reset 2016, Euro Games Technology Ltd.
  • Page 27 Multiplayer Terminal STORK User Manual Position of game platform in STORK 2016, Euro Games Technology Ltd.

  • Page 28: Keyboard Controller

    To open the back door of the Multiplayer terminal STORK; / the cable form to the back door is disconnected/; To activate an editing mode; To carry out the required procedure for creation/deletion of an electronic key, according to the described below rules depending on the version of board i-Button Reader .
  • Page 29 Multiplayer Terminal STORK User Manual 3.4.2. ENTERING INTO EDITING MODE 1.Button <Edit> (pos.7) is held pressed for 3 seconds. 2.The LED Erase (pos.5) begins to flash time and the LED of channel 1 (pos.1) lights continuously, to indicate, that channel 1 is selected.
  • Page 30 Multiplayer Terminal STORK User Manual 3.4.5. DELETING A KEY The desired channel is selected and the button <Erase> is pressed (pos.6) at which the LED Erase goes out. When the deletion is completed, the LED Erase goes out and the controller returns into editing mode as visualizes the last channel, with which is operated.
  • Page 31 Multiplayer Terminal STORK User Manual 3.4.6 ELECTRONIC SWITCHES AND SERVICE FUNCTIONS Access to accounting, service functions and the method of placing or loan payment each player positions is done through electronic keys. To perform any of the operations described above need the owner or dealer to put your identification key recognition system.
  • Page 32 Multiplayer Terminal STORK User Manual 3.4.6.1. ATTENDANT KEY: 3.4.6.1.1 Adding credit using the electronic key: The introduction of credit of gaming space is via key "Attendant". Using the screen left, keyboard will open through which introduces a monetary amount by which the player will participate in the game After being introduced monetary value of the dealer button activates ADD.If the last...
  • Page 33 Multiplayer Terminal STORK User Manual 3.4.6.1.3. Reserved gaming place: Reservation (Locked) or Unlocked gaming place is via key "Attendat”. Activation of the function is implemented through button Unlocked and Locked. By activating the button Locked, gaming place acquired status of reserved seat.
  • Page 34 Multiplayer Terminal STORK User Manual 3.4.6.2. CASHIER KEY : When inserting the electronic key "Cashier" or "Admin" in a reader and its successful recognition will be displayed on the left screen. The keys provide access to the following sections: Accounting;...
  • Page 35 Multiplayer Terminal STORK User Manual 3.4.6.2.2. menu Diagnostic - provides access to diagnostic facility. 3.4.6.2.3. History - provides access to the history of the games held at the specific gaming place. 3.4.6.2.4 menu Logs - provides access to records and events occurring on the gamiing place 2016, Euro Games Technology Ltd.
  • Page 36 Multiplayer Terminal STORK User Manual 3.4.6.2.5 menu Servers provides access to information about roulette wheel (centers) and settings counters. 3.4.6.2.6 menu Service - provides information on the duration of the license codes. 2016, Euro Games Technology Ltd.
  • Page 37 Multiplayer Terminal STORK User Manual 3.4.6.3. OWNER KEY: The menu Owner provides access to all local settings of the system that relate to the gaming place, the roulette wheels and the server. The overall menu navigation and identification settings is achieved by touching and releasing a finger on the touch screen of the gamiing place.
  • Page 38 Multiplayer Terminal STORK User Manual 3.4.6.3.2. menu Diagnostic - provides access to diagnostic facility. The diagnostics constitutes a process of testing different components of the system. A check of one or more program modules, their control data, work procedures, as well as operation procedures for communication among them is accomplished through it in order to find out whether they function properly.
  • Page 39 Multiplayer Terminal STORK User Manual 3.4.6.3.4 menu Logs - provide access to records and events occurring on the playing area. The functionality of this group is to displays specific events from the system in chronological order. A click on the "Log" field activates a drop-down menu with 12 sections that provide the user with different information about the events in system.
  • Page 40 Multiplayer Terminal STORK User Manual 3.4.6.3.7 menu Servers - provides access to information about roulette wheel (centers) and settings counters. 3.4.6.3.8 Service меню - provides information on the duration of the license codes. The menu allows the activation check and / or reactivation of the operating time of the facility.

  • Page 41: Mechanical Counters

    Multiplayer Terminal STORK User Manual 3.5. MECHANICAL COUNTERS Description: The gaming machine has 6 electromechanical counters Their condition is monitored and an error message is displayed at interruption or short circuit in the corresponding counter. In this case the counter circuit must be checked.

  • Page 42: Power Suppy Unit

    Multiplayer Terminal STORK User Manual Characteristics of the mechanical counters module: Specially designed by Euro Games Technology Ltd. specialists; Supports 6 mechanical counters; Conducts protocol communication whit ccTalk ®. 3.6. POWER SUPPLY UNITS They ensure the necessary power voltage for the all machine components.

  • Page 43: Loudspeakers

    High quality reproduction, minimal distortions; Wide Xmax without diffuse magnetic filed. 3.8. LED`S LIGHTS Multiplayer terminal STORK with basic lights in RGB variants. Controlled by special board: Flexible LED RGB Strip: Top and bottom of the main screen , and back of the terminal (fig.

  • Page 44: I-Button Pills

    Multiplayer Terminal STORK User Manual Fig. 3.8.1. Fig. 3.8.2. Light back Light top and bottom of the main screen Light bottom the keyboard and Logo 3.9. I-BUTTON PILLS I-Button Pills - They consist of a plastic holder and electronic chip indicator with a unique ID number in a steel housing, water-and dust resistant.

  • Page 45: Information Monitor 6.2

    Multiplayer Terminal STORK User Manual 3.10. INFORMATION MONITOR Monitor display system presentation. Serves to show ads about raffles and events in the games room (chain casinos) at the request of the manager / owner of the hall. (fig.3.1.1., position.4. ) Producer: ALPHA DISPLAY;...

  • Page 46: Distribution Box

    Two fuses 6.3 А each. Fig. 3.12.1. 3.13. SENSOR MONITOR Visualize multiplayer terminal STORK program and give the opportunity to the users to make their own bets, to learn the rules, to see the statistics, etc. Producer: ALPHA DISPLAY Model: APD-A2202 Fig.
  • Page 47 Multiplayer Terminal STORK User Manual 3.14. BILL VALIDATOR Gives the user the opportunity to buy credits without the help of the staff by placing a bill or bills in the corresponding device of their game place. Producer: CASHCODE Company 3.14.a / JCM Global 3.14.b / Ardac Elite 3.14.c / MEI SC Series 3.14.d.
  • Page 48 Multiplayer Terminal STORK User Manual Fig. 3.14.c. Bill Validator Ardac Elite MEI SC Series Electrical Parameters Value Supply Voltage 12 ÷ 28V DC ± 5% 0.45 А Standby Current Consumption 1.25÷3.0 А Operation Mode Communication Interface Communication Interface RS232 Environment Parameters...
  • Page 49 Multiplayer Terminal STORK User Manual Components: Configuration switches Entrance bills Validating head Cassette Chassis Fig.3.14.1 Fig.3.14.2 Components CashCode MFL Components JCM UBA-10-SS Fig.3.14.3 Components Ardac Elite 2016, Euro Games Technology Ltd.
  • Page 50 Multiplayer Terminal STORK User Manual Validating head Validating head U p d a t i n g t h e software of MEI SC Entrance bills Series is done by Chassis using mobile d e v i c e c a l l e d...
  • Page 51 Multiplayer Terminal STORK User Manual Remove the bills from JCM UBA –10-SS Fig.3.14.6 Taking bills from JCM UBA -10-SS 1. Open door Bill validator; 2. Hold the of the cassette handle and pull it in the direction shown by the arrow in Fig.3.14.6.
  • Page 52 Multiplayer Terminal STORK User Manual Removing a jammed bills on JCM UBA –10-SS: Fig.3.14.8.Removing Jammed bills from JCM UBA –10-SS. Depending on the specific situation stranded banknotes were removed in the manner shown in Fig.3.14.8. Configuration Bill Validators: CashCode MFL The configuration of CashCode MFL is done by configuration switches, which are located in the back of the head validated under a clear plastic cover.
  • Page 53 Multiplayer Terminal STORK User Manual CashCode work regimes: normal service. Determining the settings modes and authorized denominations of acceptance is performed by two groups of switches - KL1 and KL2 (Fig.3.14.10, Fig.3.14.11 and Fig.3.14.12). ON Conditions КЛ1.1 Denomination 1 authorized Denomination 1 prohibited КЛ1.2...
  • Page 54 Multiplayer Terminal STORK User Manual Acceptance of bar-code Acceptance of bar-code vouchers is prohibited vouchers is authorized Denomination 1 prohibited Denomination 1 authorized * By default, all switches Denomination 1 prohibited Denomination 2 authorized a re of f . Add it ion a l...

  • Page 55: Ticket Printer

    Multiplayer Terminal STORK User Manual 3.15. TICKET PRINTER According to the game place settings and the individual wish of the client, the ticket printer prints a ticket with information about the credit. Option А: Producer: FutureLogic Inc; Model: GEN2 Universal.
  • Page 56 Multiplayer Terminal STORK User Manual Parameters Ithaca Epic 950 printer: Electrical parameters Values 24V DC ± 10% Supply voltage max 2.2 А Current consumption At 24V and 25% black RS232 Communication interface Values Environmental parameters 5°C ÷ 45°C Working temperature -10°C ÷...
  • Page 57 Multiplayer Terminal STORK User Manual Setting the switches on FutureLogic GEN2 printer: Fig.3.15.2 The printer has 6 DIP switches accessible through a slot in the top of the stationary module. They are used for selection of the communication protocol. Switches must be set according fig.3.15.2 and the table given below:...

  • Page 58: Top Lights And Functionality

    Multiplayer Terminal STORK User Manual 3.16. TOP Lights and functionality Top Lighting opportunity than as a decorative element to act as signal lighting. TOP Lights Fig.3.16.1. Top lighting is controlled by signal lights controller. The controller is designed by the Euro Games Technology Ltd. and holds the following designations and specifications: Manage the lighting of beacons depending received commands;...
  • Page 59 Multiplayer Terminal STORK User Manual Top lights functionality: Color of Lamp Function Reason: Lamp flashes: Appears splash upon payment of a sum of money on hand(“Handpay”). № 1 The lamp extinguishes: When clearing splash. Flashing regime: Flashing with a period of 1 second (500ms lights / 500ms off).
  • Page 60 Multiplayer Terminal STORK User Manual 2016, Euro Games Technology Ltd.
  • Page 61 Multiplayer Terminal STORK User Manual 4. ATTACHMENTS Block Diagrams ................... 62 2016, Euro Games Technology Ltd.

  • Page 62: Block Diagrams

    Multiplayer Terminal STORK User Manual 4.1. BLOCK DIAGRAMS 4.1.1. Block diagrams - Multiplayer terminal Stork 2016, Euro Games Technology Ltd.
  • Page 63 Multiplayer Terminal STORK User Manual 2016, Euro Games Technology Ltd.

  • Page 64: Problems In Use

    Multiplayer Terminal STORK User Manual 5. PROBLEMS IN USE 5.1. Possible problems and their resolution……………………….………….…. 2016, Euro Games Technology Ltd.
  • Page 65 Multiplayer Terminal STORK User Manual 5.1. POSSIBLE PROBLEMS IN USE External causes Possible causes Removal No power cord is plugged. Turn power cable. Defective power cable. Replace the power cable. Burn Fuse. Change Fuse. Nothing is off Main power supply.
  • Page 66 Multiplayer Terminal STORK User Manual 2016, Euro Games Technology Ltd.

  • Page 67: Multiplayer Terminal Stork Configuration

    Multiplayer Terminal STORK User Manual 6. MULTIPLAYER TERMINAL STORK CONFIGURATION Introduction....................68 Configuration with roulette center ............. 69 Configuration with automatic electronic Roulette........72 Configuration with Live Wheel Connection Kit……………...……………... 73 2016, Euro Games Technology Ltd.

  • Page 68: Introduction

    Multiplayer terminal STORK is fully automated, computer-controlled touch screen terminal, which is characterized by a stylish and ergonomic design. The multiplayer terminal can be integrated with the electronic roulette wheels of EGT, TCS, Cammegh, Abbiati and as well as any other live roulette wheel with Live Wheel Connection Kit system .
  • Page 69 Multiplayer Terminal STORK User Manual 6.2. CONNECTION TO ALONE AUTOMATIC ROULETTE CENTER 2016, Euro Games Technology Ltd.
  • Page 70 Multiplayer Terminal STORK User Manual 2016, Euro Games Technology Ltd.
  • Page 71 Multiplayer Terminal STORK User Manual 2016, Euro Games Technology Ltd.
  • Page 72 Multiplayer Terminal STORK User Manual 6.3.CONNECTION TO AUTOMATIC ELECTRONIC ROULETTE 2016, Euro Games Technology Ltd.
  • Page 73 Multiplayer Terminal STORK User Manual 6.4. CONNECTION TO LIVE WHEEL CONNECTION KIT 2016, Euro Games Technology Ltd.
  • Page 74 Multiplayer Terminal STORK User Manual 2016, Euro Games Technology Ltd.
  • Page 75 Multiplayer Terminal STORK User Manual 2016, Euro Games Technology Ltd.

  • Page 76: Contacts

    Multiplayer Terminal STORK User Manual 7. CONTACTS Technical support …………………………………………………………..77 Offices and representatives …………………………………………………... 80 2016, Euro Games Technology Ltd.
  • Page 77 Multiplayer Terminal STORK User Manual 7.1. TECHICAL SUPPORT 2016, Euro Games Technology Ltd.
  • Page 78 Multiplayer Terminal STORK User Manual 2016, Euro Games Technology Ltd.
  • Page 79 Multiplayer Terminal STORK User Manual 2016, Euro Games Technology Ltd.
  • Page 80 Multiplayer Terminal STORK User Manual 7.2. OFFICES AND REPRESENTATIVAS For more information about your area visit the WEB address: www.egt-bg.com If you have any problems while using the software product or the devices, integrated into the equipment, please contact Euro Games Technology.
