S-Line S32/55
User Manual
type:EGT-PS3-5
USER MANUAL
S32/55
Rev.1.1
18.07.2019
The manufacturer retains its right to make changes
on the product and the documentation without prior notice.
www.egt-multiplayer.com
www.egt-multiplayer.com
©2019, EGT Multiplayer Ltd.
©2019, EGT Multiplayer Ltd.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the S-Line S32/55 and is the answer not in the manual?

Questions and answers

Related Manuals for EGT S-Line S32/55

Summary of Contents for EGT S-Line S32/55

  • Page 1 S-Line S32/55 User Manual USER MANUAL S32/55 type:EGT-PS3-5 Rev.1.1 18.07.2019 The manufacturer retains its right to make changes on the product and the documentation without prior notice. www.egt-multiplayer.com www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd. ©2019, EGT Multiplayer Ltd.
  • Page 2 S-Line S32/55 User Manual Revision History: Rev.1.0. Initial version of document. Rev.1.1. Added dimensions in cm; technical data update; USA contact information update www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.
  • Page 3 Symbols used: ATTENTION! This symbol warns about specific situation and/or conditions that should be approached with special attention. NOTE! This symbol indicates important and/or additional information regarding the presented hardware and/or software product. www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.

  • Page 4: Table Of Contents

    5. Multiplayer terminal configuration 5.1. Introduction ......................... 43 5.2. Connection to automatic Roulette Center ................43 5.3. Connection to Live Roulette Center ..................43 6. Contacts 6.1. Technical support ....................... 44 6.2. Offices and representatives ....................48 www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.

  • Page 5: Introduction

    It can be arranged in various configurations, depending on the specifics of the gaming floor and the requirements of the operator. General Features of S-Line S32/55: Elegant and pure design; ...

  • Page 6: Technical Data

    S-Line S32/55 User Manual 1.2. TECHNICAL DATA 1.2.1. Technical Data: Producer: EGT Multiplayer Ltd, Bulgaria Type: EGT-PS3-5 Voltage: 100 V - 240 V Current: 3.2 / 1.6 A Frequency: 50 - 60 Hz Fuse: 1 х 6.3 А Consumption: 300 W Location of Identification Details: All technical data is specified and indicated on an Identification Badge, affixed on each gaming device.
  • Page 7 The S-Line Multiplayer terminal has the following dimensions (Fig.1.2.2.): Fig.1.2.2 Dimensions of S-Line Multiplayer Terminal S32/55 Height: 806 mm / 2441mm (80.6 cm / 244.1 cm) Width: 791 mm (79.1 cm) Depth: 883 mm (88.3 cm) www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.

  • Page 8: General Conditions Of Use

    The terminal must be placed in vertical position upon transportation. It must stay in stable position, secured against moving and mechanical impact upon transportation. EGT Multiplayer is not responsible for damages caused during transportation. ATTENTION! When the terminal has been transported or displaced from a cold to a warm room, it has to acclimatize for at least two hours prior to power supply, in order to avoid condensation.

  • Page 9: Installation And Exploitation

    100 V - 240 V; 50 - 60 Hz  The electrical connections from and to the multiplayer terminal should only be performed by EGT Multiplayer Ltd. specialists, their authorized representatives, or specialists, who have undertaken proper training;...

  • Page 10: Safety Precautions

    Children should not to be allowed to play on the multiplayer terminal;  www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.

  • Page 11: Hardware

    Bill Validator Exit Loudspeakers Keyboard Panel Main Door Key lock 10 Main Door 11 EGT MP illumination logo 12 Foot rest stand 13 Control Monitoring System Panel 14 Ticket Printer Exit 15 Collect Ticket Sticker 16 I Button Reader - Socket...
  • Page 12 S-Line S32/55 User Manual DESCRIPTION OF COMPONENTS (Fig.3.1.2) Cooling Fan LED illumination EGT MP illumination logo Monitor stand Fig.3.1.2. S-Line Multiplayer Terminal S32/55 - back overview DESCRIPTION OF COMPONENTS (Fig.3.1.3) Keyboard Controller 80 mm Cooling Fan Bill Validator Electromechanical Counters...
  • Page 13 29 Power Distribution Box 30 Electromechanical Counters 31 Power Supply Units 32 Bass Box 33 RGB Static Controller 34 mCORE Game Platform 31 (behind metal plank) Fig.3.1.4. S-Line Multiplayer Terminal S32/55 - overview with all doors open www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.

  • Page 14: Mcore Game Platform

    – Player terminals, Game (Roulette) centers, Jackpot Servers, etc. EGT Multiplayer uses Linux OS in all of its equipment. mCore is assembled by EGT Multiplayer and has four main components (fig. 3.2.1.): Mini-ITX motherboard;...
  • Page 15 Turn off the power; h) Remove the NVRAM Clear Cfast Card.; i) Close the door of the Gaming Platform, turn on the power and complete the settings of the gaming platform. Pos. 1 Fig.3.2.3. Master Slot Location www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.
  • Page 16 Parameters and check if there are other not configured menus.(Fig.3.2.5) Fig.3.2.5. Settings/Not Set Parameters screen NOTE! The current document does not include software features. Detailed information, can be found in the respective Software User Manual. www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.

  • Page 17: Keyboard Controller

    User Manual 3.3. KEYBOARD CONTROLLER The keyboard controller (Fig.3.3.1) controls the mechanical buttons used by the players. Characteristics: Designed by EGT Multiplayer Ltd. specialists;  Supports up to 18 mechanical buttons with a  backlight; Performs the protocol communication with ccTalk ®.
  • Page 18 Flashing mode of the LED Erase at adding of a new key (Table 3.4.4.1): Number of flashes Number of cycles Cause There are no free places in the list This key exists in the list The number of the key is not read correctly Table 3.4.4.1. www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.
  • Page 19 ( Fig.3.4.5.) Fig.3.4.5. Keyboard controller Controller characteristics : Designed by EGT Multiplayer Ltd. specialists;  Hierarchical structure in four access levels;  Supports up to 16 electronic keys which duplicate the indication of the electronic counters.
  • Page 20 ADMIN - it is active only in Blackjack game. It shows the history of the game. It provides  information about the game number, Local, History, placed bets and played hands. www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.
  • Page 21 A splash with the credit value appears. The credit must be paid in the relevant currency (Fig 3.4.6.1.2). The "Attendant" key allows the credit of the gaming device to be paid. Fig 3.4.6.1.2 Cash Out/handpay www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.
  • Page 22 Fig. 3.4.6.1.3.1 Reservation screens A splash appears on the user interface with an information message "Reserved" (Fig. 3.4.6.1.3.2 ). Fig. 3.4.6.1.3.2 “Reserved” Splash The cancellation of a reservation is identical to the procedure for making one. www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.
  • Page 23 Detailed description of each of the menus can be found in the Software User Manual which accompanies the respective gaming device. 3.4.6.2.1. Accounting menu – provides access to accounting information of the gaming device Fig. 3.4.6.2.1). Fig. 3.4.6.2.1 Accounting menu www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.
  • Page 24 3.4.6.2.3. History menu - provides access to history of the games, played at the particular gaming device. (Fig. 3.4.6.2.3). Fig. 3.4.6.2.3. History menu 3.4.6.2.4 Logs menu - provides access to records and events of the particular gaming device (Fig. 3.4.6.2.4). Fig. 3.4.6.2.4 Logs menu www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.
  • Page 25 3.4.6.2.5 Servers menu - provides access to information about roulette wheels (centers), games and counters settings (Fig. 3.4.6.2.5). Fig. 3.4.6.2.5 Servers menu 3.4.6.2.6 Service menu - provides information about the duration of the license codes (Fig. 3.4.6.2.6). Fig. 3.4.6.2.6 Service menu www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.
  • Page 26 Detailed description of each of the menus can be found in the Software User Manual which accompanies the respective gaming device. 3.4.6.3.1. Accounting menu – provides access to accounting information of the gaming device (Fig. 3.4.6.3.1.). Fig. 3.4.6.3.1. Accounting menu www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.
  • Page 27 3.4.6.3.3. History menu - provides access to history of the games, played at the particular gaming device. The history log contains 100 entries as a minimum. Each one includes data about the main games, their bonuses, scatter games, gamble and jackpots (Fig. 3.4.6.3.3). Fig. 3.4.6.3.3. History menu www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.
  • Page 28 (Fig. 3.4.6.3.5). Fig. 3.4.6.3.5 Settings menu 3.4.6.3.6 Games menu - allows access to settings and configuration of the games included in the software version (Fig. 3.4.6.3.6). Fig. 3.4.6.3.6 Games menu www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.
  • Page 29 All screens considered in Electronic keys and Service functions sections refer to m-Core control platform with the respective software product. NOTE! Detailed description of each menu accessible by an electronic key can be found in the instructions of the particular software. www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.

  • Page 30: Mechanical Counters

    Maintains communication with the Game platform; Tests the counters to detect if interruption or short circuit exist. Characteristics of the mechanical counters module: Specially designed by EGT Multiplayer Ltd.  specialists (Fig. 3.5.2); Fig. 3.5.2. Mechanical counters module Supports 6 mechanical counters;...

  • Page 31: Power Supply Unit

     5 V Power Supply Unit Producer: MEAN WELL ENTERPIRSES CO., LTD; Model: UHP 200-5V/40A Voltage output: 5V Protection against short circuit or overvoltage. Fig. 3.6.2. PSU - Power Supply Unit Mean Well UHP 350-24 www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.

  • Page 32: Loudspeakers

    - Red - Yellow Fig. 3.8.1 Dip Switches combinations ATTENTION! The color of the LED lights may vary. EGT Multiplayer Ltd. consultants could recommend colors of the lights so they are suitable to the interior of the given room. www.egt-multiplayer.com...

  • Page 33: I-Button Pills

    Fig. 3.9.1. I-Button Pills 3.10. DISTRIBUTION BOX Distribution box - distributes the power supply voltage of 220 V between the components of the gaming device (Fig. 3.10.1.). Model: EGT Distribution box 4-port; 4 - Ports;  1 fuse - 6.3 А;...
  • Page 34 Line Multiplayer terminal these settings are locked and the second information monitor displays information set by default. NOTE! The current document does not include software features. Detailed information, can be found in the respective Software User Manual. www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.

  • Page 35: Bill Validator

    Validating head Portable Programming Module - Bill Entrance a mobile device used to update Chassis the software of MEI SC Series. Cassette Fig. 3.12.2. Components of the MEI SC Series www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.
  • Page 36 S-Line S32/55 User Manual Producer: iVIZION Model: JCM iVIZION-100-SS Fig. 3.12.3. Bill Validator JCM iVIZION-100-SS www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.
  • Page 37 S-Line S32/55 User Manual Producer: MEI Model: MP.MEI SC Advance 900 note Fig. 3.12.4. Bill Validator MEI SC Advance 900 note www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.

  • Page 38: Ticket Printer

    Capacity of the cassette 300 tickets Parameters of the ticket Values Ticket Width 66 mm Ticket Length (distance between perforation) 156 ± 1mm Ticket Thickness 4,5 mil, 1 color / 2 colors Table 3.13.2. GEN5 Thermal Printer Parameters www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.
  • Page 39 The switches must be set according to Fig.3.13.3 and the table given below (Table 3.13.4): Switch SW1 SW2 SW3 SW4 SW5 SW6 Position OFF OFF OFF Table 3.13.4. GEN5 Thermal Printer - Switches configuration www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.
  • Page 40 Parameters of the voucher Values 65 ± 1mm Width of the voucher 156 ± 1mm Length of the voucher (distance between perforation) 0.114 ÷ 0.127mm A thickness of the voucher Table 3.13.6. Epic 950 Thermal Printer Parameters www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.

  • Page 41: Top Lights

    Top Lights serve as a decorative element as well as a light signal of the device. The top lights are managed by a controller, which is designed by the EGT Multiplayer Ltd. and it has the following designations and specifications: Manages the light signals according to the received commands;...

  • Page 42: Troubleshooting

    CHAPTER 4. TROUBLESHOOTING 4.1. TROUBLESHOOTING In table 4.1 different problems that may take place are presented. For each problem there is a proposed solution. If a problem persists, get in touch with EGT Multiplayer Ltd. Problem Possible causes Solution The power cable is unplugged.

  • Page 43: Multiplayer Terminal Configuration

    The S-Line Multiplayer terminal S32/55 is а fully automated, computer-controlled touchscreen terminal, which is characterized by a stylish and ergonomic design. The multiplayer terminal can be configured with EGT electronic roulette wheels and centers, TCS, Cammegh, Abbiati and any other live roulette wheels via Live Wheel Connection Kit system.

  • Page 44: Contacts

    S-Line S32/55 User Manual CHAPTER 6. CONTACTS 6.1. TECHNICAL SUPPORT www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.
  • Page 45 S-Line S32/55 User Manual www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.
  • Page 46 S-Line S32/55 User Manual www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.
  • Page 47 S-Line S32/55 User Manual www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.

  • Page 48: Offices And Representatives

    S-Line S32/55 User Manual 6.2. OFFICES AND REPRESENTATIVES For more information about your area visit www.egt-multiplayer.com the WEB address: www.egt-multiplayer.com ©2019, EGT Multiplayer Ltd.

This manual is also suitable for:

Egt-ps3-5
