- Page 1 LED Panel Circle Products Installation SERVICE MANUAL LED Panel Circle Large LED Panel Circle Small Products Installation (rev. 1.0) ©2024, Euro Games Technology Ltd. www.egt.com Page 1 www.egt.com...
-
Page 2: Table Of Contents
Wiring and Grounding the Metal Structure of the Base of the Product LED Module 4x13 Circle 20 Test of Functionality ........................20 The Gaming Machines Positioning ....................20 Overall dimensions of a group of gaming machines and Products LED Panel Circle ....22 Contacts ............................... 23 Page 2 www.egt.com... -
Page 3: Revision History
LED Panel Circle Products Installation Revision History Version Date Changes rev.1.0 October 2024 An initial document version. The manufacturer shall reserve its right to make changes and amendments to the item and documentation without prior notification of the customer. Page 3 www.egt.com... -
Page 4: Introduction
M6x6 DIN 976. Note: To fully improve the stability of the structure, we recommend fixing it to the floor using appropriate fasteners, depending on the structure of the floor. Use the holes circled in red in the image above. Page 4 www.egt.com... -
Page 5: Mounting Legs To Supporting Base
2. Insert the tube with the smallest section (6) into the hole of the frame with the notch on the narrow side facing inward and fix it with 2 pcs. pipe connection (7) and screws M6x12 DIN 692. Page 5 www.egt.com... - Page 6 3. Install intermediate tube (8) on tube (6). Leave the pipe slot 8 on the inside of the structure. 4. Install intermediate tube (8) on tube (6). Leave the pipe slot 8 on the inside of the structure. 5. Repea t operations 1 to 4 similarly for the second leg. Page 6 www.egt.com...
-
Page 7: Installing The Jack
1. Mount the assembled jack (10) to the metal frame (3) using an M10x60 DIN 933 screw and an M10 DIN 6923 nut. 2. Install tube (11) between legs in upper position using screw M8x55 DIN 601 and nut M8 DIN 6923. Page 7 www.egt.com... -
Page 8: Installation Of Locking Plates For The Extensions
2. 2. Determine the mounting position according to the product type: Position Jackpot Board LED Panel Circle Small JP-830214 LED Panel Circle Large JP-830413 Warning! At this stage, the marking serves for approximately positioning of the locking plates for the extensions. -
Page 9: Installation Of The Positioning Profiles
DIN 967. The profile serves to fix the stands (15) of the gaming machines. The fixing position depends on the type of gaming machine: Gaming Machine Position G 27-27 Up (EGT-VS21) C/27UR G 50 C Up (EGT-VS28) G 50 J2 Up (EGT-VS32) G 50 J1 Up (EGT-VS30) Page 9 www.egt.com... - Page 10 LED Panel Circle Products Installation 1.2. For SlanTop type slot machines, use positioning profile ST (16) and screw M6x8 DIN 967: Product Positioning Profile LED Panel Circle Small JP-830214 Profile positioning cabinets in a group 4x90 (2x14 panel) LED Panel Circle Large JP-830413...
-
Page 11: Preparation, Installation And Raising To Working Height Of Led Module Xxyy Circle
1. LED Module XxYY Circle is transported mounted on a pallet using transport supports (17). Disassemble them immediately before installation. Note: To gain access to the fasteners of LED Module 4x13 Circle, it is necessary to remove the decorative covers (18). View without decorative covers Page 11 www.egt.com... - Page 12 4. Wire the module according to the current block diagram of the corresponding panel (see LED Jackpot Panels_User_Manual_EN_1_0). 5. Turn on the power and check if the module is functioning. • If it does not function, check that the cables are correctly connected according to the diagram. Page 12 www.egt.com...
- Page 13 2336 G 50 J2 St EGT-VS33 2205 2236 G 50 V St EGT-VS34 2229 2286 The Elevation Hight for LED Panel Circle Small JP-830214 Elevation Hight Gaming Machine Product Gaming Machine Topper Hight Low Level Hight Stage 1 Stage 2...
- Page 14 6.1.3. Lower the jack (10) and pad (12) to the required level. 6.1.4. Fit a second tube (11) to the provided lugs (19) at the lower end of a flanged tube (9) using an M8x55 DIN 601 screw and an M8 DIN 6923 nut. Page 14 www.egt.com...
- Page 15 5.2.2. For precise leveling in both vertical planes, fix the intermediate pipe (8) with a set screw M6x8 DIN 913. 5.2.3. Install the decorative covers (18) on the LED Module 4x13 Circle (applies only to it) after raising it to working height. Page 15 www.egt.com...
- Page 16 2. Determine the mounting position (I / II) of the holders (22) depending on the type of gaming machine. Gaming Machine Topper Installation Position G 27-27 Up EGT-VS21 G 27-27 St EGT-VS22 G 50 C Up EGT-VS28 G 50 C St...
- Page 17 LED Panel Circle Products Installation 3. Mount the left and right glass holder (22) with M3x8 DIN 967 screw. 4. Mount the two add-on elements, left (19) and right (20) to each extension with an M3x6 DIN 915 screw. Page 17 www.egt.com...
- Page 18 5.2. Adjust the height of the extension using an M6x12 DIN 6921 screw and an M6 DIN 6923 nut. Warning! When installing, ensure that the extension is perpendicular to the horizontal plane. After positioning the extensions, fix the locking plates for the extensions (13) with an M6x8 DIN 967 screw. Page 18 www.egt.com...
-
Page 19: Preparation Of The Bearing Plate 1 And Bearing Plate 2
967 screw. The position of the holders (the mark is cut into the holders) and the required mounting holes (the mark on the holders) depend on the type of gaming machines. Gaming Machine Topper Mounting position Mounting Holes G 27-27 Up EGT-VS21 G 27-27 St EGT-VS22 G 50 C Up EGT-VS28 G 50 C St EGT-VS29... -
Page 20: Wiring And Grounding The Metal Structure Of The Base Of The Product Led Module 4X13 Circle
A11 DIN 6902 washer and M10 DIN 6932 nut. Note: Position the bearing plates (25) using the holders (26) inside the group before it is completely closed. Mounted neodymium magnets (27) serve to hold the bearing plates to the gaming machines. Page 20 www.egt.com... - Page 21 LED Panel Circle Products Installation 2. Place the SlanTop type gaming machines (29) inside the structure as far as they will go in the positioning profiles (16). 3. Mount the glass supports (30) with a Polycarbonate M4x12 DIN 965 screw. Page 21 www.egt.com...
-
Page 22: Overall Dimensions Of A Group Of Gaming Machines And Products Led Panel Circle
Overall dimensions of a group of gaming machines and Products LED Panel Circle Note: The configuration is an example. The dimensions of the composition depend on the gaming machines used. The diameter of a composition with chairs depends on the type of chairs. Page 22 www.egt.com... -
Page 23: Contacts
Head Office Address 6 Panorama Sofia Str., Sofia Park RichHill Business Center, Block A 1756 Sofia, BULGARIA EGT Technical Support - Head Office Phone: +359 2 890 24 68 Mobile: +359 896 71 02 72 e-mail: support@egt.com; parts@egt.com EGT Sales - Head Office...
