Summary of Contents for Converters.TV 864
- Page 1 Multi-Media LAN Transmitter and Receiver - ID# 864 Operation Manual...
- Page 2 Introduction HDMI & USB over CAT5/6 TX/RX is a pair of devices that allow a HDMI and/or USB host device to send and save data up to 100 metres away over CAT5/6 cable, while offering four USB port extensions to facilitate operation from the remote end.
- Page 3 System Requirements Input HDMI and or USB source equipment such as DVD, Blue-Ray player ● and or PC/Notebook with connection cables. Output display such as HD TV, monitor and or PC/Notebook, active ● speaker, amplifier and connection cables. ● CAT5e/6 cable up to 100Ms in between of transmitter and receiver. ●...
- Page 4 ⑤ RS 232 IN: This slot is to connect with D-Sub 9pin from PC’s system for controlling both the input source and output display over RS-232. ⑥ IR BLASTER: This slot is to connect with IR blaster cable included in the package for IR signal sending and controlling the HDMI input source equipment.
- Page 5 ⑤ AUDIO OUT: This slot is for external audio output equipment to be connected with active speaker and connection cable. ⑥ HDMI OUT: This slot is to connect with output display such as HD TV or monitor with connection cable. Specifications Transmitter Input Port...
- Page 6 Connection...
