H-5239
GARMENT HANGER
TOOLS NEEDED
Rubber Mallet
7/16" Wrench or Ratchet
2⁄" Bolt x 4
1.
Insert the bottom hanger poles into the top hanger
poles. Using the rubber mallet, tap the poles
together to align the pre-drilled holes. (See Figure 1)
2. Insert two 1" bolts through the holes that connect the
top and bottom hanger poles. (See Figure 2)
3. Using the rubber mallet, tap the bolts into place.
Secure bolts using two cap nuts and tighten with
wrench.
PAGE 1 OF 6
1-800-295-5510
uline.com
PARTS
1⁄" Bolt x 2
1" Bolt x 2
Top Hanger Pole x 2
Bottom Hanger Pole x 2
Crossbar x 1
ASSEMBLY
Pour le français, consulter les pages 5-6.
Locknut x 4
Figure 1
Figure 2
Para Español, vea páginas 3-4.
Cap Nut x 4
0423 IH-5239
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for U-Line H-5239
Summary of Contents for U-Line H-5239
- Page 1 Para Español, vea páginas 3-4. Pour le français, consulter les pages 5-6. H-5239 1-800-295-5510 uline.com GARMENT HANGER TOOLS NEEDED Rubber Mallet 7/16" Wrench or Ratchet PARTS 2⁄" Bolt x 4 1⁄" Bolt x 2 1" Bolt x 2 Locknut x 4...
- Page 2 ASSEMBLY CONTINUED 4. Slide the crossbar onto the top of the hanger poles. Figure 3 Side View Insert two 1⁄" bolts through the holes that connect the crossbar and hanger poles. Secure using two cap nuts. (See Figure 3) 5. Insert the hanger pole ends through the basket to the outside of the frame base.
-
Page 3: Herramientas Necesarias
H-5239 800-295-5510 uline.mx BARRA PARA COLGAR ROPA HERRAMIENTAS NECESARIAS Mazo de Caucho Llave o Matraca de 7/16” PARTES 4 Pernos de 2¼” 2 Pernos de 1¼” 2 Pernos de 1” 4 Tuercas 4 Cubiertas de Tuercas 2 Postes Superiores 2 Postes Inferiores... - Page 4 CONTINUACIÓN DE ENSAMBLE 4. Deslice la barra de soporte en la parte superior Diagrama 3 Vista Lateral de los postes. Inserte dos pernos de 1¼" a través de los orificios que conectan la barra de soporte y los postes. Asegure utilizando dos cubiertas para tuercas.
-
Page 5: Outils Requis
H-5239 1-800-295-5510 uline.ca PORTEMANTEAU OUTILS REQUIS Maillet en Clé ou cliquet de 7/16 po caoutchouc PIÈCES Boulon de 2 ⁄ po - x 4 Boulon de Boulon de 1 po - x 4 Contre-écrou x 4 Écrou borgne x 4 1 ⁄... - Page 6 MONTAGE SUITE 4. Faites glisser la barre transversale sur le dessus des Figure 3 Vue latérale pôles de suspension. Insérez deux boulons de 1 ⁄ po à travers les trous qui relient la barre transversale et les pôles de suspension. Sécurisez-les en utilisant deux écrous borgnes.
