Printed Matter No. 9836 6423 01
Publication Date 2019-10-24
Valid from Serial No. -
DSL-03 Push Button
DSL-03 Blanking Plugs
ESL-04 Standard
ESL-04 Compact
ESL-04 GM Spain
ESL-04 Scania
ESL-04 Rotating Red
ESL-04 Rotating Yellow
ESL-04 Siren
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
8433 0570 10
8433 0570 11
8433 0570 13
8433 0570 16
8433 0570 20
8433 0570 25
8433 0570 30
8433 0570 35
8433 0570 40
WARNING
Stacklight
Product Instructions
Advertisement
Table of Contents
Related Manuals for Atlas Copco DSL-03 Push Button
Summary of Contents for Atlas Copco DSL-03 Push Button
- Page 1 Stacklight Printed Matter No. 9836 6423 01 Publication Date 2019-10-24 Valid from Serial No. - Product Instructions DSL-03 Push Button 8433 0570 10 DSL-03 Blanking Plugs 8433 0570 11 ESL-04 Standard 8433 0570 13 ESL-04 Compact 8433 0570 16 ESL-04 GM Spain...
-
Page 2: Table Of Contents
Table of Contents Product Instructions.................... 3 Configuration .................... 3 Changing a lamp or buzzer .............. 3 Changing the light from constant to flashing ......... 3 Changing switches ................ 4 © Atlas Copco Industrial Technique AB - 9836 6423 01... -
Page 3: Product Instructions
The circuit board inside the lamp comprises of a switch. By setting the switch the light can be changed from constant to flashing. The switch is set to constant light by default. This setting can also be configured in the software. © Atlas Copco Industrial Technique AB - 9836 6423 01... -
Page 4: Changing Switches
Remove the four screws holding the lid and remove the lid. Loosen the screw on the holder and remove the switch. The screw to be loosened is the screw in the slotted corner of the holder. © Atlas Copco Industrial Technique AB - 9836 6423 01... - Page 5 Position the switch so that the white tabs are horizontal. Tighten the screw on the holder. Mount the lid with the four screws. Make sure the light tube is perpendicular to the front plate. © Atlas Copco Industrial Technique AB - 9836 6423 01...
- Page 8 Original instructions Atlas Copco Industrial © Copyright 2019, Atlas Copco Industrial Technique AB. All rights reserved. Any Technique AB unauthorized use or copying of the contents or part thereof is prohibited. This SE-10523 STOCKHOLM applies in particular to trademarks, model denominations, part numbers and drawings.
