14

WALL CONTROLS

* Please see instruction manuals for individual controls for proper wiring and set up of control systems.
Ensure that unit is not plugged when connecting the control.
CENTRAL CONTROLS
These cannot be used with another central control
*Maintain polarity between control and ERV
**Recirculation is only available with products with a damper
STS 2.0
• Our most complete, yet easy-to-use control system
• Sleek design with backlight touchscreen LCD
• ECO mode selects the best operating mode and speed for the season, minimizing energy use associated with
ventilation
• Set preferred indoor relative humidity range and ventilation mode for day and night conditions
• No battery to replace, all programmed settings are retained during power outages
• Maintenance reminder indicator
• Error code messages reduce troubleshooting time
EHC 2.5
• MODE button provides 3 modes of operations: VENTILATION, RECIRCULATION, and STANDBY mode.**
• User selected fan speed: Reduced, Medium, Normal, and 20 minutes per hour.
• AUTO setting allows the homeowner to choose the humidity level.
• When the humidity exceeds the desired setpoint, the ventilation system operates at normal speed.
• Once the desired humidity level is achieved, your ventilation system resumes to its previous mode of
operation.
EHC 2.0
• Press button once for ECONO mode: continuous low or medium speed.
• Press button twice for 20 MIN/H mode: the unit will cycle 20 minutes ON/40 minutes OFF at intermittent
speed and repeat.
• Press button three times for CONT mode: the unit will run continuously in ventilation or recirculation on HIGH
speed.
The wiring connectors can be removed for easier connection.
(+ → + ; - → -)
FEATURES
CONNECT TO
B
A
D+
W
W
