Greentek SOLACE Series Installation, Operation And Maintenance Manual

Greentek SOLACE Series Installation, Operation And Maintenance Manual

Fresh air appliance
Hide thumbs Also See for SOLACE Series:

Advertisement

Available languages

Available languages

Installation, Operation, and Maintenance Manual
Manuel d'installation, d'utilisation et d'entretien
SOLACE Series
®
Fresh Air Appliance (FAA/HRV)
Appareil à air frais (VRC/VRC)
PARTS IN THE BOX
Heat Recovery Ventilator, 1 pc
Hanging Chain Kit, 1 pc
Hardware Kit, 1 pc
Drain Hose Kit, 1 pc
Installation, Operation, and Maintenance Manual,
1 pc
PIÈCES DANS LA BOÎTE
Ventilateur récupératuer de chaleur, 1 pc
Kit de suspension, 1 pc
Vis et matériel d'assemblage, 1 pc
Tuyau d'évacuation , 1 pc
Manuel d'installation, de fonctionnement et de
maintenance, 1 pc
Your ventilation system should be installed in conformance with the appropriate provincial requirements or, in the absence of
such requirements, with the current edition of the National Building Code, and / or ASHRAE's "Good Engineering Practices".
Votre système de ventilation doit être installé conformément aux exigences de la province où vous habitez ou, à défaut de
telles exigences, conformément à l'édition actuelle du Code national du bâtiment du Canada ou aux « méthodes d'ingénierie
appropriées » de l'ASHRAE.
50 Kanalflakt Way, Bouctouche, NB, E4S 3M5
Tel.: 888.724.5211 • email: info@greentek.ca
Greentek reserves the right to modify, at any time and without notice, any or all of its products' features,
designs, components and specifications to maintain their technological leadership position.
Please visit our website www.greentek.ca for more detailed technical information.
Greentek se réserve le droit de modifier partiellement ou entièrement, en tout moment et sans préavis, les
caractéristiques, la conception, les composants et les spécifications de ses produits, afin de conserver sa
position de leader de technologie.
S'il vous plaît visitez notre site siteweb www.greentek.ca pour des informations techiques plus détaillées.
Literature Item #: 445712
Rev Date: 2024-06-03
Numéro d'article de la littérature : 445712
Date de révision : 2024-06-03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SOLACE Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Greentek SOLACE Series

  • Page 1 50 Kanalflakt Way, Bouctouche, NB, E4S 3M5 Tel.: 888.724.5211 • email: info@greentek.ca Greentek reserves the right to modify, at any time and without notice, any or all of its products’ features, designs, components and specifications to maintain their technological leadership position.
  • Page 2 Note Warning/ Information Technical Practical tip Important information note This product earned the ENERGY STAR® by meeting strict energy efficiency guidelines set by Natural Resources Canada and the US EPA. This product meets ENERGY STAR requirements only when used in Canada. To ensure quiet operation of the ENERGY STAR certified H/ERV, each product model must be installed using sound attenuation techniques appropriate for the installation.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS INSTALLATION TYPES HRV ducting for fully Dedicated System ........... . 4 HRV/Furnace ducting for Partially Dedicated System.
  • Page 4: Installation Types

    In the case of a multi-zone system, system blower is running and the HRV is forced air system is not needed. please contact Greentek customer running at "Normal" speed. service prior to installing any installation In the case of a multi-zone system,...
  • Page 5: Installing The Outdoor Vents

    INSTALLING THE OUTDOOR VENTS RECOMMENDED INSTALLATION Intake • Should be located upstream of prevailing winds from exhaust • At a minimum of 900 mm (3') away from dryer vents and furnace exhaust (medium (900 mm) (900 mm) or high efficiency furnaces), driveways, oil 36"...
  • Page 6: Duct Installation

    DUCT INSTALLATION CONNECTING THE DUCTS TO THE HRV EXHAUST TO FRESH OUTDOOR STALE AIR FRESH AIR OUTDOOR HOOD AIR INTAKE • Ducts should be kept short and have as FROM HOME TO HOME few bends or elbows as possible. • 45º elbows are preferable to 90º. •...
  • Page 7: Mounting Options

    MOUNTING OPTIONS WALL MOUNTING BRACKET INSTALLATION INSTALLATION WALL MOUNTING KIT INCLUDES: USE THE GUIDELINES THAT FOLLOW TO HELP DECIDE WHERE TO PUT THE PRODUCT: Safety screws (included) • For best performance, the space’s temperature should be above 54°F (12°C). At a minimum, the space must be above freezing temperatures.
  • Page 8: Chain Mount Installation

    CHAIN MOUNT INSTALLATION INSTALLATION CHAIN MOUNTING KIT INCLUDES: DO NOT Connecting appliances to the HRV is not recommended. These include: • Clothes dryer • Range top • Stovetop fan • Central vacuum system • Bathroom exhaust fans unless they are specifically designed for this purpose •...
  • Page 9: Wall Controls

    WALL CONTROLS * Please see instruction manuals for individual controls for proper wiring and set up of control systems. 1. Ensure that unit is not plugged when connecting the control. The wiring connectors can be removed for easier connection. CENTRAL CONTROLS These cannot be used with another central control (+ →...
  • Page 10 WALL CONTROLS (CONT'D) AUXILIARY CONTROL –These controls can be paired with central controls or combined together. (+ → + ; - → -) *Maintain polarity between control and HRV T SERIES FEATURES CONNECTS TO • 20/40/60 minute timer with three LED light •...
  • Page 11: Balancing

    BALANCING Balancing must be completed using the Greentek STS 2.0 Programmable Touch Screen Wall Control Supply manometer High High ENTERING BALANCING MODE Exhaust In the options menu during manometer the initial 5 second countdown sequence, long press on "ECO" area for 5 seconds to enter basic balancing mode.
  • Page 12: Wiring Diagram

    WIRING DIAGRAM - SOLACE 1.2H, 1.5H, 2.0H...
  • Page 13 WIRING DIAGRAM - SOLACE 1.5H-EC, 2.5H-EC (CONT'D)
  • Page 14 WIRING DIAGRAM (CONT'D) WIRING DIAGRAM TO Standard Accessory Control Contact Standard Furnace Interlock Wiring FURNACE THERMOSTAT TERMINALS FOUR WIRE TWO WIRE heating only FOR A FURNACE CONNECTION TO A COOLING SYSTEM: On some newer furnaces and older FURNACE thermostats, energizing the R and 24-VOLT TERMINAL BLOCK G terminal at the furnace has the...
  • Page 15: Control Hierarchy / Operations

    CONTROL HIERARCHY / OPERATIONS Terminal Block Label Description Remote off function (dry contact) – When S+ and S- terminals are shorted together, the ventilation product will be forced into standby mode until the dry contact is opened. Digital communication lines for four-wire controllers. ↓...
  • Page 16: Troubleshooting

    TROUBLESHOOTING Problem Causes Solutions Air is too dry Dehumidistat control is set too low Increase the desired level of humidity. Change ventilation mode from continuous mode to standby. HRV out of balance Have contractor balance HRV airflows Air is too humid Dehumidistat control is set too high Reduce the desired level of humidity.
  • Page 17: Filter Location

    MERV8/MERV13 the serial number will be used for Filter (Optional) the beginning of the warranty period. • The fans found in all Greentek HRVs require no lubrication, and are factory balanced to prevent vibration Electrostatic and promote silent operation.
  • Page 19 50 Kanalflakt Way, Bouctouche, NB, E4S 3M5 Tél.: 888.724.5211 • email : info@greentek.ca Greentek se réserve le droit de modifier partiellement ou entièrement, en tout moment et sans préavis, les caractéristiques, la conception, les composants et les spécifications de ses produits, afin de conserver sa position de leader de technologie.
  • Page 20 Remarque Avertissement/ Information Information Conseil pratique Remarque technique importante Ce produit a obtenu la certification ENERGY STAR® en respectant les directives strictes d'efficacité énergétique établies par Ressources naturelles Canada et l'EPA des États- Unis. Ce produit répond aux exigences ENERGY STAR uniquement lorsqu'il est utilisé au Canada. Pour assurer un fonctionnement silencieux du VRC/E certifié...
  • Page 21 TABLE DES MATIÈRES TYPES D’INSTALLATION Conduits de VRC pour un système entièrement spécialisé ........22 Conduits de VRC/chaudière pour un système partiellement spécialisé...
  • Page 22: Types D'installation

    Dans le cas d'un système multi-zone, synchronisé d'un système à air pulsé. contacter le service à la clientèle de Greentek avant d'installer tout type d'installation Suggéré pour : nécessitant l'utilisation synchronisé d'un système à air pulsé.
  • Page 23: Installation Des Évents Extérieurs

    INSTALLATION DES ÉVENTS EXTÉRIEURS INSTALLATION RECOMMANDÉE Admission • Doivent être situés en amont des vents dominants de l’échappement. • Distance minimale de 900 mm (3 pi) des évents de la sécheuse et de l’échappement de 900 mm 900 mm la chaudière (chaudières à efficacité moyenne (3 pi) min.
  • Page 24: Installation Des Conduits

    INSTALLATION DES CONDUITS RELIER LES CONDUITS AU VRC ÉVACUATION VERS ADMISSION D’AIR AIR VICIÉ AIR FRAIS L'EXTÉRIEUR FRAIS EXTÉRIEUR • Les conduits doivent être courts et DE LA MAISON VERS LA MAISON présenter le moins de plis ou coudes possibles. •...
  • Page 25: Options De Fixation

    OPTIONS DE FIXATION LE KIT DE MONTAGE MURAL D'INSTALLATION COMPREND: UTILISEZ LES INSTRUCTIONS SUIVANTES POUR VOUS Vis de sécurité AIDER À DÉCIDER OÙ (incluses) INSTALLER LE PRODUIT: • Pour une meilleure performance, la température de l’espace devrait être maintenue au-dessus de 12 °C (54 °F).
  • Page 26: Installation À L'aide De Chaînes

    INSTALLATION À L’AIDE DE CHAÎNES LE KIT DE MONTAGE DE LA CHAÎNE D'INSTALLATION COMPREND: À NE PAS FAIRE Il n’est pas recommandé de relier des appareils au VRC, dont les : • Sécheuses • Cuisinières • Hottes de cuisinière • Systèmes d’aspirateur central •...
  • Page 27: Commandes Murales

    COMMANDES MURALES * Veuillez consulter les manuels d’instructions des dispositifs de commande individuels pour connaître la bonne configuration de câblage et l’installation adéquate des systèmes de commande. 1. Assurez-vous que l’appareil n’est pas branché lorsque vous reliez la commande. Les raccords de câblage peuvent être retirés pour faciliter le branchement. COMMANDES CENTRALES Ceux-ci ne peuvent pas être utilisés avec une autre commande centrale (+ →...
  • Page 28 COMMANDES MURALES (SUITE) COMMANDE AUXILIAIRE – Ces commandes peuvent être associées à des commandes centrales ou combinées ensemble. (+ → + ; - → -) *Conserver la polarité entre la commande et le VRC SÉRIE T CARACTÉRISTIQUES RELIER À • Minuterie de 20/40/60 minutes avec trois voyant à DEL. •...
  • Page 29: Équilibrage

    ÉQUILIBRAGE L’équilibrage doit être réalisé à l’aide de la commande murale à écran tactile programmable Greentek STS 2.0. Manomètre d’alimentation Élevé Élevé ACCÉDER AU MODE D’ÉQUILIBRAGE Faible Faible Manomètre Dans le menu d’options, lors de la d’évacuation séquence de décompte initiale de 5 secondes, appuyez sur la zone...
  • Page 30: Schéma Électroniques

    SCHÉMA DE CÂBLAGE - SOLACE 1.2H, 1.5H, 2.0H...
  • Page 31 SCHÉMA DE CÂBLAGE - SOLACE 1.5H-EC, 2.5H-EC (SUITE)
  • Page 32 SCHÉMA DE CÂBLAGE (SUITE) SCHÉMA DE CÂBLAGE Contact de commande d’accessoire standard Fil de verrouillage de chaudière alternatif VERS LA CHAUDIÈRE BORNES DE THERMOSTAT QUATRE FILS DEUX FILS chauffage DISPOSITIF DE VERROUILLAGE seulement POUR RELIER UNE CHAUDIÈRE À UN SYSTÈME DE REFROIDISSEMENT : Sur certaines nouvelles chaudières et BLOC DE JONCTION...
  • Page 33: Hiérarchie / Opérations De Contrôle

    HIÉRARCHIE / OPÉRATIONS DE CONTRÔLE Étiquette de bornier Description Fonction d'arrêt à distance (contact sec) – lorsque les bornes S+ et S- sont court-circuitées, le produit de venti- lation est forcé en mode veille jusqu'à ce que le contact sec soit ouvert. Lignes de communication numériques pour contrôleurs à...
  • Page 34: Dépannage

    DÉPANNAGE Problème Causes Solutions L’air est trop sec. Le réglage du déshumidistat est trop faible. Augmentez le taux d’humidité souhaité. Changez le mode de ventilation de continu à en attente. Le VRC est déséquilibré. Demandez à un entrepreneur d’équilibrer les débits d’air du VRC. L’air est trop humide.
  • Page 35: Emplacement Du Filtre

    (Optionnel) servira pour établir la période de la garantie. • Les ventilateurs dans tous les VRC Filtres de Greentek ne nécessitent aucune lubrification, et ils sont équilibrés électrostatiques en usine afin de prévenir les vibrations et favoriser un fonctionnement silencieux.
  • Page 36: Parts List

    PARTS LIST/LISTE DE PIÈCES Solace 1.2H Solace 1.5H Solace 2.0H Solace 1.5H-EC Solace 2.5H-EC BOM # Description (463299) (463313) (463314) (463315) (463316) MOTOR 448002 428515 428516 428517 428518 CELL 414708 414709 414710 414709 414710 MERV3 (pack of 2) 428519 428520 428521 428520 428521...
  • Page 40 Greentek reserves the right to make technical changes. Greentek se réserve le droit d’apporter des modifications For updated documentation please refer to www.greentek.ca techniques. Pour de la documentation à jour, veuillez consulter le site www.greentek.ca Greentek MD...
