Mounting
CEILING INSTALLATION
1 Using the screw with washer mount the mounting bracket through the
rubber insulator. Ensure the bracket is straight.
3 Slide the unit the bracket as shown above.
We recommend placing the duct on the unit at this
stage of the unit's installation.
2 Using the screw with washer mount the brackets at the bottom of the
unit.
4 Secure both side of the unit using the same method as step 1.
11
