MPS-ULCAN6-5 or MPS-ULCAN8
Installation Instructions
Speaker wires
Mounting the Speakers
Locate the grommet on the rear of the pod. Insert the wire leaving
enough slack to mount the speaker.
These PODS have been designed to be universal, this fit will require
holes to be drilled in the PODs mounting flange.
It's recommended to install speakers on a bench. Place the speaker
into the opening, mark the needed holes.
Using the hardware provided with the speakers, select the proper
drill bit and carefully drill the required holes into the flange.
Connect up the speaker wires, from the previous steps and
proceed to mount the PODs to the vehicle.
Metra Insert
Using a small Phillips screw driver, insert
the logo plate and secure with the (2)
screws. Logo can be mounted "up or
down" depending on the look desired.
MetraOnline.com
Technical Support: 386-257-1187
Advertisement
Related Manuals for Metra Electronics MPS-ULCAN6-5
Summary of Contents for Metra Electronics MPS-ULCAN6-5
- Page 1 MPS-ULCAN6-5 or MPS-ULCAN8 Installation Instructions Speaker wires Mounting the Speakers Locate the grommet on the rear of the pod. Insert the wire leaving enough slack to mount the speaker. These PODS have been designed to be universal, this fit will require holes to be drilled in the PODs mounting flange.
- Page 2 MPS-ULCAN6-5 or MPS-ULCAN8 Installation Instructions 1. Using a 5mm HEX remove 2. Select correct 3. Using 2.5mm set 4. Using 4mm HEX, 5. mount the CAN to screws from mount. adaptor and load screw adjust set tighten the mount the tube, using a 5MM into the two halves desired CAN rotation.
- Page 3 MPS-ULCAN6-5 Specifications Interior Volume: 0.05 MetraOnline.com Technical Support: 386-257-1187...
- Page 4 MPS-ULCAN8 Specifications Interior Volume: 0.1 MetraOnline.com Technical Support: 386-257-1187...
