Specifications - IKONIX TVB-2 Instruction Sheet

TVB-2 Technical Specifications
MODEL
COMPONENTS
120kΩ
1MΩ
0.5Ω
49mΩ
100mΩ
GENERAL
TEST POINTS
PASS
ACW/DCW 2MΩ / 6W
FAIL
ACW/DCW 120kΩ / 50W
PASS
IR 4MΩ / 12W
FAIL
IR 1MΩ / 3W
PASS
GC 0.5Ω / 2W
FAIL
GC 2Ω / 8W
PASS
GB 50mΩ / 50W
FAIL
GB 200mΩ / 50W
ENVIRONMENT
DIMENSIONS
WEIGHT
Note: if the resistance is greater than 200mΩ you must reduce the test current to 10A in order to display the actual resistance reading.
1
Note: si la résistance est supérieure à 200mΩ vous devez réduire le courant de test par 10A afin d'afficher la valeur de la résistance réelle.
1
© Ikonix
2.5KVAC / 50W / 1% ± 50ppm
3KVDC / 3W / 1% ± 50ppm
350VDC / 2W / 5% ± 300ppm
100VDC / 50W / 1% ± 50ppm
100VDC / 25W / 1% ± 100ppm
TEST CONDITION
1. ACW: 1240V, 10mA or DCW: 2121V, 5000uA
2. Maximum Voltage 2500V
3. Test duty cycle, OFF time = ON time x 2
4. Maximum ON time limit 30 seconds
5. Recommended 2s ramp time
1. ACW: 1240V, 10mA or DCW: 2121V, 5000uA
2. Maximum Voltage 2300V
3. Test duty cycle, OFF time = ON time x 8
4. Maximum ON time limit 5 seconds
5. Recommended 2s ramp time
1. IR: 500V, 2MΩ
2. Maximum Voltage: 2500V
1. IR: 500V, 2MΩ
2. Maximum Voltage 1000V
1. GC: 0.1A, 1Ω
2. Maximum Current 1A
1. GB: ≤ 30A, 100mΩ
2. Maximum Current 30A
3. Test duty cycle, OFF time = ON time x 6
4. Maximum ON time limit 5 seconds
5. Maximum resistance range at 30A is 200mΩ
1. Test Current 15A
2. Test duty cycle, OFF time=ON time x 6
3. Maximum ON time limit 10 seconds
4. Maximum resistance range at 30A is 200mΩ
32° F - 104° F (0° - 40° C)
7.3" (W) x 5.75" (L) x 2.95" (H) , 186mm x 146mm x 75 mm
1.55 lbs
TVB-2
RESISTOR SPECIFICATION
1
1
TVB-2 Instruction Sheet

SPECIFICATIONS

2%
2%
2%
2%
5%
5%
5%
3%
2
