Pos. Component Article Name
BFS-i06.1
Bearingless Fan
1
(ATEX / IECEx)
BFS-i06.1-22 (2.2 m)
Pos. Component Article Name
Set of ICP-5.1-03
2 Adaptor Cable Set
and ICS-5.1-03
ICP-5.1-03 (0.3 m)
2a Adaptor Cable Power
ICP-5.1-15 (1.5 m)
ICS-5.1-03 (0.3m)
2b Adaptor Cable Signals
ICS-5.1-15 (1.5 m)
TIB 240-148
3 AC/DC Power Supply
(Traco)
4 Interface Panel FIP-2.1
5 User Panel LUI-B.1-06
6 USB-RS485 Adaptor YN-485I-TR
IP Adaptor Cable ICS-1.1-10 (1 m)
7
Signal 6 Wires ICS-1.1-30 (3 m)
IP Adaptor Cable ICS-1.2-10 (1 m)
8
Signal 6 Wires ICS-1.2-50 (5 m)
IP Adaptor Cable
9 ICS-1.3-50 (5 m)
Signal 6 Wires
ATEX Cable ACS-A.1
10
Sealing System (Roxtec)
Note 1: See section 3.1.2 for a list of tested power supplies for one or multiple fans
PL-3502-00, Rev04, DCO# 24-054 This document and its content is confidential and the property of Levitronix
disclosed or used for manufacturing or sale of Levitronix
Article # Characteristics
Voltage, Power Input
Max. Pressure, Max. Flow
Point of Max. Power
ATEX / IECEx Marking
IP Rating
(5 m) 100-10184
Electrical Interfaces
100-10185
Standard Firmware
Mechanical Interface
Cable Length
Materials
Weight
Table 1: Specification of standard configuration
Article # Characteristics
100-91510
Specifications
190-10463
190-10490
Purpose
Specifications
190-10464
190-10491
Purpose
Voltage Output / Input
1
100-40032 Power Output
Certification / Standards
Structure/Design
1
100-91659
Purpose
Specifications
100-30549
Purpose
Structure/Design
100-30392
Purpose
Specifications
190-10344
190-10345
Purpose
Specifications
190-10440
190-10346
Purpose
Specifications
190-10389
Purpose
Materials
100-90292
Note
Table 2: Specification of standard accessories
Value / Feature
48 V DC ±10%, 240 W
(Option: 24 V DC ±5%, 65 W, with reduced max. speed of 8000 rpm)
915 Pa (3.68 inH
2
3
850 Pa, 440 m /h, 13000 rpm
(Optional 24 V supply voltage: 320 Pa, 260 m
1258 2503
Ambient and gas temperature range 0 to 40 °C
IP67
PLC with 2 analog inputs
1 analog output
2 digital inputs
2 digital outputs
RS485 interface, Modbus protocol (extended control or service through
fieldbus or Levitronix
V3.48
Flange on both motor sides with mounting holes 4 x Ø 12 mm on
diameter 138 mm. Flange inside Ø 100 mm, outside 120 mm x 120 mm
5/2.2 m + 0.2/0.8 m wires with TE connectors for power and PLC signals
Polypropylene, electrically conductive, flame retardant
Cable: PVC jacket, PVDF bushing
1.4 kg, 3.1 lb (for 5 m version)
Value / Feature
See 2a and 2b
PVC insulated open wires (3 x 1.5 mm
Connection of fan cable to DC power supply
PVC insulated open wires (12 x 0.14 mm
Connection of fan cable to PLC signals and RS485 fieldbus
48 V DC / 85 – 264 V AC
240 W (360 W for 4 s)
CB, UL, CSA, Semi F47
DIN-rail mountable PCB with connectors for:
- 4 x Signal for BFS-i06 fans (TE Connectivity 1-1827875-6)
- 4 x Power for BFS-i06 fans (TE Connectivity 1-178136-3)
- 1 x Power supply connector (Wago 2624-3105)
- 22 x PLC push-in (analog/digital inputs/outputs, RS485)
- 1 x Circular COM for LUI-B.1 or USB-RS485 adaptor
Easy wiring of power and PLC signals for up to four BFS-i06 fans, see
section 4.3 for further information
Firmware A8.00, IP65, 5 to 24 V supply voltage
Control of fan via handheld device with display and menu buttons.
USB connector (A) with termination resistor and cable (2 m) with
connector pair (B and C) for external RS485 wire connection.
Magnetically isolated. Included is a USB space saver cable (D)
Control or service of fan via USB port of a PC with Levitronix® Service
Software
PVC jacket, connectors: circular to circular type
Connection of user panel (LUI-B.1) to interface panel (FIP-2.1)
PVC jacket, connectors: circular type to screw type
Connection of user panel (LUI-B.1) to adaptor cable (ICS-5.1) and 5 to
24 V supply
PVC jacket, connectors: circular type to screw type
Connection of interface panel (FIP-2.1) to USB adaptor (YN-485I-TR)
Sleeve (A) and Gasket (B): Stainless Steel, EPDM
Frame(C) and 2x Cable Module (D): Roxylon (EPDM Rubber)
Lubricant (E) and measurement plates (F) are included
