This manual contains information necessary for the safe and proper use of the BFS-i06 bearingless fan.
Included are specifications for the standard configurations and instructions regarding its use, installation,
operation, adjustment, inspection, and maintenance. For special configurations refer to accompanying
information. Please familiarize yourself with the contents of this manual to ensure the safe and effective
use of this product. After reading this manual, please store it where the personnel responsible for operating
the bearingless fan can readily refer to it at any time.
®
The Levitronix
Service Software (with according manual Levitronix
operation, troubleshooting, parameter logging, and user specific configurations. For the bearingless fan
®
the Levitronix
Service Software version V2.0.10.0 or higher is needed.
PL-3502-00, Rev04, DCO# 24-054
This document and its content is confidential and the property of Levitronix
disclosed or used for manufacturing or sale of Levitronix
Bearingless Fan BFS-i06
915 Pa
3
500 m
/h
USER MANUAL
(3.68 inH
O)
2
(294 cfm)
Doc.# PL-4138-00) is available for
®
and shall not be reproduced, distributed,
®
products without the expressed written consent of Levitronix
User Manual for BFS-i06
www.levitronix.com
First Release: 26-Jan-2018
Last Update: 01-Mar-2024
®
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BFS-i06 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Levitronix BFS-i06

  • Page 1 (294 cfm) USER MANUAL This manual contains information necessary for the safe and proper use of the BFS-i06 bearingless fan. Included are specifications for the standard configurations and instructions regarding its use, installation, operation, adjustment, inspection, and maintenance. For special configurations refer to accompanying information.
  • Page 2: Table Of Contents

    Disposal of Equipment – WEEE Directive 2012/19/EU ................23 7.1.3 Symbols and Signal Words......................24 PL-3502-00, Rev04, DCO# 24-054 This document and its content is confidential and the property of Levitronix ® and shall not be reproduced, distributed, disclosed or used for manufacturing or sale of Levitronix ®...
  • Page 3: Safety Precautions

    1 Safety Precautions The BFS-i06 bearingless fan is designed to be used in industrial production machines and equipment containing ventilation circuits. Typical applications are semiconductor and chemical manufacturing equipment. Installation shall be done by qualified personnel only. The following safety precautions and all “CAUTION”, “WARNING”...
  • Page 4: Specifications

    2.1 Specification of Components Figure 1: Standard fan Figure 2: Accessories PL-3502-00, Rev04, DCO# 24-054 This document and its content is confidential and the property of Levitronix ® and shall not be reproduced, distributed, disclosed or used for manufacturing or sale of Levitronix ®...
  • Page 5 100-91659 - 22 x PLC push-in (analog/digital inputs/outputs, RS485) - 1 x Circular COM for LUI-B.1 or USB-RS485 adaptor Easy wiring of power and PLC signals for up to four BFS-i06 fans, see Purpose section 4.3 for further information Specifications Firmware A8.00, IP65, 5 to 24 V supply voltage...
  • Page 6: System Configuration

    Figure 4: ATEX / IECEx system configuration (left) and connection with interface panel (right) Note: Connection options (right of dashed line) are interchangeable with Figure 3 PL-3502-00, Rev04, DCO# 24-054 This document and its content is confidential and the property of Levitronix ® and shall not be reproduced, distributed, disclosed or used for manufacturing or sale of Levitronix ®...
  • Page 7: Basic Dimensions Of Main Components

    A = 5.00 m [196.85 in] B = 0.20 m [7.87 in] Figure 5: Basic dimensions in mm [in] of bearingless fan BFS-i06.1 Note: Non-tolerated dimensions are for reference only, dimensions in inch are rounded only Figure 6: Basic dimensions of adaptor cables ICP-5.1-YY and ICS-5.1-YY...
  • Page 8: General Environmental Conditions

    Pollution degree Table 3: Environmental conditions for bearingless fan PL-3502-00, Rev04, DCO# 24-054 This document and its content is confidential and the property of Levitronix ® and shall not be reproduced, distributed, disclosed or used for manufacturing or sale of Levitronix ®...
  • Page 9: Pressure-Flow Curves

    8000 rpm for 24 V supply voltage. • ® Negative Rotation Direction: Negative rotational speeds can be enabled in the Levitronix Service Software or via Modbus command. This feature can be used to block an existing flow, as replacement for actively controlled valves.
  • Page 10: Engineering Information

    Rotational Speed / rpm Figure 11: Peak power consumption during acceleration (DC input) Note 1: Typical values measured for BFS-i06.1 at operating point with maximum power consumption Note 2: Dashed line: example of optional input power limitation PL-3502-00, Rev04, DCO# 24-054 This document and its content is confidential and the property of Levitronix ®...
  • Page 11: Power Supply

    3.1.3 Inrush Current The BFS-i06 relies on the inrush current limiter of the power supply and does not have a built-in inrush current limiter. Therefore, high inrush currents may occur if the fan is directly connected to an already powered DC socket.
  • Page 12: Sound Pressure Level

    3.2 Sound Pressure Level The sound pressure level emitted by the BFS-i06 strongly depends on the installation, operating point, and rotational speed. It is recommended that customers measure the sound pressure level after installation of the fan in their setup during typical operation.
  • Page 13: Installation

    RS485 master by connecting RS485+, RS485- and ground to each other. See Figure 13. ® Address setting of the fan units can be done with the Levitronix Service Software and a PC. A termination resistor is recommended for long bus lengths. Do not use closed ring arrangements.
  • Page 14 Table 5: Standard configuration of motor connectors ® Note: Levels and assignments of analog and digital inputs and outputs are configurable in Levitronix Service Software or through Modbus protocol. See firmware specification (SW-3502-04) for detailed information YN-485I-TR ICS-1.2 ICS-1.3...
  • Page 15 Recommended for main bus line > 5 m Figure 13: Multi-fan system array on RS485 fieldbus PL-3502-00, Rev04, DCO# 24-054 This document and its content is confidential and the property of Levitronix ® and shall not be reproduced, distributed, disclosed or used for manufacturing or sale of Levitronix ®...
  • Page 16: Electrical Schematics Overview Of Motor Interface

    Note 1: RS485 to USB converter cable with termination resistors to be ordered according to Table 2 Note 2: Do not use multiple master devices on the RS485 at the same time PL-3502-00, Rev04, DCO# 24-054 This document and its content is confidential and the property of Levitronix ® and shall not be reproduced, distributed, disclosed or used for manufacturing or sale of Levitronix ®...
  • Page 17: Mechanical Installation

    Only remove rotor if necessary. Keep distance to pacemakers and handle fan rotor with care. WARNING Only specific BFS-i06 bearingless fans are classified for the use in Ex classified locations. Refer to the corresponding section in the manual. WARNING In case separation of Ex classified locations is needed at installation, the relevant safety precautions to fulfill the relevant regulatory requirements must be considered.
  • Page 18: Mounting Proposals

    4.2.2 Mounting Proposals BFS-i06 fans can be adapted into many different duct systems and may be operated in parallel or series to achieve higher flow or pressure. This section shows a few of many possible mounting scenarios. For more in- ®...
  • Page 19: Installation Examples With Interface Panel

    The interface panel FIP-2.1 can be used for easy wiring of up to four fans. The panel can be mounted to a DIN Figure 18 ® rail. describes two of many possible scenarios. For more in-depth information contact Levitronix technical support (chapter 6.3). See section 3.1.2 for the selection of the power supply. Power supply Power...
  • Page 20: Operation

    Do not touch the fan rotor while it is moving. Please consider the following notes for safe and successful operation of the bearingless fan BFS-i06 to prevent injury to personnel or damage to equipment: •...
  • Page 21: Operation For Atex / Iecex Application

    Do not operate the fan against closed valves Operation against closed valves might lead to increased gas temperature. PL-3502-00, Rev04, DCO# 24-054 This document and its content is confidential and the property of Levitronix ® and shall not be reproduced, distributed, disclosed or used for manufacturing or sale of Levitronix ®...
  • Page 22: Troubleshooting And Support

    The integrated PLC provides status and error signals. However, the source of error cannot be identified by  these signals. For detailed analysis and debugging it is recommended to use the Levitronix Service Software (see below). Alternatively, the Status, Error, Warning and Message bytes can be read using Modbus ®...
  • Page 23: Appendix

    7 Appendix 7.1 Regulatory Status 7.1.1 CE / UKCA Marking We herewith declare that the Bearingless Fan BFS-i06, in its various configurations, is in conformity with the below mentioned European Directives and UK Statutory Instruments. Machinery Directive 2006/42/EU / SI 2008/1597: The machinery directive essentially has been followed by a risk analysis, according to mitigation actions and a user manual for safe operation.
  • Page 24: Symbols And Signal Words

    Table 7: Safety symbols and signal words PL-3502-00, Rev04, DCO# 24-054 This document and its content is confidential and the property of Levitronix ® and shall not be reproduced, distributed, disclosed or used for manufacturing or sale of Levitronix ®...
