3.3..5 V
Master
W
510
RS485+
W
120
RS485-
W
510
Ground
Initialization network:
Always recommended, to be implemented at master
PL-3502-00, Rev04, DCO# 24-054 This document and its content is confidential and the property of Levitronix
disclosed or used for manufacturing or sale of Levitronix
Branch bus lines:
Main bus line:
Figure 13: Multi-fan system array on RS485 fieldbus
sum of all branch lengths < 33 m
< 100 m. Shielded twisted wires recommended
® and shall not be reproduced, distributed,
® products without the expressed written consent of Levitronix
User Manual for BFS-i06
www.levitronix.com
120
Termination:
Recommended for main bus line > 5 m
® .
W
15
