Levitronix BFS-i06 User Manual page 14

Pin Wire Color Designation
Power Connector:
TE D3200 1-178128-3
1 Red Power +
2 Black Power -
3 Yellow-green GND / earth
PLC Connector:
TE D1200 1-1827864-6
B4 Pink Digital input 1
B5 Gray Digital input 2
B3 Yellow Digital input ground
B6 Violet Analog input 1
B1 Gray-pink Analog input 2
B2 Blue Analog input ground
A2 Brown Digital output 1
A3 White Digital output 2
A1 Blue-red Analog output
A5 Brown-green RS485 +
A6 White-yellow RS485 -
A4 White-green Ground
Note: Levels and assignments of analog and digital inputs and outputs are configurable in Levitronix
Modbus protocol. See firmware specification (SW-3502-04) for detailed information
YN-485I-TR
Pin
Open wire to USB adaptor
1 -
2 -
3 -
4 Ground
5 RS485-
6 RS485+
Table 6: Pin definition of screw type connectors on adaptor cables
PL-3502-00, Rev04, DCO# 24-054 This document and its content is confidential and the property of Levitronix
disclosed or used for manufacturing or sale of Levitronix
Description
Counterpart:
TE D3200 1-178128-3
Supply
Supply
Cable shield
Counterpart:
TE D1200 1-1903131-6
Default: not used
Process / speed mode switch
Reference for digital inputs
Setpoint speed / process value
and enable / reset fan
Actual process value
(pressure or flow sensor)
Reference for analog inputs
System status signal
Error signal
Actual speed
RS485 interface
Reference for digital and analog
outputs
Table 5: Standard configuration of motor connectors
ICS-1.2
Open wire to user panel LUI-B
RS485+
RS485-
Ground
-
-
+ 24 VDC supply for LUI-B
Standard Levels
+ 48 VDC ± 10 %
+ 24 VDC ± 5 % (reduced performance)
Internally connected to cable shield
To be connected to earth
(Configurable: enable / reset)
5...24 V (min. 30 ms)  Process mode
0 V / n.c. (min. 30 ms)  Speed mode
4...20 mA  0...13000 rpm / 0...100 % setpoint
> 3.5 mA (edge triggered)  On / reset
4...20 mA  0...100 %
Circuit closed  Power output on
Circuit open  Power output off
Ground (A4) is reference
Circuit closed  No errors present
Circuit open  System is in error state
Ground (A4) is reference
0...13000 rpm  4...20 mA
Ground (A4) is reference
Modbus protocol
GND / earth (internally connected to power - and cable
shield)
® and shall not be reproduced, distributed,
® products without the expressed written consent of Levitronix
User Manual for BFS-i06
www.levitronix.com
®
Service Software or through
ICS-1.3
Interface panel FIP to USB adaptor
RS485+
RS485-
Ground
-
-
-
® .
14
