2-6. Floor type

Model name
Power supply
Available voltage range
Capacity
Input power
Running current
Cooling
Airflow rate
Fan
Heating
Type × Q'ty
Motor output
Cooling
Sound pressure level *
Heating
Dimensions (H × W × D)
Fin pitch
Heat exchanger type Rows × Stages
Pipe type
Fin type
Material
Enclosure
Color
Net
Dimensions
(H × W × D)
Gross
Net
Weight
Gross
Liquid
Size
Connection pipe Gas
Method
Material
Drain hose
Size
Cooling
Operation range
Heating
Remote controller type
NOTES:
• The protective function might work when using it outside the operation range.
• *Sound pressure level:
– Measured values in manufacturer's anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
2-6. Floor type
Btu/h class
W
A
HIGH
MED
LOW
QUIET
3
CFM (m /h)
HIGH
MED
LOW
QUIET
W
HIGH
MED
LOW
QUIET
dB (A)
HIGH
MED
LOW
QUIET
in (mm)
FPI
in (mm)
lb (kg)
in (mm)
in (mm)
°F (°C)
%RH
°F (°C)
- 12 -
AGU9RLF AGU12RLF
208/230 V ~ 60 Hz
187—264 V
9,000 12,000
16 20
0.15 0.18
312 (530) 353 (600)
259 (440) 288 (490)
212 (360) 224 (380)
159 (270) 159 (270)
312 (530) 353 (600)
270 (460) 300 (510)
224 (380) 241 (410)
159 (270) 159 (270)
Crossflow fan × 2
16
39 42
34 36
28 30
22 22
39 42
35 38
30 32
22 22
14-7/8 × 21-5/8 × 1-1/16 (378 × 550 × 26.6)
21
2 x 18
Copper tube
Aluminum
Polystyrene
White
(Approximate color of Munsell N 9.25/)
23-5/8 × 29-1/8 × 7-7/8 (600 × 740 × 200)
27-9/16 × 32-5/16 × 12-3/16 (700 × 820 × 310)
31 (14)
37 (17)
Ø1/4 (Ø6.35)
Ø3/8 (Ø9.52)
Flare
PVC
Ø9/16 (Ø13.8) (I.D.), Ø11/16 (Ø16.7) (O.D.)
64 to 90 (18 to 32)
80 or less
60 to 86 (16 to 30)
Wireless (Wired [option])
AGU15RLF
14,000
23
0.20
383 (650)
306 (520)
235 (400)
159 (270)
383 (650)
318 (540)
253 (430)
159 (270)
44
38
31
22
44
39
33
22
Ø1/2 (Ø12.70)
