16. Function settings

To adjust the functions of this product according to the installation environment, various types of
function settings are available.
NOTE: Incorrect settings can cause a product malfunction.
16-1. Compact cassette type indoor unit (setting by DIP switch)
By using some components on the PCB, you can change the function settings.
¢ Component location
Components on the indoor unit main PCB used for the function settings are located as shown in
the following figure.
¢ DIP switch setting
• SW101: Setting change prohibited
16-1. Compact cassette type indoor unit (setting by DIP switch)
SW101
1 2 3
- 184 -
