17-2. Slim duct type
¢ Models: ADUH07LUAS1, ADUH09LUAS1, ADUH12LUAS1,
ADUH18LUAS1, and ADUH24LUAS1
Part name
Operating manual
Installation manual
Installation template
Washer
Drain hose
Hose band
Drain hose insulation B
17-2. Slim duct type
Exterior Q'ty
1 Cable tie (large)
1 Cable tie (medium)
Filter (small)
1 (Other than 18
model)
Filter (large)
8
(For 18/24 models)
Coupler heat
1
insulation (large)
Coupler heat
1
insulation (small)
1
- 222 -
Part name Exterior Q'ty
4
3
2
2 (18 model)
1 (24 model)
1
1
