15-3. Wireless remote controller (UTY-LNTU: Optional part)
¢ Overview
Signal
transmitter
MIN. HEAT
button
TEMP.
button
Economy
button
Start/Stop
button
NOTE: Functions may differ by type of the indoor unit. For details, refer to the operation manual.
Display panel
Transmit indicator
Mode indicator
To facilitate explanation, the accompanying illustration has been drawn to show all possible indicators;
in actual operation, however, the display will only show those indicators appropriate to the current oper-
ation.
15-3. Wireless remote controller (UTY-LNTU: Optional part)
MODE button
ON TIMER button
OFF TIMER button
TIMER SELECT button
SLEEP TIMER button
TIMER CANCEL button
- 164 -
FAN button
SWING button
SET button
RESET button
TEST RUN button
CLOCK ADJUST button
Temperature
Fan speed indicator
Swing indicator
Clock and Timer indicator
indicator
