6. Servo installation
Install the prepared servos to wing servo bays. Use a 0,8 mm steel wire with Z bends as a
linkage between the servos and aileron and flap control horns. Elevator and rudder servo will
be fixed by servo holder or directly glued in the fuselage.
See video guide Douglas DC-3 / C-47 Dakota servo assembly
you will need:
6x Corona CS238MG or any similar sized servos
13 x 30 x 30 mm / 0.51 x 1.18 x 1.18 inches
Servo cable extension
Snap knife,
... print your plane | www.3DLabPrint.com
Z pliers
20
page
