3D LabPrint Douglas DC-3 / C-47 Dakota User Manual page 16

5.2.1 Fuselage assembly Douglas DC-3 / C-47 Dakota
The fuselage is ready for both transport and military variants. Different parts are F2, F3, F5,
F6, F8 and C1 cowling. Glue fuselage parts F1-F5 with CA glue together. The new
3DLabPrint lock system will help you. Do not glue back part F8 before tail and elevator
assembly. Wall thickness should be 0.55-0.67.
For fuselage cover arm use a ball pen spring. Put it to the part 2 and glue with part 1 together.
Video guide Douglas DC-3 / C-47 Dakota fusselage assembly
you will need:
F8
2,8g/0.1oz LW
F7
41,3g/1.46oz LW
F6
27,9g/0.98oz LW
CA Glue - medium +
Snap knife, SandPaper Some cloth for wiping CA glue...
BallPen Spring
10,21g/0.36oz LW
F5
37,4g/1.32oz LW
F4
58g/2.05oz LW
... print your plane | www.3DLabPrint.com
Activator for CA Glue
cover 2
2,6g/0.09oz LW
F3
47,1g/1.66oz LW
16
page
cover lock
cover 1
19,25g/0.68oz LW
F2
24,2g/0.85oz LW
18,6g/0.66oz LW
ball pen spring
F1
