5.2.3 Main landing gear assembly

Complete all printed parts by M3 screws and short 3mm carbon rods. Mount all landing gear
parts to the LG bay as first before glue. Check the functionality of the landing gear assembly
carefully.
Video guide Douglas DC-3 / C-47 Dakota Landing gear assembly
you will need: 4x 67mm of 3 mm carbon rod
1x 46mm of 3 mm carbon rod
2x M3x50mm for axle
4x M3x30mm for side fix
4x M3x14mm
4x M3x10mm
8x 3,2x15mm screws
... print your plane | www.3DLabPrint.com
3mm carbon rod
ball pen spring
gear tyre (pair)
11,6g/0.41oz FLEX
40g retracts
Servoless Electric Retractable Landing
Gear with steering
Dimension: 65.8 x 35.1 x 25.1 mm
Travel:
Voltage:
Shaft:
18
page
main gear disc (pair)
7,6g/0.27oz PLA
2.59 x 1.38 x 1.0 inch
90°
4.8V – 6V
4 mm
