- Page 1 AF14004 ASSEMBLY INSTRUCTIONS HANDY ANDY ASSEMBLY INSTRUCTIONS ALUMINUM FENCE AF14004 60 MIN Want to see a video on how to assemble this product? Scan the QR code WWW.WAMBAMFENCE.COM WWW.WAMBAMFENCE.COM VER. 110822...
- Page 2 AF14004 ASSEMBLY INSTRUCTIONS GENERAL IMPORTANT INFORMATION Check the inside of the larger pieces in your box for other materials packed inside. When assembling components, place on a non-abrasive surface (i.e. shipping box) to avoid scratching. We recommend an area approximately 5’x 8’ for unobstructed assembling.
- Page 3 Joe’s job is to help you perform the task of installing an a-kind and there are many scenarios you could encounter WamBam is available to help you. Please feel free to call us - we’d love to help you out.
- Page 4 REALITY CHECK ROME WASN’T BUILT IN A DAY, AND YOUR FENCE PROBABLY WON’T BE EITHER. Time is your friend when installing your WamBam Fence. So chill out. Relax. Do a yoga pose. Take plenty of breaks. you’re mistaken. Yeah, we know your dog and kids are running loose and your neighbor is...
- Page 5 AF14004 ASSEMBLY INSTRUCTIONS JUST A COUPLE MORE THINGS OTHER STUFF YOU NEED TO KNOW Draw a sketch layout of the proposed fence lines and logically look it over. If it doesn’t make sense on paper, chances are it won’t make sense in your yard. Ask for some help.
- Page 6 AF14004 ASSEMBLY INSTRUCTIONS PITFALLS! HAVE YOU CONTACTED your fence to avoid puncturing any unseen underground YOUR LOCAL UTILITIES? is made easy for you. Simply call 811 in the US or visit www.call811.com. In Canada, visit www.transcanada.com/contactus.html for a list of phone numbers by province. HAVE YOU CHECKED YOUR Local zoning laws and Home Owners Associations may regulate LOCAL ZONING LAWS?
- Page 7 AF14004 ASSEMBLY INSTRUCTIONS TOOLS AND MATERIALS YOU’LL NEED Safety Glasses WamBam Pipe Pounder (Purchase or rent a similar product from Home 2in. x 2in. x 6in. Inch Wood “Spacer” Block Cordless Drill Shovel Toothed Blade String Line Stakes Spool of String...
- Page 8 AF14004 ASSEMBLY INSTRUCTIONS MURPHY’S ALUMINUM FENCE LAWS To get started, we are going to walk you through how you would install the fence illustrated below. work out evenly, the birds are chirping, and the sky is blue. obstacles you could run into while installing your fence and how to overcome them. You can laws WWW.WAMBAMFENCE.COM...
- Page 9 This fence can be trimmed down both in width 86in. 82in. 4.59in. (o.c.) 3.97in. 57.4in. 36in. 54in. Ground 2in. String Line 3in. 84in. Ground Center to Center 42in. WamBam Ornamental Anchor 1.06in. 1.00in. .06in. .65in. Top, Middle, & Bottom Rails WWW.WAMBAMFENCE.COM...
- Page 10 AF14004 ASSEMBLY INSTRUCTIONS MATERIALS STEP 1: Nut and Bolt ( ) Top Rail (1) Stainless Steel 1” x 1” x 81¾” 1” x 1” x 81¾” (42) WWW.WAMBAMFENCE.COM...
- Page 11 AF14004 ASSEMBLY INSTRUCTIONS STEP 2: STEP 2.1 STEP 2.2 Slide the leveling donut over the pipe anchor. surface to leave room for the post. Make sure your level with the ground and not sloped at an angle. STEP 2.3 Use a post pounder to stabilize the pipe anchor in the anchor the ground, please refer to our ‘Mur- WWW.WAMBAMFENCE.COM...
- Page 12 AF14004 ASSEMBLY INSTRUCTIONS STEP 2.4 STEP 2.5 Drive the pipe anchor 42” At 6” intervals, check that the pipe anchor is into the ground. 36” of the level. Pounding the pipe anchor from all four pipe anchor should be above sides will help to achieve this.
- Page 13 AF14004 ASSEMBLY INSTRUCTIONS STEP 4: STEP 4.1 Lay out one of the rails along the string line. STEP 4.2 the end of the rail. Repeat this step for all of your anchor Top View Side View as aluminum will scratch when in contact with rocks, rough dirt, etc.
- Page 14 AF14004 ASSEMBLY INSTRUCTIONS SOIL AND STEP 5: STEP 5.1 (OPTIONAL) buried in the ground, remove about 3” of soil from STEP 5.2 STEP 5.3 included in the post box, through the anchor Adjust your string line to the string line The hex head tek screws are packaged adjust both up and down on the pipe anchor the post.
- Page 15 AF14004 ASSEMBLY INSTRUCTIONS LEVELING DONUTS STEP 6: STEP 6.1 ing tek screws included in the donut packaging. The donut can be level should sit adjusted to compensate for a slightly crooked pipe of the anchor anchor. Slide the donut a level plane between the donut.
- Page 16 AF14004 ASSEMBLY INSTRUCTIONS STEP 7.2 STEP 7.3 self-drilling tek screw Repeat step 7 for all from the post box posts. through the post, anchor anchor. FENCE PANELS STEP 8: STEP 8.1 Insert the Spear Pickets and Flat Top Pickets and align the holes in the pickets with the holes in the rail.
- Page 17 AF14004 ASSEMBLY INSTRUCTIONS STEP 8.2 STEP 8.3 Insert pickets into the other horizontal Insert the pickets into the Top Rail rail and align the holes in the pickets with and align the holes in the pickets with the holes in the horizontal rail. the holes in the top rail.
- Page 18 AF14004 ASSEMBLY INSTRUCTIONS STEP 9: STEP 9.1 STEP 9.2 Using the Rail Bracket (A), measure about stainless steel hex screw. If you force the screws, you will strip them. proper side of the post, through the post itself, and into the pipe anchor inside. 2”...
- Page 19 AF14004 ASSEMBLY INSTRUCTIONS ATTACH PANELS TO POSTS STEP 10: STEP 10.1 Slide the fence panel in between the rail brackets. STEP 10.2 Fasten the fence panel with the bolts and nuts that are packaged with the rail brackets. The posts can be trimmed down if necessary.
- Page 20 AF14004 ASSEMBLY INSTRUCTIONS STEP 10.3 remaining fence panels as shown. WWW.WAMBAMFENCE.COM...
