Printer Overview

Control panel

1 2 3
Feature
1 LCD
2 Copy button
3 Fax button
4 Scan button
5 Navigation buttons
6 Back button
7 OK button
8 Home button
9 Redial button
10 Auto Answer button
11 Phonebook button
2
4 5 6 7 8
Description
Displays pictures, messages, and menus
Displays the Copy Options menu
Lets you enter a phone number for sending a fax, or choose the Fax Options menu
Displays the Scan Options menu
Used to navigate menus, scroll through pictures
Displays the next higher screen in the menu structure
Selects a menu item, accepts a setting, and continues with current operation
Displays the Main Menu
Dials the last dialed phone number
Turns the fax auto answer feature on or off; when on, the fax answers all incoming
calls
Displays the phone book of fax numbers entered on this printer; lets you enter or
edit phone numbers
www.kodak.com/go/aiosupport
9 10 11 12 13 14 15 16 17 18
