KOBE Range Hoods
"So Quiet...You Won't Believe It's On!"
RAX95 SQB-1 Parts Location and Replacement
This basic guide is to show the parts location of the RAX95 SQB-1 and how to remove or install certain parts.
To see more detailed guidelines, please visit:
Kobe Service and Repair
For models (w/ Standard Duct Cover): RAX9530SQB-DC-1, RAX9536SQB-DC-1, RAX9542SQB-DC-1,
RAX9548SQB-DC-1 or RAX9530SQB-1, RAX9536SQB-1, RAX9542SQB-1, RAX9548SQB-1
For models (w/ 24" Duct Extension): RAX9530SQB-DC24-1, RAX9536SQB-DC24-1, RAX9542SQB-DC24-1,
RAX9548SQB-DC-24-1
Overall Snapshot of RAX95 SQB-1
3
3
2
1
Part #8 – See "Parts List" page on manual)
1. Motor
(Manual
Part #s 5 – See "Parts List" page on manual)
2. Knobs
(Manual
Part #3 – See "Parts List" page on manual)
3. LED Light (3W)
(Manual
Page 1 of 5
Version 20160725
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for KOBE RAX95 SQB-1
Summary of Contents for KOBE RAX95 SQB-1
- Page 1 “So Quiet…You Won’t Believe It’s On!” RAX95 SQB-1 Parts Location and Replacement This basic guide is to show the parts location of the RAX95 SQB-1 and how to remove or install certain parts. To see more detailed guidelines, please visit:...
- Page 2 KOBE Range Hoods “So Quiet…You Won’t Believe It’s On!” Removing the Capacitor Panel Warning: Loosen the screw first with a hand tool screw driver. Figure 1 Figure 2 Figure 3 Figure 4 Part #11 – See “Parts List” page on manual) 4.
- Page 3 KOBE Range Hoods “So Quiet…You Won’t Believe It’s On!” Accessing the Capacitor and LED Driver Part #9 – See “Parts List” page on manual) 5. Capacitor (Manual Part #10 – See “Parts List” page on manual) 6. LED Driver (Manual...
- Page 4 KOBE Range Hoods “So Quiet…You Won’t Believe It’s On!” Removing the Control Knobs Figure 1 Figure 2 Figure 3 Figure 4 Accessing the LED Light For a more detailed guideline, visit: How to Replace LED Lights Page 4 of 5...
- Page 5 KOBE Range Hoods “So Quiet…You Won’t Believe It’s On!” Removing the Motor Warning: 1. Loosen the screw first with a hand tool screw driver. 2. Place a support or hold the blower before removing it. Figure 1 Figure 2 Figure 3 Figure 4 Part #8 –...
