- Page 1 KOBE Range Hoods Deluxe Series RA92 SQB-5 Series Model No. RA9230SQB-5 / RA9230SQB-DC30-5 / RA9230SQB-DC46-5 (30”) RA9236SQB-5 / RA9236SQB-DC30-5 / RA9236SQB-DC46-5 (36”) INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
- Page 2 3. Contact your merchant for product replacement due to shipping damages, cosmetic damages or defects. 4. For all other issues, call 1-877-BUY-KOBE (289-5623), or e-mail to info@koberangehoods.com NO RETURN, NO REFUND, NO EXCHANGE IF: 1. PRODUCT HAS BEEN INSTALLED 2.
-
Page 3: Table Of Contents
[ENGLISH] - READ AND SAVE THESE INSTRUCTIONS - CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..................1 COMPONENTS OF PACKAGE....................3 INSTALLATION .......................... 4 OPERATING INSTRUCTIONS....................7 MAINTENANCE ......................... 9 SPECIFICATIONS ........................10 MEASUREMENTS & DIAGRAMS .....................11 PARTS LIST ..........................13 CIRCUIT DIAGRAM ........................14 TROUBLE SHOOTING ......................15 WARRANTY ..........................16 WARRANTY INFORMATION FORM ..................18 - READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING -... -
Page 4: Important Safety Instructions
KOBE RANGE HOODS authorized agents will automatically void the warranty. KOBE RANGE HOODS will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood. - Page 5 What to Do In The Event Of a Range Top Grease Fire • SMOTHER FLAMES with a tight fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
-
Page 6: Components Of Package
(Must keep all material for returns or refunds) RA92 SQB-5 Series Range Hood Box {A} KOBE Range Hood (with RA092DC-1) {B} Warranty Registration Card {C} Quick Reference Guide 3/16” x 3/8” (6 PCS) {D} Baffle Filter x 2 (30” hood) Wire caps (3) x 3 (36”... -
Page 7: Installation
INSTALLATION PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING Calculation before Installation To calculate installation, please refer to TABLE 1. (All calculation in inches.) TABLE 1 A = Height of Floor to Ceiling B = Height of Floor to Counter Top (Standard: 36") C = Preferred Height of Counter Top to Hood Bottom (Minimum 26"... - Page 8 Preparation before Installation Figure 1 NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING THE VENT OPENING. Decide the location of the venting pipe from the hood to the outside. Refer to Figure 1. A straight, short venting run will allow the hood to perform more efficiently.
- Page 9 Figure 4 Wiring to Power Supply THIS RANGE HOOD MUST BE PROPERLY GROUNDED. MAKE SURE THIS IS DONE BY QUALIFIED ELECTRICIAN IN ACCORDANCE WITH ALL APPLICABLE NATIONAL AND LOCAL ELECTRICAL CODES. BEFORE CONNECTING WIRES, SWITCH POWER OFF AT SERVICE PANEL AND LOCK SERVICE PANEL TO PREVENT POWER FROM BEING SWITCHED ON ACCIDENTALLY.
-
Page 10: Operating Instructions
OPERATING INSTRUCTIONS Note: For best results, turn fan on prior to any preparation or cooking and keep fans running while cooking. Adjust speed as needed. Power Control Press Power Control to turn On/Off the range hood. Speed Control The fan will start on Speed #3. Press button to decrease the speed level.Press button to increase the speed level. - Page 11 ECO Mode can be activated while fan is running or off. Press and hold button until icon briefly appears in the LED Display. While fan is running you can change the speed, use delay shutoff or turn off fan without disabling ECO Mode. When fan is off and ECO Mode has been activated, the icon will appear in the LED Display.
-
Page 12: Maintenance
MAINTENANCE For optimal performance, clean the range hood surface and baffles regularly. To Clean Hood Surface CAUTION: NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. *** Regular care will help preserve its fine appearance. 1. Use only mild soap or detergent solutions. Dry surfaces using soft cloth. 2. -
Page 13: Specifications
SPECIFICATIONS MODEL / SIZE For 30” model For 36” model RA9230SQB-5 RA9236SQB-5 RA9230SQB-DC30-5 RA9236SQB-DC30-5 RA9230SQB-DC46-5 RA9236SQB-DC46-5 COLOR 18-Gauge Commercial Grade Stainless Steel CONSUMPTION / AMPERE 300W / 2.5A NUMBER OF BLOWER DESIGN Seamless / Satin Finish BLOWER TYPE Single Horizontal Squirrel Cage EXHAUST Top 6”... -
Page 14: Measurements & Diagrams
MEASUREMENTS & DIAGRAMS *** All inch measurements are converted from millimeters. Inch measurements are estimated. *** All measurements in ( ) are millimeters. MODEL NO.: RA9230SQB-5 (30”) RA9236SQB-5 (36”) - Page 15 MODEL NO.: RA9230SQB-DC30-5 (30”) RA9236SQB-DC30-5 (36”) Extension Duct Cover Model: RA0930DC * For the diagram of hood dimension, please refer to Page 11. MODEL NO.: RA9230SQB-DC46-5 (30”) RA9236SQB-DC46-5 (36”) Extension Duct Cover Model: RA0946DC * For the diagram of hood dimension, please refer to Page 11.
-
Page 16: Parts List
PARTS LIST MODEL NO.: RA9230SQB-5 / RA9230SQB-DC30-5 / RA9230SQB-DC46-5 (30”) RA9236SQB-5 / RA9236SQB-DC30-5 / RA9236SQB-DC46-5 (36”) DESCRIPTION MODEL /SIZE PART NO. Duct Cover-Mounting Bracket L1-0203-0092 Duct Cover RA092DC-1 12-09200-61 6” Round Plastic Exhaust L1-0505-0003 LED Light (3W) L1-0403-0301 Control Panel L1-0404-6001-A Control Panel Support L1-0207-1630... -
Page 17: Circuit Diagram
CIRCUIT DIAGRAM MODEL NO.: RA9230SQB-5 / RA9230SQB-DC30-5 / RA9230SQB-DC46-5 (30”) RA9236SQB-5 / RA9236SQB-DC30-5 / RA9236SQB-DC46-5 (36”) -
Page 18: Trouble Shooting
TROUBLE SHOOTING Issue Possible Cause Solution After The power is not on. Make sure the circuit breaker and the Installation, unit’s power is ON. Use a voltage meter both motors to check the power supply. and lights are The wire connection is not secure. Check and tighten wire connection. -
Page 19: Warranty
ONE-YEAR LIMITED LABOR WARRANTY ON KOBE DELUXE SERIES: For one year from the date of your original invoice from a KOBE authorized dealer, we will repair any parts or components free of charge that failed due to manufacturing defects. KOBE reserves the right to replace, rather than repair the product free of charge at our sole discretion. - Page 20 TO REQUEST WARRANTY SERVICE, PLEASE CONTACT KOBE RANGE HOODS SERVICE CENTER: From the 48 contiguous states:...
-
Page 21: Warranty Information Form
1. Date of purchase 2. Model No. 3. Serial No. For warranty service or spare parts purchase contact: KOBE Service Center (USA ONLY) Toll Free: 1-877-BUY-KOBE (289-5623) Email: customer.service@koberangehoods.com For service in Canada and to report a problem, please... - Page 22 Arcadia, CA 91006 USA www.koberangehoods.com This KOBE hood is made for use in the USA and CANADA only. We do not recommend using this hood overseas as the power supply may not be compatible and may violate the electrical code of that country. Using a KOBE hood overseas is at your own risk and will void your warranty.
