Summary of Contents for Duke FLEXBAKE 5

Page 1 CAUTION: Please read this manual completely before attempting to install, operate or service this equipment This manual is Copyright © 2018 Duke Manufacturing Co. All rights reserved. Reproduction without written permission is prohibited. Duke is a registered P/N 514154 trademark of the Duke Manufacturing Co.
Page 2: Table Of Contents
Owner's Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity TABLE OF CONTENTS Important Safety Instructions ..................... 3 Introduction ............................6 Specifications ............................ 7 Installation ............................11 Operating Instructions ........................16 Care and Cleaning .........................19 Door Adjustment & Gasket Maintenance ................20 Lamp Bulb Replacement ......................24...
Page 3: Important Safety Instructions
• Do not operate this equipment if it has a damaged cord or plug, if it is not working properly, or if it has been damaged or dropped. • This equipment shall be serviced by qualified personnel only. Contact the nearest Duke authorized service facility for adjustment or repair.
Page 4 • Keep cord away from heated surfaces. • If the supply cord is damaged, it must be replaced by a special cord assembly available from Duke Manufacturing Co. or its service agent. Note: Refer to the specifications data plate when ordering or replacing a cord set.
Page 5 Owner’s Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity IMPORTANT SAFETY INSTRUCTIONS - continued The following warnings and cautions appear throughout this manual and shall be carefully observed. • Turn the unit off, disconnect the power source and allow unit to cool down before performing any service or maintenance on the unit.
Page 6: Introduction
For more information on this oven, including Operations Training, as well as your other Duke products, scan the QR code on the right or visit our website: https://www.dukemfg.com/subway For more information on utilizing the wifi technology on this oven, scan the QR code on the right or visit: https://connected.dukemfg.com/Subway...
Page 7: Specifications
Owner’s Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity SPECIFICATIONS Patent Pending Unit Weight: Oven and Stand 550 lbs / 250 kg Model 5R-DBPS Shipping Weight: Carton Box 600 lbs / 272 kg Optional Cart: 67 lbs / 30 kg...
Page 8 Owner's Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity DOMESTIC UNIT...
Page 9 Owner’s Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity CE UNIT...
Page 10 Owner's Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity MAIN FEATURES...
Page 11: Installation
Owner’s Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity INSTALLATION UNPACKING UNIT WARNING Inspect the shipping carton and/or container, carefully noting any exterior damage on the delivery receipt; also note any ELECTRICAL SHOCK HAZARD UNIT damage not evident on the outside of the shipping container (concealed damage).
Page 12 STEP 2. Push the 1/4” prevent stress under pull. (6.35mm) ID x 3/8” (9.53mm) OD tubing fully Contact Duke for service of IVS (Integrated Ventilation System) onto the open barb on the supply interconnection. ‘T’ fitting. EXTERNAL EQUIPOTENTIAL Terminal provides a connection for bonding to equipment enclosure.
Page 13 Duke Manufacturing approved service Direction section of this manual. personnel. Call Duke Service Department for action if electrical rating tag information is not compatible with the available STEP 6 Check the door seal and make sure both doors close mains supply.
Page 14 Bake Oven to a potable water supply before making any plumbing connections. Plumbing code requirements vary, but European Union (CE) and other jurisdictions require a backflow prevention device that is factory-installed or available as a kit (P/N 600187). The backflow prevention device used on Duke Flexbake 5 Proof and Bake Oven protects water supply systems by preventing the reverse flow of non-potable water into the potable domestic water system.
Page 15 STEP 5 Check the door seal and make sure the door closes completely. STEP 6 If the unit does not power up correctly or if the door does not close and seal properly, call Duke for assistance. AUDIBLE ALARMS The Proof and Bake has various audible alarms.
Page 16: Operating Instructions
Owner's Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity OPERATING INSTRUCTIONS Oven/Proofer Start-Up Turn ON the Duke Flexbake 5 Control Power Switch Boot Screen Automatically Transitions to Baking Main Screen Main Screen Recipe Name Touch to turn on...
Page 17 30 minutes. An audible alarm will sound (3 short chirps) when the oven reaches the ready state. Your Duke Flexbake 5 Proof and Bake Oven is now ready to operate.
Page 18 Owner's Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity OPERATING INSTRUCTIONS - continued STEP 3 Once the preheat or conditioning cycle is complete, STEP 6 If a bake with cheese recipe was selected, at 2:00 the display will change to the Oven Recipe Ready to Start minutes remaining in the proof cycle an alarm will beep (triple screen.
Page 19: Care And Cleaning
Owner’s Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity OPERATING INSTRUCTIONS - continued BAKING TIPS • Always select the oven recipe and allow preheat time prior to loading product. Only load when the Oven Recipe Ready to Start Timers screen is displayed.
Page 20: Door Adjustment & Gasket Maintenance
Owner's Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity DOOR ADJUSTMENT & GASKET MAINTENANCE REVERSING OVEN DOOR SWING DIRECTION Step 3. Remove the six pan head screws on the front of the WARNING oven to expose the hinge screw holes for the other swing Note: Reversing oven door requires two (2) direction (Fig.
Page 21 Owner’s Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity DOOR ADJUSTMENT & GASKET MAINTENANCE -cont. Step 7. Remove the 2 screws securing the door latch plastic FIG 8 housing cover. Remove the 1 screw securing the tab for supporting the plastic housing cover.
Page 22 Step 4 Refer to Figure: Gasket Check in this section to check the gasket for leaks. Also, check that the new gasket is not compressed too much, making the door hard to close. Call Duke Service for assistance if the gasket does not seal properly. Figure: Door and Gasket...
Page 23 Owner’s Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity DOOR ADJUSTMENT & GASKET MAINTENANCE -cont. COOL-TOUCH DOOR INFORMATION AND CLEANING INSTRUCTIONS The Cool-Touch door has two window panes. The inner window Step 3 Cool-Touch Door bottom easily swings open for can be easily separated from the outer window for cleaning.
Page 24: Lamp Bulb Replacement
Owner's Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity LAMP BULB REPLACEMENT BULB MOUNTING DETAILS Turn counter-clockwise. Lamp Holder Remove bulb cover. Assy. G4 12V 10W (Max.) Lamp Flat Lens Gasket - 12V Halogen 58mm Lens 58mm...
Page 25: Programming Controls
Owner’s Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity PROGRAMMING CONTROLS To access the SPECIAL FUNCTIONS, touch button on the Main Tool Bar. Figure: Main Tool Bar Figure: Stage Edit Selection Screen Step 3 Touch the stage you want to edit (STAGE 1).
Page 26 Owner's Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity PROGRAMMING CONTROLS - continued NOTE: To add a new recipe, touch a ‘Blank’ button. To add a • Touch the parameter you want to change (Stage Time, stage to a new or existing recipe, touch the next consecutive Temperature, etc.).
Page 27 Owner’s Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity PROGRAMMING CONTROLS - continued USER (USER DOCUMENTS) Step 4 To edit the recipe name, touch the button for the EDIT RECIPE NAME screen. NOTE: Typing will add letters/characters to the end of the Step 1 Touch the button.
Page 28 Owner's Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity PROGRAMMING CONTROLS - continued CONFIG (CONFIGURATIONS) Step 1 Touch the button and then enter pin code 2 3 4 5 and Touch the button when prompted. Step 2 Touch the button for the setting you want to edit.
Page 29: Network Configuration And Connected Operation
Scan the QR code to the right or visit the website: https://connected.dukemfg.com/Subway NETWORK REQUIREMENTS Duke FlexBake 5 (FB5) utilizes an internet connection to offer the following features: • Remote recipe updates •...
Page 30 Internet Content, we request that you If ETHERNET is selected, “SAVE” button sets whitelist traffic to the following URL for access to the Duke Ethernet and DHCP mode. Note: ADVANCED will allow setting of static IP. Connected Equipment Platform.
Page 31 Owner’s Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity NETWORK CONFIGURATION - cont. Selecting “SAVE” will set unit to Wireless DHCP mode and attempt to connect. Note: ADVANCED will allow setting of static IP. Figure: Network FBFIVE...
Page 32 • Connected to Router - Confirmed oven connection to in store router • Connected to Duke - Confirmed oven connection to the Figure: IP Configuration cloud Duke Connected Equipment Platform CREATE ACCOUNT AND/OR REGISTER Scan the QR code below or visit the website: https://connected.dukemfg.com/Subway...
Page 33 Owner’s Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity CONNECTED OPERATION AND AVAILABLE FEATURES - continued Step 3 Individual recipes can be edited by selecting EDIT on the specific recipe you wish to change. Edit the desired param- eters and select SAVE when complete.
Page 34 .json recipe file, select Choose File, browse to the file’s folder location and select the recipe file. NOTE: This must be an exported .json file from the Duke Connected Equipment Platform Web App. Once it is selected, the file name will be displayed on the Web App adjacent to the Choose File button.
Page 35 Owner’s Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity CONNECTED OPERATION AND AVAILABLE FEATURES - continued VIEWING OVEN STATUS, USAGE DATA, USAGE VIEWER – This page displays a time based event usage view, including Event Time, Event group, and Events (occurred AND DIAGNOSTICS within the Event group).
Page 36 Owner's Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity CONNECTED OPERATION AND AVAILABLE FEATURES - continued RECIPE USAGE – This page, similar to the Usage Data, displays DIAGNOSTICS – This page displays the diagnostic fault status the ovens total recipe counts by Recipe Name in a usage table of all monitored components and performance.
Page 37 When the unit is online, it will compare its current loaded version to the latest version available via the Duke CEP. If it is an older version, the update will be pushed to the unit and saved in local memory ensuring no disruption to the unit or store operations.
Page 38: Fb5 Network Trouble Shooting (Faq)
STATUS to view connectivity status. iv. For cloud connectivity to the Duke Connected Equipment Platform, you can go to the Special Functions USER menu and select NETWORK STATUS to view connectivity status. Alternatively, on the FB5 main screen there is an always...
Page 39 Typically, an I.T. group at your location would give you a static IP address to use. If you do not have an I.T. group, you may have to work with your franchisee’s outside I.T. vendor. 10. How do I set a static IP address on the FlexBake 5? Go to the Special Functions CONFIG menu and select NETWORK CONFIG. Select your type of connection (WIRELESS or ETHERNET) and then select ADVANCED.
Page 40 Check for any fault messages on the unit. (e.g. CAN ACM Connection Lost) d. If you are connected to the in store router but you cannot establish connection to the Duke Connected Equipment Platform, your internet service might be down. On another connected device to the same network, check to see if you can browse to an internet site.
Page 41: Troubleshooting
Owner’s Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity TROUBLESHOOTING Problem 1. Touch Screen Control display is not a. Is the control panel power Go to “b”. Turn on switch. switch ON b. Is the main circuit breaker Reset Circuit Breaker.
Page 42: Wire Diagram
Owner's Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity WIRING DIAGRAM FOR QUALIFIED SERVICE TECHNICIAN OR ELECTRICIAN ONLY V-Detect PCB WiFi Antenna Current Sense Ethernet Front Control Panel Sw 1 Sw 2 Sw 1 Sw 2...
Page 43 Owner’s Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity...
Page 44 Owner's Manual for Duke Flexbake 5 Proof and Bake Oven with WiFi Connectivity Duke Manufacturing Co. Phone: 314-231-1130 Toll Free: 1-800-735-3853 2305 N. Broadway www.dukemfg.com Fax: 314-231-5074 St. Louis, MO 63102...
