FRY HOLDING UNIT AIR SCROLL
(FHUAS)
Patent(s) Pending
MODELS
FHUAS-2
IMPORTANT INFORMATION, READ BEFORE USE.
This manual is Copyright © 2017 Duke Manufacturing Company. All rights reserved.
Reproduction without written permission is prohibited. Duke is a registered
PLEASE SAVE THESE INSTRUCTIONS.
trademark of the Duke Manufacturing Company.
Duke Manufacturing Company
2305 N. Broadway
St. Louis, MO 63102
Phone: 314-231-1130
Toll Free: 1-800-735-3853
Fax: 314-231-5074
www.dukemfg.com
OWNER'S MANUAL
P/N 229668K
03/08/2017
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Duke FHUAS-2
Summary of Contents for Duke FHUAS-2
- Page 1 FHUAS-2 IMPORTANT INFORMATION, READ BEFORE USE. PLEASE SAVE THESE INSTRUCTIONS. This manual is Copyright © 2017 Duke Manufacturing Company. All rights reserved. Reproduction without written permission is prohibited. Duke is a registered trademark of the Duke Manufacturing Company. Duke Manufacturing Company 2305 N.
- Page 2 Owner's Manual for Fry Holding Unit Air Scroll (FHUAS)
-
Page 3: Table Of Contents
Owner's Manual for Fry Holding Unit Air Scroll (FHUAS) TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ................4 SPECIFICATIONS .......................6 MAIN FEATURES ........................8 INSTALLATION ........................9 ACCESSORY LAYOUT .......................12 Add On options ........................13 OPERATION INSTRUCTIONS ....................14 SURFACE TEMPERATURE CHECK ..................14 CARE AND CLEANING .......................15 TROUBLESHOOTING ......................17 REPLACEMENT PARTS LIST ....................18 WIRING DIAGRAM ......................19... -
Page 4: Important Safety Instructions
Do not use corrosive chemicals, water jet equipment, or other pressurized liquid spraying equipment to clean this unit. ELECTRICAL HAZARD! • This equipment should be serviced by qualified personnel only. Contact the nearest Duke authorized service facility for adjustment or repair. •... - Page 5 Owner's Manual for Fry Holding Unit Air Scroll (FHUAS) IMPORTANT SAFETY INSTRUCTIONS (continued) • Properly rated all poles mains protection and earthing compliance with local electric codes are required for safe operation of this unit. • Disposal of the unit must be in accordance with local environmental codes and/or any other applicable codes.
-
Page 6: Specifications
Configuration Line Current Configuration Amps (A) Single Phase NEMA 5-20P(2EA) NOTE: Duke fry hold station is supplied with (2) 6’ cords with NEMA 5-20 plugs. Customer must provide approved receptacles for equipment. 32" 34" 36" NOTE: MARKS FOR FHUAS 34"... - Page 7 Line Current Configuration Amps (A) Single Phase NEMA 5-20P(2EA) NOTE: Duke fry hold station is supplied with (2) 6’ cords with NEMA 5-20 plugs. Customer must provide approved receptacles for equipment. 32 1/8" NOTE: MARKS FOR FHUAS 36" COMMERCIAL COOKING APPLIANCE 8 1/8"...
-
Page 8: Main Features
Owner's Manual for Fry Holding Unit Air Scroll (FHUAS) MAIN FEATURES FRY BASKET WITH "AIR SCROLL" TECHNOLOGY RETURN PLENUM PLATE, REMOVABLE FOR CLEANING FRY BASKET WITH "AIR SCROLL" TECHNOLOGY AIR INTAKE FILTER, REMOVABLE FOR CLEANING GREASE CATCH PAN, REMOVABLE FOR CLEANING RETURN PLENUM PLATE, REMOVABLE FOR CLEANING... -
Page 9: Installation
Owner's Manual for Fry Holding Unit Air Scroll (FHUAS) INSTALLATION UNPACKING UNIT UNIT PLACEMENT – BASE MOUNTED MODEL Inspect the shipping carton and/or container, • Do not block any louvers on the appliance. carefully noting any exterior damage on the delivery For best results locate the unit in ambient air receipt;... - Page 10 Owner's Manual for Fry Holding Unit Air Scroll (FHUAS) PHU SHELF INSTALLATION – TELESCOPING OPTION 1. *Important – Keep support block in place under shelf during the install process to prevent damage. 2. Once the Fry Station and Burger Expedite counters are in place and leveled, the telescoping shelf installation can be completed.
- Page 11 Owner's Manual for Fry Holding Unit Air Scroll (FHUAS) TRANSITION PIECE/SPLASH GUARD INSTALLATION WARNING 1. To be used as a splash guard to prevent fry ELECTRICAL SHOCK HAZARD UNIT MUST BE SAFETY GROUNDED, oil from falling in between fryer and fry station EARTHED.
-
Page 12: Accessory Layout
Owner's Manual for Fry Holding Unit Air Scroll (FHUAS) ACCESSORY LAYOUT TELESCOPING SHELF OPTION ADJSUTS IN LENGTH TICKET MOUNTS TO FRY HOOD RAIL FULL LENGTH FRY RIBBON FRY BASKET DIVIDERS FRY PACKAGING HOLDER W/ MOVABLE DIVIDERS CONDIMENT HOLDER W/ MOVABLE DIVIDERS FRY RIBBON INSERT USE TAB TO ALIGN... -
Page 13: Add On Options
Owner's Manual for Fry Holding Unit Air Scroll (FHUAS) ADD ON OPTIONS OPTIONAL BLACK PAINT GRIP PANEL & SHELVING OPTIONAL UNDERSHELF PART # E050781 PART # E050711 30" SHELF OPTION STAND ALONE OPTION Only Available on 36” Model LEFT HAND PYLON SHOWN RIGHT HAND PYLON SHOWN LEFT HAND PYLON SHOWN RIGHT HAND PYLON SHOWN... -
Page 14: Operation Instructions
Owner's Manual for Fry Holding Unit Air Scroll (FHUAS) OPERATION INSTRUCTIONS The information in this section is intended for the use of qualified operating personnel. Qualified operating personnel are those individuals who have carefully read the information contained in this manual, are familiar with the function of the Fry Holding Unit and/or have had experience with operating the equipment described. -
Page 15: Care And Cleaning
Owner's Manual for Fry Holding Unit Air Scroll (FHUAS) CARE AND CLEANING FHUAS-2 CAUTION Electrical shock hazard: Do not wash with water jet or hose. CAUTION Do not use oven cleaners, caustic cleaners, degreasers, acids, ammonia products, abrasive cleaners, steel wool, or abrasive pads containing iron. These can damage the stainless steel and plastic surfaces. - Page 16 Owner's Manual for Fry Holding Unit Air Scroll (FHUAS) Remove Collection Pan and Wipe any debris build clean in three compartment sink. up that has accumulated behind the removable filter. CAUTION: This area may be hot. Wipe down the front louvered Insert Collection Pan after Wipe out all crumbs and debris.
-
Page 17: Troubleshooting
Owner's Manual for Fry Holding Unit Air Scroll (FHUAS) TROUBLESHOOTING FHUAS Troubleshooting Power Flowchart Main Power Verify plugged into Contact Service: Switch ON and outlet. If yes then Faulty On / Off lights up in ( I ) Observation check panel circuit Switch, Wiring position ? breaker, if no plug in. -
Page 18: Replacement Parts List
Owner's Manual for Fry Holding Unit Air Scroll (FHUAS) REPLACEMENT PARTS LIST Qty Per Unit Locator Description 32 & 34 414070 PAN, COLLECTION, REPLACEMENT 413720 PAN, COLLECTION, REPLACEMENT 414071 PLATE, PLENUM, RETURN, REPLACEMENT 413721 PLATE, PLENUM, RETURN, REPLACEMENT 413714 REPLACEMENT DIVIDER, SLOTTED 414072 BASKET WITH TAB, SLOT 413722... -
Page 19: Wiring Diagram
Owner's Manual for Fry Holding Unit Air Scroll (FHUAS) WIRING DIAGRAM Wire Diagram FHUAS2 229014 Rev. B 03-08-17 RIGHT SIDE Power Switch RELAY Rear Mains Terminal Block 120V COM2 COIL N.0.2 COM1 COM2 COM1 OPTION: V–BUCK PCB N.0.2 N.0.1 N.0.1 Calrod Heating Element Motor Terminal... - Page 20 Owner's Manual for Fry Holding Unit Air Scroll (FHUAS) Duke Manufacturing Co. 2305 N. Broadway St. Louis, MO 63102 Phone: 314-231-1130 Toll Free: 1-800-735-3853 Fax: 314-231-5074 www.dukemfg.com...
