7
Specifications
7.2 Electrical Specifications
Measurement rate
Input impedance
AC bandwidth
AC response
Crest Factor
50/60 Hz
Supplied
Thermocouple
Non-Contact Voltage
(NCV) response
Peak detector
Fuse
#NAS100174; r. AA/97578/97616; en-US
3 readings per second, nominal
10 MΩ (Voltage AC/DC)
50 to 1000 Hz (AC voltage); 50/60 Hz (AC current)
True RMS (AC voltage and current)
3.0 in 60 A and 600 A ranges
1.4 in 1000 A range
Specified for 5% to 100% of range
Type K; rated 482℉ (250℃) maximum
100 to 600 V AC
> 1 ms
200 mA, 600 V ceramic fast blow, 5 x 20 mm
29
