Operation

6. The diode or junction can be evaluated as follows.

If one reading is 0.400 V to 0.800 V, and the other reading is OL, then the

diode is good.

If both readings are OL the device is bad (open).

If both readings are very low or zero, the device is bad (shorted).

#NAS100174; r. AA/97578/97616; en-US
