- Page 1 PIT si1.2 Control and signal devices Operating Manual21039EN03...
- Page 2 Preface This document is the original document. All rights to this documentation are reserved by Pilz GmbH & Co. KG. Copies may be made for internal purposes. Suggestions and comments for improving this documentation will be gratefully received. Pilz®, PIT®, PMI®, PNOZ®, Primo®, PSEN®, PSS®, PVIS®, SafetyBUS p®, SafetyEYE®, SafetyNET p®, the spirit of safety® are registered and protected trademarks of Pilz GmbH & Co. KG in some countries. SD means Secure Digital...
-
Page 3: Table Of Contents
Content Introduction Validity of documentation Using the documentation Definition of symbols Safety Intended use Safety regulations Use of qualified personnel Warranty and liability Disposal Unit features Function description Installation and wiring Wiring Installation Connection examples Driven via PNOZmulti Driven via PSSuniversal Dimensions Technical details Order reference EC declaration of conformity Operating Manual PIT si1.2 21039EN03... -
Page 4: Introduction
PIT si1.2 Introduction Validity of documentation This documentation is valid for the product PIT si1.2. It is valid until new documentation is published. This operating manual explains the function and operation, describes the installation and provides guidelines on how to connect the product. Using the documentation This document is intended for instruction. Only install and commission the product if you have read and understood this document. The document should be retained for future ref erence. Definition of symbols Information that is particularly important is identified as follows: DANGER! This warning must be heeded! It warns of a hazardous situation that poses an immediate threat of serious injury and death and indicates preventive measures that can be taken. WARNING! This warning must be heeded! It warns of a hazardous situation that could lead to serious injury and death and indicates preventive measures that can be taken. CAUTION! This refers to a hazard that can lead to a less serious or minor injury plus material damage, and also provides information on preventive measures that can be taken. NOTICE This describes a situation in which the product or devices could be dam aged and also provides information on preventive measures that can be taken. It also highlights areas within the text that are of particular import ance. Operating Manual PIT si1.2 21039EN03... -
Page 5: Safety
PIT si1.2 INFORMATION This gives advice on applications and provides information on special fea tures. Safety Intended use The muting lamp is intended for use as an indicator in muting mode. If the function of the lamp is monitored by an evaluation device that meets PL e (Cat. 4) of EN ISO 138491 and the necessary circuit measures are taken into account, the muting lamp can also be used up to PL e (Cat. 4). Permissible evaluation devices are: The modular safety system PNOZmulti (for application example see technical catalogue PNOZmulti) Programmable safety systems in the PSS range Programmable safety systems in the PSS range with SafetyBUS p connection The following is deemed improper use in particular: Any component, technical or electrical modification to the product Use of the product outside the areas described in this manual Use of the product outside the technical details (see chapter entitled "Technical De tails"). Safety regulations Use of qualified personnel The products may only be assembled, installed, programmed, commissioned, operated, maintained and decommissioned by competent persons. A competent person is someone who, because of their training, experience and current pro fessional activity, has the specialist knowledge required to test, assess and operate the work equipment, devices, systems, plant and machinery in accordance with the general standards and guidelines for safety technology. It is the company’s responsibility only to employ personnel who: Are familiar with the basic regulations concerning health and safety / accident preven tion Have read and understood the information provided in this description under "Safety" And have a good knowledge of the generic and specialist standards applicable to the specific application. Operating Manual PIT si1.2 21039EN03... -
Page 6: Warranty And Liability
PIT si1.2 Warranty and liability All claims to warranty and liability will be rendered invalid if The product was used contrary to the purpose for which it is intended Damage can be attributed to not having followed the guidelines in the manual Operating personnel are not suitably qualified Any type of modification has been made (e.g. exchanging components on the PCB boards, soldering work etc.). Disposal When decommissioning, please comply with local regulations regarding the disposal of electronic devices (e.g. Electrical and Electronic Equipment Act). Unit features Muting lamp in accordance with EN 61496 2 semiconductor outputs for function monitoring Scope of supply: – Muting lamp including bulb – Mounting bracket – 2 screws Function description In muting mode, the operator must be made aware of the hazard that results from the sus pension of the safety function. The muting lamp is designed for this purpose. It illuminates as soon as muting mode is started. Two semiconductor outputs enable the function of the lamp to be monitored. Normal mode: If the lamp is not operated, both outputs are low. If the lamp is operated and illuminated (muting mode active), both outputs are high. Error during operation If an error occurs or the lamp is faulty, at least one of the two output signals changes to low. Recommendation: To increase the availability of the plant, you can use a second muting lamp. If one of the muting lamps fails (e. g. faulty bulb), the second muting lamp takes over its function. Operating Manual PIT si1.2 21039EN03... -
Page 7: Installation And Wiring
PIT si1.2 Installation and wiring The cover must be taken off and the bulb removed for installation and wiring: Turn the cover to the right and pull it off upwards. While applying slight downward pressure, rotate the bulb by approx. 90° to the right and pull it out. Fig.: Take off the cover and remove the bulb Wiring CAUTION! Wire the lamp when it is isolated from the power supply. Perforate the stuffing box using a screwdriver. Connect the supply voltage and the input signal that signals muting mode to the 3pole terminal. Depending on the category required, connect one or both semiconductor outputs to an evaluation device. 6 cores Fig.: Wiring Operating Manual PIT si1.2 21039EN03... -
Page 8: Installation
PIT si1.2 Installation CAUTION! The muting lamp must be mounted upright. Install the base directly on a horizontal surface or on the fastening bracket using the two screws supplied. Install the fastening bracket with the base on a vertical surface. Fig.: Installation Refit the bulb and the cover. To ensure that no dirt enters the housing, the cover must be securely locked to the base. Rotate the cover to the left until the lug on the cover en gages behind the lug on the base. Fig.: Fit the bulb and lock the cover Operating Manual PIT si1.2 21039EN03... -
Page 9: Connection Examples
PIT si1.2 If it is necessary to open the cover again, e.g. to replace the bulb, press down the strip un derneath the lug using a screwdriver. In this way the cover is unlocked and can be opened by rotating. Fig.: Reopen cover Connection examples Driven via PNOZmulti /1.a.5 CHIP-Card PIT si1.2 24VDC +24V Dual-channel operation PNOZ m1p Open circuit monitoring Monitoring of shorts across contacts Fig.: Driven via PNOZ m1p Operating Manual PIT si1.2 21039EN03... -
Page 10: Driven Via Pssuniversal
Periphery Supply Supply +24V +24V +24V +24V 312 010 312 190 312 200 312 210 SB ADDRESS PIT si1.2 24VDC +24V Dual-channel operation SafetyBUS p Open circuit monitoring Monitoring of shorts across contacts PSSu BS PSSu BP PSSu BP 1/8S... -
Page 11: Technical Details
PIT si1.2 Technical details General Approvals CE, TÜV, cULus Listed Selfmonitored Lamp Kind bulb Type BA15d, 24 V DC, 7W Electrical life 1,000 hours Electrical data Supply voltage Voltage 24,0 V Kind Voltage tolerance 15 %/+15 % Output of external power supply (DC) 7,0 W Residual ripple DC 5 % Continuous duty 100 % Semiconductor outputs Number Current 100 mA Short circuitproof Relay outputs Contact fuse protection external, safety contacts Blowout fuse, quick 0,5 A Times Reaction time In operation and with broken bulb filament 1 5 ms When fuse is triggered and with short circuit cur rent ≥; 4 A < 300 ms Environmental data... -
Page 12: Order Reference
PIT si1.2 Mechanical data Dimensions Height 138,5 mm Diameter of pushbutton 100,0 mm Weight 218 g Where standards are undated, the 201304 latest editions shall apply. Order reference Product type Features Order no. PIT si1.2 muting lamp self Signal lamp for muting mode with self monitoring 620 020 monitoring EC declaration of conformity This product/these products meet the requirements of the directive 2004/108/EC for ma chinery of the European Parliament and of the Council. The complete EC Declaration of Conformity is available on the Internet at www.pilz.com/downloads. Representative: Norbert Fröhlich, Pilz GmbH & Co. KG, FelixWankelStr. 2, 73760 Ost fildern, Germany Operating Manual PIT si1.2 21039EN03... - Page 13 Back cover Support Technical support is available from Pilz round the clock. Americas Australia Scandinavia Brazil +61 3 95446300 +45 74436332 +55 11 97569-2804 Spain Canada Europe +34 938497433 Switzerland +1 888-315-PILZ (315-7459) Austria +43 1 7986263-0 +41 62 88979-30 Mexico...
