Summary of Contents for Briteq BTI-LIGHTSTRIKE IP66
-
Page 3: Before Use
• Besides the standard DMX with RDM support, there is also full support for Art-net and sACN allowing large sets to be built up and controlled quickly and efficiently. • The BTI-LIGHTSTRIKE IP66 is very compact and has a low weight which allows it to be quickly incorporated into all kinds of scenery. -
Page 4: Safety Instructions
• Due to safety reasons it is prohibited to make unauthorized modifications to the unit. Important: Never look directly into the light source! Don’t use the effect in the presence of persons suffering from epilepsy. BRITEQ 2/26 BTI-LIGHTSTRIKE IP66 ®... - Page 5 10. COUPLER MECHANISM: the coupler mechanism makes it possible to quickly connect and align two or a long line of projectors together. Please proceed as described. BRITEQ 3/26 BTI-LIGHTSTRIKE IP66 ®...
-
Page 6: Overhead Rigging
• The operator has to make sure that the safety-relating and machine-technical installations are approved by an expert before using them for the first time. The installations should be inspected every year by a skilled person to be sure that safety is still optimal. BRITEQ 4/26 BTI-LIGHTSTRIKE IP66 ®... -
Page 7: Setup Menu
+ max LED temp. Fan State xxxx shows actual rotation speed Firmware Version RDM UID xxxxxx Fixture Errors Error Logs Reset Error Log confirm with password (= 050) No/Yes Special Functions Factory Restore No/Yes BRITEQ 5/26 BTI-LIGHTSTRIKE IP66 ®... -
Page 8: Dmx Address
• Press the ▼/▲ buttons to browse the menu until the required function shows up. • Press the ENTER button: you can monitor the incoming DMX-signal, functions and values are displayed. • Press the ▼/▲ buttons to select the channel that you want to monitor. BRITEQ 6/26 BTI-LIGHTSTRIKE IP66 ®... -
Page 9: Dimmer Curve
• Fast: quick and snappy response, can small steps can be noticed while dimming very slowly. • Smooth: smoother dimming without visual steps but slower reaction time for fast changes. • Once the desired value shows on the display, press the ENTER button to confirm. BRITEQ 7/26 BTI-LIGHTSTRIKE IP66 ®... -
Page 10: White Balance
• Yes: flipped display. • Once the correct option shows on the display, press the ENTER button to save it. Remark: a faster shortcut is to press the ▼/▲ buttons together for about 2 seconds. BRITEQ 8/26 BTI-LIGHTSTRIKE IP66 ®... - Page 11 • Press the ENTER button: the current firmware version of the different processors is shown. Note: The firmware of this unit can be upgraded using our special “Firmware Updater” (separately available from Briteq). More information about this can be found in the user manual of the firmware updater or our website: https://briteq-lighting.com/firmware-updater...
-
Page 12: Special Functions Menu
ENGLISH USER MANUAL • This RDM-UID has 2 parts: • Fixed part (same for all BTI-LIGHTSTRIKE IP66 units): 2122004E • Random part (unique 4-digit for each unit, ranging from 0000 to FFFF) ERROR Logs Shows eventual ERROR messages if they exist. - Page 13 This reduces the delays between unit and also improves reliability of the installation. • Internally the selected DMX-universe is treated as a normal DMX-signal so further setup of the DMX- address, channel mode etc. should be done as usual. BRITEQ 11/26 BTI-LIGHTSTRIKE IP66 ®...
-
Page 14: Dmx Charts
Color6 055-061 Color7 062-069 Color8 070-076 Color9 077-084 Color10 085-091 Color11 092-099 Color12 100-106 Color13 107-113 Color14 114-121 Color15 122-128 Color16 129-136 Color17 137-143 Color18 144-151 Color19 152-158 Color20 159-165 Color21 166-173 Color22 174-180 Color23 BRITEQ 12/26 BTI-LIGHTSTRIKE IP66 ®... - Page 15 000-090 No function 091-105 WHITE Macro 1 106-120 WHITE Macro 2 121-135 WHITE Macro 3 136-150 WHITE Macro 4 151-165 WHITE Macro 5 166-180 WHITE Macro 6 181-195 WHITE Macro 7 196-210 WHITE Macro 8 BRITEQ 13/26 BTI-LIGHTSTRIKE IP66 ®...
- Page 16 Color2 025-032 Color3 033-039 Color4 040-047 Color5 048-054 Color6 055-061 Color7 062-069 Color8 070-076 Color9 077-084 Color10 085-091 Color11 092-099 Color12 100-106 Color13 107-113 Color14 114-121 Color15 122-128 Color16 129-136 Color17 137-143 Color18 144-151 Color19 BRITEQ 14/26 BTI-LIGHTSTRIKE IP66 ®...
- Page 17 RGB Macro 27 MACRO SPEED 000-004 STOP (waiting at first step) SPEED L→R: SLOW to FAST 005-127 128-132 STOP (waiting at last step) SPEED R→L: SLOW to FAST 133-255 FADE EFFECT (zero → max) 000-255 BRITEQ 15/26 BTI-LIGHTSTRIKE IP66 ®...
- Page 18 066-070 LED PWM Frequency: 3600Hz 3 seconds delay 071-075 LED PWM Frequency: 4800Hz 3 seconds delay 076-080 LED PWM Frequency: 7200Hz 3 seconds delay 081-085 LED PWM Frequency: 12000Hz 3 seconds delay 086-255 No function BRITEQ 16/26 BTI-LIGHTSTRIKE IP66 ®...
- Page 19 MASTER DIMMER (fine) 0 → 100% 000-255 000-255 STROBE DURATION STROBE SPEED 000-006 No strobe SPEED (slow → fast) 007-255 STROBE EFFECTS 000-005 No effect 006-050 Ramp up 051-100 Ramp down 101-150 Ramp up-down 151-200 Lightning 201-255 Random BRITEQ 17/26 BTI-LIGHTSTRIKE IP66 ®...
- Page 20 65CH LAYOUT 113CH + 123CH LAYOUT 17CH 33CH 65CH 113CH 123CH VALUE FUNCTION REMARKS PIXEL CONTROL 000-255 RED1 000-255 GREEN1 000-255 BLUE1 000-255 RED2 000-255 GREEN2 000-255 BLUE2 000-255 RED3 000-255 GREEN3 000-255 BLUE3 000-255 RED4 BRITEQ 18/26 BTI-LIGHTSTRIKE IP66 ®...
- Page 21 RED19 000-255 GREEN19 000-255 BLUE19 000-255 RED20 000-255 GREEN20 000-255 BLUE20 000-255 RED21 000-255 GREEN21 000-255 BLUE21 000-255 RED22 000-255 GREEN22 000-255 BLUE22 000-255 RED23 000-255 GREEN23 000-255 BLUE23 000-255 RED24 000-255 GREEN24 000-255 BLUE24 BRITEQ 19/26 BTI-LIGHTSTRIKE IP66 ®...
- Page 22 0→ 100% 000-255 MASTER DIMMER (coarse) 0→ 100% 000-255 MASTER DIMMER (fine) 000-255 STROBE DURATION STROBE SPEED 000-006 No strobe SPEED (slow → fast) 007-255 pixel 2 STROBE EFFECTS 000-005 No effect 006-050 Ramp up BRITEQ 20/26 BTI-LIGHTSTRIKE IP66 ®...
- Page 23 DMX CHARTS for combined PIXEL MAPPING AND MACRO SUPPORT The best choice if you want to use the BTI-LIGHTSTRIKE IP66 with media servers and consoles with pixel mapping possibilities but you also want to have access to the easy internal macros: best of both worlds …...
- Page 24 RGB Macro 8 104-111 RGB Macro 9 112-119 RGB Macro 10 120-127 RGB Macro 11 128-135 RGB Macro 12 136-143 RGB Macro 13 144-151 RGB Macro 14 152-159 RGB Macro 15 160-167 RGB Macro 16 BRITEQ 22/26 BTI-LIGHTSTRIKE IP66 ®...
- Page 25 WHITE Macro 11 MACRO SPEED 000-004 STOP (waiting at first step) SPEED L→R: SLOW to FAST 005-127 128-132 STOP (waiting at last step) SPEED R→L: SLOW to FAST 133-255 FADE EFFECT (zero → max) 000-255 BRITEQ 23/26 BTI-LIGHTSTRIKE IP66 ®...
- Page 26 • The DMX-controller sends out a “discovery command”, all RDM devices respond and send their unique device ID. • The DMX-controller asks each RDM device for some basic data so it knows which devices are connected. The projector will respond: • Device name: BTI-LIGHTSTRIKE IP66 • Manufacturer: ® Briteq • Category: LED Dimmer •...
-
Page 27: Maintenance
• Clean with a soft cloth using normal glass cleaning products. • Always dry the parts carefully. Attention: We strongly recommend internal cleaning to be carried out by qualified technician! BRITEQ 25/26 BTI-LIGHTSTRIKE IP66 ®... -
Page 28: Specifications
Surface: 65°C max. Dimensions LxWxD (mm) 1000x91x125 (see drawing) Weight (kg) 10,5 LUX CHART The information might be modified without prior notice You can download the latest version of this user manual on our website: www.briteq-lighting.com BRITEQ 26/26 BTI-LIGHTSTRIKE IP66 ®... -
Page 32: Mailing List
Suscríbete hoy a nuestra lista de correo para recibir las últimas noticias! Inscreva-se hoje na nossa mailing list para estar a par das últimas notícias! WWW.BRITEQ-LIGHTING.COM Copyright © 2023 by BEGLEC NV ‘t Hofveld 2C ~ B1702 Groot-Bijgaarden ~ Belgium...
