7. Connecting and setting

For safety, please do not connect any power supply before the external devices setup.

7.1. External computer and touch connecting

1) Connect a VGA cable (15 pin) between the VGA and external PC. Connect
an earphone cable between the
2) Connect a USB cable between the external PC and USB terminal.
3) Plug the POWER cord and switch it on from the rear panel.
4) Start up the external computer.
5) Press
6) Select Signal source to VGA source according to the one you connected.
Note: The panel can connect with the external PC via HDMI.
Audio IN VGA IN
to turn on the panel.
USB-Touch
PC and audio at the same time.
14
