SYNERGY 329

Twin Assembly

Includes:

(1) Twin 30 Unit

(2) S30 Side Panels

(2) S20 Doors

(2) Adjustable Shelves

(1) Double-Width Shelf

Limited Warranty

Five full years Salamander Designs Ltd will repair or replace, at our option, any product defective in materials or craftsmanship. Salamander Designs Ltd. will not be responsible for any damage to or destruction of other equipment consequential

to our equipment failure. Defective product must be given Return Authorization and is to be returned to the factory prepaid, in the original carton and packing material. Any damage incurred in a shipment not in original packaging shall be the

responsibility of the owner. Warranty repairs will be returned prepaid, via UPS within the continental U.S.A. only.

Salamander Designs Ltd.

•

800-535-5659

BEFORE YOU BEGIN:

• Unpack all parts and read instructions carefully before beginning.

• Shelf pegs and door hinges must slide into the channels of the post in the correct order.

They cannot be removed individually without disassembling the whole unit.

Connect Posts to Bottom Shelf

Square Post

Square the post to the bottom shelf.

Connect Post

Screw foot with metal washer through bottom

shelf and into the end of each extruded post.

Hand tighten fully and use wrench to tighten

nut onto underside of shelf.

WARNING: Tighten by screwing the leveler foot NOT the post.

•

www.SalamanderDesigns.com

Washer

Hex Nut

Leveler Foot

Doc No. 501-100 /v5.24

329 - 1/4
