PARTS
- Supplied with Armless, Left and Right-End Chairs
1
Connector Bolt
1/4 - 20 x 2"
Part# 014978
Lilliana - 500-922 v8/20
Lilliana
Assembly Instructions
2
¼ - 20
Hex Nut
Part# 005489
Thank you for your purchase.
Unpack all content and check to
ensure that all of the parts are in
proper condition. To help protect
the environment, use the appropriate
recycling and discarding methods
for the packaging items.
Read ALL assembly instructions
before beginning. If you have any
questions, please contact your
installator or Salamander Designs
at 800-535-5659.
Tool Required:
Philips Screwdriver
3
¼ - 20 x 2½"
Connector Bolt
Part# 015255
Pre-installed in seatback
Spacers
4
page 1 of 6
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Salamander Designs Lilliana
Summary of Contents for Salamander Designs Lilliana
- Page 1 - Supplied with Armless, Left and Right-End Chairs ¼ - 20 x 2½” Connector Bolt ¼ - 20 Spacers Connector Bolt 1/4 - 20 x 2” Hex Nut Part# 015255 Part# 014978 Part# 005489 Pre-installed in seatback Lilliana - 500-922 v8/20 page 1 of 6...
- Page 2 Tactile Transducer Power Seating - Optional Connect power supplies to motors. Coil & Tie Extra Wire Length. Be careful to route wires away Connect recliner controllers from mechanism. to motors. 2-pin adaptor cord Lilliana - 500-922 v8/20 page 2 of 6...
- Page 3 Raise lower back panels and locate the back bolt holes. Secure connection by inserting bolt through chair and into arm. Lilliana - 500-922 v8/20 page 3 of 6...
- Page 4 Fasten with nut. 2 spacers are needed between seats. In this configuration 2 spacers are needed between each seat. Secure connection by inserting bolt (1) through chair frames. Fasten with nut (2). 2 spacers are needed between seats. Lilliana - 500-922 v8/20 page 4 of 6...
- Page 5 Press down to align the backrest screw holes to the upper and lower holes in the chair mechanism tongues. Install and tighten screws. Recline chair and fasten seatback flap under rear edge. Lilliana - 500-922 v8/20 page 5 of 6...
- Page 6 We recommend a small size power strip to connect multiple power chairs. It is also possible to utilize multiple Y-type splitters to connect chairs in series. Please note the specifications of the power components and be cautious not to overload the electrical circuit. phone: 800-535-5659 www.SalamanderDesigns.com Lilliana - 500-922 v8/20 page 6 of 6...
