PARTS
- Supplied with Armless, Left and Right-End Chairs
1
Connector Bolt
1/4 - 20 x 2"
Part# 014978
Matteo - v8/20
MATTEO
Assembly Instructions
2
1/4 - 20
Hex Nut
Part# 005489
Thank you for your purchase.
Unpack all content and check to
ensure that all of the parts are in
proper condition. To help protect
the environment, use the appropriate
recycling and discarding methods
for the packaging items.
Read ALL assembly instructions
before beginning. If you have any
questions, please contact your
installator or Salamander Designs
at 800-535-5659.
3
5/16 - 18 x 50mm
Connector Bolt
Part# 005488
4
Spacers
Hex Wrench
5
Part# 005490
page 1 of 6
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Salamander Designs MATTEO
Summary of Contents for Salamander Designs MATTEO
- Page 1 Read ALL assembly instructions before beginning. If you have any questions, please contact your installator or Salamander Designs at 800-535-5659. PARTS - Supplied with Armless, Left and Right-End Chairs Spacers Connector Bolt...
- Page 2 Tactile Transducer Powered Seating Connect power supplies to motors. 2-pin extension cord Coil & Tie Extra Wire Length. Be careful to route wires away from mechanism. Connect recliner controllers to motors. Matteo - v8/208 page 2 of 6...
- Page 3 Remove lower back panel and locate the back bolt hole. Secure connection by inserting bolt through chair and into arm. Matteo - v8/20 page 3 of 6...
- Page 4 Front Spacer In this configuration 2 spacers are needed between the seats. Remove lower back panel and locate the back bolt holes. Secure connection by inserting bolts through chair bases with spacers in between. Fasten with nut. Matteo - v8/20 page 4 of 6...
- Page 5 Note: Backrests may be removed by releasing the clips on the receiver brackets in the backrest. Matteo - v8/20 page 5 of 6...
- Page 6 We recommend a small size power strip to connect multiple power chairs. It is also possible to utilize multiple Y-type splitters to connect chairs in series. Please note the specifications of the power components and be cautious not to overload the electrical circuit. phone: 800-535-5659 www.SalamanderDesigns.com Matteo - v8/20 page 6 of 6...
