- Page 1 GRASSLAND PRO HARROW GP 600 M2 | GP 750 M2 OPERATOR MANUAL PLEASE READ CAREFULLY BEFORE INITIAL OPERATION Translation of the original operating manual Version: 3.0 EN; item number: 00603-3-084...
-
Page 2: Table Of Contents
TABLE OF CONTENTS EC DECLARATION OF CONFORMITY ..................5 UK CONFORMITY ASSESSED ...................... 6 REPRESENTATION OF INFORMATION ..................7 Layout of the warnings ......................7 IDENTIFICATION OF THE IMPLEMENT ..................7 SERVICE ............................8 WARRANTY ........................... 8 Warranty activation ......................8 SAFETY INFORMATION ........................ - Page 3 LIGHTING CIRCUIT DIAGRAM ....................43 HYDRAULIC DIAGRAM ....................... 44 18.1 GP 600 M2 / GP 750 M2 ....................44 18.2 GP 600 M2 / GP 750 M2 with chassis damping ..............45 DECOMMISSIONING, STORAGE AND DISPOSAL..............46 19.1 Decommissioning the implement ..................46 19.2 Storage of the implement ....................
- Page 4 21.9 Hydraulic tine adjustment ....................53 21.10 Sensor set: GPSa + linkage sensor ................... 53 21.11 Feeler wheel mounting kit GP 600 M2 ................54 21.12 Hydropneumatic chassis damping ..................55 21.13 Seeding rail ........................55 SPARE PARTS ..........................55...
-
Page 5: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY Manufacturer: APV - Technische Produkte GmbH Dallein 15 AT - 3753 Hötzelsdorf hereby declares that the mounted implement series described in the following complies with the applicable basic safety and health requirements of the above-mentioned Directives in terms of its concept and design as well as the versions put on the market. -
Page 6: Conformity Assessed
UK CONFORMITY ASSESSED Manufacturer: APV - Technische Produkte GmbH Dallein 15 AT - 3753 Hötzelsdorf hereby declares that the mounted implement series described in the following complies with the applicable basic safety and health requirements of the above-mentioned Directives in terms of its concept and design as well as the versions put on the market. -
Page 7: Representation Of Information
REPRESENTATION OF INFORMATION LAYOUT OF THE WARNINGS The following symbols are used in the operating manual for particularly important information: DANGER! Identification of an immediate danger with high risk, resulting in death or serious physical injuries if it is not avoided. WARNING! Identification of a possible danger with moderate risk, which can possibly result in death or serious physical injuries if it is not avoided. -
Page 8: Service
WARRANTY ACTIVATION Every APV implement must be registered immediately after delivery. The registration activates the claim for warranty services and APV can guarantee the best service. To activate the warranty for your implement, simply scan the QR code with your smartphone - you will then be taken directly to the service area on our website. -
Page 9: Safety Information
SAFETY INFORMATION This chapter contains general rules of conduct for the intended use of the implement and safety- related information that should always be observed for your safety. The list is very extensive, and some of the information does not apply exclusively to the delivered implement. - Page 10 specified in the operating manual are met and that the connections specified in the operating made are correctly established. • When driving through low or narrow obstacles (e.g. power lines, underpasses, etc.), attention must be paid to the height and width of the implement to avoid collisions. •...
-
Page 11: Mounted Implements
MOUNTED IMPLEMENTS • Only APV implements and accessories may be mounted on the implement. • Do not stand between the tractor and the implement when actuating the external controls for the three- point mounting! •... -
Page 12: Hydraulic System
• Replacing components that cannot be removed with tools such as a screwdriver or wrench may only be replaced by qualified specialist personnel from an appropriately authorised company or by APV Customer Service. • The implement must be checked regularly by the operator (before every use) for any fractures and cracks, leaks, chafe marks, loose bolts and connections, vibrations and to ensure it functions correctly. -
Page 13: Tyres
The platform kit must only be used as a maintenance walkway. • An ascent must be established conforming to the standards. This ascent is available from APV. • When not in use, the steps must be folded up and secured. -
Page 14: Danger Areas
NOTE! Misprints, errors and omissions excepted. DANGER AREAS WARNING! Travelling danger area The danger area of the implement travels along with the implement during operation. The danger area includes the area across the entire width of the implement in the direction of travel (see Figure 3). An additional safety distance of 2 m from the implement must be maintained on each side. -
Page 15: Danger Areas During Implement Operation
7.8.1 DANGER AREAS DURING IMPLEMENT OPERATION Figure 3... -
Page 16: Danger Areas When Folding And Unfolding
7.8.2 DANGER AREAS WHEN FOLDING AND UNFOLDING Figure 4 RESIDUAL HAZARDS Residual hazards are special hazards when working with the implement, which cannot be eliminated despite safety-compliant design. Residual hazards are often not obvious and can be a source of possible injuries or health risks. 7.9.1 DANGER FROM MECHANICAL SYSTEMS There is a risk of accidents due to crushing, cutting and impacts with body parts... -
Page 17: Dangers Arising From Operation
7.9.3 DANGERS ARISING FROM OPERATION During operation, there is a risk of injury to body parts, particularly the face, due to stones and clods of soil being flung up. INFORMATION SIGNS / HAZARD LABELS Pay special attention to the stickers on the implement, as they warn you of specific dangers! CAUTION! Keep information signs and hazard labels clean If hazard labels or information signs are becoming or are already detached, they need to be replaced... - Page 18 Information sign (symbolic representation) Order number 00603-3-687 00600-3-138 00600-3-163 After a short period of These stickers indicate Labelling of the lubrication Explanation operation, re-tighten all the tyre inflation pressure. points. bolts and nuts. Information sign Order number 00602-3-119 00600-3-139 00601-3-658 Loading hooks.
-
Page 19: Hazard Labels
HAZARD LABELS Information sign Order number 00604-3-648 00603-3-664 00602-3-294 Caution, crushing area! Caution, do not climb onto Never reach into the Always lift the implement Explanation the implement! crushing danger zone as slowly off the ground. long as the parts can still Risk of rolling over! move! Information... -
Page 20: Placement Of The Hazard Labels And Other Signs
PLACEMENT OF THE HAZARD LABELS AND OTHER SIGNS The following figures show the arrangement of the hazard labels and other signs on the implement. Figure 5 Figure 6 Figure 7 Figure 8 Figure 9 Figure 10... -
Page 21: Operating Manual
Figure 11 Figure 12 OPERATING MANUAL LAYOUT AND MODE OF OPERATION Drawbar Folding cylinder Chassis cylinder Running gear Levelling plate 12 mm tines 8 mm tines roller cylinder Cambridge roller toothed ring roller Figure 13 Thanks to its robust and compact design, the Grassland Pro harrow is ideal for new seeding, reseeding, and controlling weeds on grassland. -
Page 22: Mounting And Dismounting The Implement
MOUNTING AND DISMOUNTING THE IMPLEMENT 9.2.1 GENERAL INFORMATION • The tractor tyre pressure must be selected as specified by the tractor manufacturer. • Under difficult operating conditions, additional wheel weights can be useful. Comply with the information provided by the tractor manufacturer. •... -
Page 23: Uncoupling
WARNING! Risk of slipping, tripping or falling due to elements such as lines, hoses or other elements in the range of motion. Route and fasten lines, hoses or other elements outside of the range of motion. • Connect the lighting and electrical cables (if present). •... - Page 24 CAUTION! Always secure the implement to prevent it from rolling away. DANGER! Prior to uncoupling, you must check again to ensure that the mechanical folding lock is engaged. WARNING! Comply with the sequence for locking the pneumatic brake system ! First uncouple the red brake line, then the yellow brake line.
-
Page 25: Unfolding From Transport Position To Working Position
UNFOLDING FROM TRANSPORT POSITION TO WORKING POSITION The hydraulic cylinders for depth setting of the roller must be in the maximum possible retracted position. Only unfold the implement under these conditions, otherwise massive collisions or warping can occur between the two roller segments. The amount of oil on the control units of the coupled tractor must be reduced accordingly, so that the entire folding procedure runs slowly (at least 12 seconds) and is gentle on the implement. -
Page 26: Working Position And Setting The Working Depth
The control unit on the coupled tractor for adjusting the roller hydraulic cylinders must be appropriately secured during road travel, so that the road transport width cannot be inadvertently misadjusted, i.e. increased. DANGER! Risk of accident due to improper folding of the side sections Improper folding of the side sections results in accidents if people are standing in the swivelling and folding range of the side sections or if there are high-voltage lines in the swivelling and folding range of the side sections. -
Page 27: Adjusting The Series Of Holes
NOTE! The working depth must be checked after driving for 10 m and re-adjusted if necessary. For larger work areas, the working depth of the tines must be checked from time to time. 9.5.2 ADJUSTING THE SERIES OF HOLES In addition to depth setting, the aggressiveness of each individual tine row can also be changed individually. -
Page 28: Coupling And Uncoupling The Roller
1 Crank 2 Locking pin 3 Shear bolt 4 Levelling plate Figure 24 Figure 25 Figure 26 WARNING! Only operate the crank with one hand; two-hand operation poses a considerable risk of injury (hand or finger injuries). The crank has a slip safeguard for better handling and transmission of force. -
Page 29: Folding Lock
NOTE! It must be noted that by removing the roller, uniform depth control can no longer be ensured for the harrow units. For this reason, feeler wheels must always be installed when the rollers are removed. CAUTION! The rollers may only be installed or removed when the feeler wheel mounting kit is used (see Point 21.11). -
Page 30: Turning On The Headland
NOTE! For easier release of the folding lock, briefly apply pressure to the folding cylinder. This fully extends the folding cylinder and the side frame is completely lifted again. 9.10 TURNING ON THE HEADLAND 9.10.1 TURNING WITH ROLLER When turning on the headland, first the lower links are lifted, then the roller is pressed downward so that the implement runs on the rollers. -
Page 31: Hydropneumatic Chassis Damping
9.12 HYDROPNEUMATIC CHASSIS DAMPING A diaphragm accumulator is attached on the chassis cylinder on both sides (tension and compression side), which ensures damping of the implement. Figure 32 NOTE! It is important to note that the hydraulic cylinder is not completely extended, otherwise the cylinder cannot dampen (approx. -
Page 32: Intended Use
To activate the warranty for your implement, simply scan the QR code with your smartphone – you will then be taken directly to the warranty activation page. You can also call up the warranty activation page through our website www.apv.at in the Service area. 10.3 INITIAL OPERATION 10.3.1 SCOPE OF DELIVERY AND ATTACHMENT... -
Page 33: Electrical Connection
Figure 35 CAUTION! If possible, do not roll up the cable into a coil! 10.3.2 ELECTRICAL CONNECTION Connect the standard connected cable directly to the 3-pin standard socket on the tractor. Stow the excess cable in the driver's cab to avoid pinching. Connect the control to your seed drill via the 3-pin standard socket on the bottom. -
Page 34: User Interface Of The Control Box
6-pin plug • Connection to the Grassland Pro Harrow (implement cable) 3-pin plug • Connection to the battery (power cable) 25 A fuse 3-pin socket • Connection for external control box of your seed drill On/off switch Figure 37 10.3.3 USER INTERFACE OF THE CONTROL BOX Switch for tine adjustment - seeding rail Switch for hydraulically adjustable drawbar <–>... -
Page 35: Assistance In The Event Of Problems
10.3.6 ASSISTANCE IN THE EVENT OF PROBLEMS Problem Solutions No display on the LED after pressing the Check whether the power cable is properly inserted into the on/off switch. control box and is also connected to the correct terminals on the battery. -
Page 36: Instructions For Regular Maintenance
• The manufacturer is not liable for any unauthorised modifications and the use of components and auxiliary parts. • Put down the implement in a way that the tines are not needlessly strained. (Roller all the way down, use the parking supports at the front.) •... -
Page 37: Changing The Tines
12.3 CHANGING THE TINES To replace broken or worn tines, unscrew the nuts and take off the tines. • The new 12 mm tine, as shown in Figure 39, is hooked into the hooks and the nuts are firmly retightened. Pay attention to the proper line spacing! The tines in the rear row cut the distance of the front tines in half. - Page 38 Quantity Position Levelling plate bearing (2 lubrication points per levelling plate; Figure 47) Brake linkage on the axle (1 lubrication point per tyre; Figure 48) Tightening spindle (if present; Figure 49) Hydraulic drawbar (if equipped; Figure 50) NOTE! Each bearing must be offloaded beforehand, so that the lubricating grease can be distributed uniformly in the bearing point.
-
Page 39: Repairs And Service
Figure 48 Figure 49 Figure 50 12.6 REPAIRS AND SERVICE In case of failure or damage to the implement, please contact the manufacturer. The contact data can be found in chapter 3. -
Page 40: Information On Nature Conservation And Environmental Protection
Many parts of the implement are made of steel or spring steel (such as the centre frame, side frames, etc.) and can be removed and recycled by a waste disposal company. TECHNICAL DATA Type designation GP 600 M2 Working width Transport dimensions in m 3.20 x 3.00 x 5.70... -
Page 41: Possible Combinations With A Pneumatic Seeder
POSSIBLE COMBINATIONS WITH A PNEUMATIC SEEDER PS200 H PS300 H PS500 H PS800 H Dimensions HxWxD Dimension HxWxD [cm] [cm] Road transport with PS 100x70x110 110x77x150 117x80x125 127x105x170 GP 600 toothed ring 350 x 299 x 575 roller GP 600 Cambridge roller 350 x 299 x 575 Can be combined with PS mounting kit GP 750 toothed ring... -
Page 42: Road Transport
ROAD TRANSPORT 16.1 TRANSPORT ON PUBLIC ROADS (GENERAL INFORMATION) • Comply with the road traffic regulations of your country's legislation. • The axle load and the total weight of the towing vehicle may not be exceeded. • The mounted implement must be identified with country-specific warning signs or stickers with red and white slanted lines (according to DIN, ÖNORM or the respective country-specific STANDARDS). -
Page 43: Lighting Circuit Diagram
LIGHTING CIRCUIT DIAGRAM Legend: Right 12 V plug, 7-pin Rear light, right Turn signal Rear light Brake light Left Rear light, left Brake light Rear light Turn signal Plug and cable assignment Desi Colour Function Yellow Turn signal, left Figure 51 White Earth Green... -
Page 44: Hydraulic Diagram
HYDRAULIC DIAGRAM 18.1 GP 600 M2 / GP 750 M2 Figure 52 Tractor-side T-connection Double-acting cylinder for hydr. adjustable drawbar G: Implement-side Load-holding valve Double-acting cylinder for tine adjustment Control unit Throttle disc Double-acting cylinder for slit seeding Coupling sleeve BG 2... -
Page 45: Gp 600 M2 / Gp 750 M2 With Chassis Damping
18.2 GP 600 M2 / GP 750 M2 WITH CHASSIS DAMPING Figure 53 Tractor-side T-connection Double-acting cylinder for hydr. adjustable drawbar G: Implement-side Load-holding valve Double-acting cylinder for tine adjustment Control unit Throttle disc Double-acting cylinder for slit seeding Coupling sleeve BG 2... -
Page 46: Decommissioning, Storage And Disposal
DECOMMISSIONING, STORAGE AND DISPOSAL 19.1 DECOMMISSIONING THE IMPLEMENT To ensure that the implement remains fully functional, even if it is out of operation for longer periods of time, it is important to take precautions for storage: To do so, observe Point 19.2. 19.2 STORAGE OF THE IMPLEMENT •... -
Page 47: Accessories
Reseeding in the spring has the advantage that the spring humidity and the disturbed soil can be used as a seedbed. However, despite the good start, the grass can dry out during a summer drought, and the pressure of the old sod is greater in the spring due to the stronger growth spurt. With the Grassland Pro Harrow, we counteract this disadvantage with a roller that presses down the seed and therefore improves soil contact. - Page 48 WARNING! Because the brakes are immediately release when the compressed air reservoir is filled, it is important to comply with the connection sequence: first couple the yellow brake line, then couple the red brake line! Figure 55 NOTE! If one compressed air line on the implement should be defective, the implement can still be moved by manually triggering the pressure accumulator on the trailer brake valve (see Figure 55).
- Page 49 21.1.1.2 READJUSTING THE BRAKE SYSTEM In the middle of the axle, there is a diaphragm cylinder. It can be readjusted using a threaded rod if necessary. The path from actuation of the cylinder to active braking may only account for max.
-
Page 50: Wheel Chocks
21.1.2 WHEEL CHOCKS The wheel chocks prevent the implement from rolling away. The wheel chocks are also available separately, the following order number can be used for this: Order number: 06028-2-251 Figure 61 21.1.3 TINE SECTIONS COVER With this protection, the bottom tine rows of the outer tine sections are covered. -
Page 51: Mounting Kit For Ps200 - 500
Seeder on the implement. Please note that it must be mounted in compliance with the standards. Order number: PS 500 M2 on GP 600 M2: 06028-2-278 PS 500 M2 on GP 750 M2: 06029-2-013 PS 800 M1 on GP 600 M2: 06028-2-279... -
Page 52: Changeover Valve For Operating Two Hydraulic Functions
21.6 CHANGEOVER VALVE FOR OPERATING TWO HYDRAULIC FUNCTIONS The changeover valve enables connection of the hydraulic circuits of the roller frame and the chassis. As a result, one less control unit is required. Switching between the two hydraulic circuits is achieved by actuating the lever on the changeover valve, which is attached to the drawbar (see Figure 69). -
Page 53: Hydraulically Adjustable Drawbar
Order number: 06028-2-319 Figure 71 21.9 HYDRAULIC TINE ADJUSTMENT Order number: GP 600 M2: 06028-2-315 GP 750 M2: 06029-2-011 Figure 72 21.10 SENSOR SET: GPSA + LINKAGE SENSOR The GPSa sensor transmits the current vehicle speed to the Control Box so that the seed rate is automatically regulated. It is installed on the seeder hopper. -
Page 54: Feeler Wheel Mounting Kit Gp 600 M2
21.11 FEELER WHEEL MOUNTING KIT GP 600 M2 This kit is required if you want to mount or dismount the roller of the GP 600 M2. It consists of: • Supports for the side frames • A manoeuvring aid for the rollers and •... -
Page 55: Hydropneumatic Chassis Damping
21.12 HYDROPNEUMATIC CHASSIS DAMPING Order number: GP 600 M2: 06028-2-316 GP 750 M2: 06029-2-012 Figure 79 21.13 SEEDING RAIL Order number: GP 600 M2: 06028-2-317 GP 750 M2: 06029-2-015 Figure 80 SPARE PARTS You have the option to order your required spare parts directly through our online spare parts catalogue. -
Page 56: Index
INDEX Accident prevention regulations ......9 Lubrication points ..........37 Adjusting the series of holes ......27 Lubrication schedule ........37 Bearing ............46 Maintenance ........... 35 Bracket for PS ..........51 Mode of operation of the implement ....21 Cable .............. - Page 57 NOTES...
- Page 58 NOTES...
- Page 59 NOTES...
- Page 60 APV – Technische Produkte GmbH Zentrale: Dallein 15 AT - 3753 Hötzelsdorf Tel.: +43 2913 8001 office@apv.at www.apv.at...
