- Page 1 Version 1.0 EN Item no.: 00602-3-225 Grassland Combi operating manual GK 400 M1 Please read carefully before initial operation! TRANSLATION OF THE ORIGINAL OPERATING MANUAL...
-
Page 2: Table Of Contents
Repairs and service ....................17 Information on nature conservation and environmental protection ......17 Technical data ........................17 Hydraulic diagram......................18 Road transport of the GK 400 M1 ..................19 14.1 Transport on public roads (in general) ..............19 14.2 Transport on public roads (most important specifications) ........ - Page 3 16.3 Disposal ........................22 16.4 Crop cultivation tips when using the GK 400 M1 ............22 Accessories........................23 17.1 Lighting with warning signs (on both sides) .............. 23 17.2 Platform kit for the harrow of the GK ................. 23 17.3 Accessories kit for dispersion plate installation on the harrow of the GK ....
-
Page 4: Ec Declaration Of Conformity
This declaration loses its validity if there are any changes to the mounted implement that are not approved by APV-Technische Produkte GmbH. Designation of the mounted implement: Grassland Combi GK 400 M1 Year of manufacture: as of 2020 Serial number(s): as of 06023-01000... -
Page 5: Identification Of The Implement
For questions regarding spare parts To order maintenance and repair work Service address: APV - Technische Produkte GmbH Telephone: +43 (0) 2913 8001-5500 HEADQUARTERS Fax: +43 (0) 2913 8002 Dallein 15 Email: service@apv.at A-3753 Hötzelsdorf... -
Page 6: Warranty Activation
Intended use The Grassland Combi GK 400 M1 is intended as a rear-mounted implement and is designed and built for use in agricultural operations. It is used to prepare the soil for subsequent tillage and use. -
Page 7: General Safety-Related Instructions And Accident Prevention Regulations
General safety-related instructions accident prevention regulations The operator has read and understood this operating manual before handling the implement. The operator must train and instruct their personnel if necessary. The personnel must have read and understood this operating manual before handling the implement. ... -
Page 8: Mounted Implements
Extreme caution must be taken when changing defective components or tools. Replacing components that cannot be removed with tools such as a screwdriver or wrench may only be replaced by specialist personnel from an appropriately authorised company or by APV Customer Service. -
Page 9: Tyres
If repairs or maintenance are required on the implement that can only be performed in conjunction with the towing vehicle, this work must be identified by a clearly visible information sign "Caution: maintenance work". Check the nuts and bolts regularly for tight fit and retighten if necessary! ... -
Page 10: Information Signs / Hazard Labels
Information signs / hazard labels Pay special attention to these stickers on the implement, as they warn you of specific dangers! Information signs Loading hooks. When loading the implement, attach the ropes or chains to Read and observe the Do not stand on the Always switch off the these points! operating manual... -
Page 11: Hazard Labels
Danger due to parts being flung out; observe the safety distance! Operating manual for GK 400 M1 Mounting on the tractor The air pressure in the rear tractor tyres should be 0.8 bar during operation. If the tyres have a lower load capacity, increase the pressure. - Page 12 After coupling the lower link, turn around the parking support by pulling out the pin, reposition it and then secure. (Fig. 2; Fig. 3) Fig. 3 Fig. 2 Connect the hydraulic hoses to a double-acting control unit. During connection, make sure that the hoses are unpressurised both on the tractor and implement sides.
-
Page 13: Layout And Mode Of Operation
For normal operation, the pin should be in the middle of the elongated slot. If you want to use the GK 400 M1 with the roller lifted, i.e. the roller in the highest position and the roller cylinder completely retracted, you must firmly attach the top link on the implement side. This position must also be used in road traffic. -
Page 14: Aggressiveness Adjustment
Aggressiveness adjustment In addition to the depth, the aggressiveness of the tines relative to one another on the GK 400 M1 can also be changed. To do so, you only have to insert the pins for the harrow rows as desired in a higher or lower hole. -
Page 15: Use Of Individual Tools
Fig. 8 Use of individual tools With GK 400 M1, it is also possible to use individual tools (levelling plate, harrow, roller) separately or in any combination, e.g. you can use the roller alone by completely extending the roller cylinder. -
Page 16: Regular Maintenance Instructions
Put down the implement in a way that the tines are not needlessly strained (roller all the way down, use the parking supports at the front). 10.2 Regular maintenance instructions All bolted connections should be re-tightened at the latest after 3 operating hours and again after 20 hours, and then checked regularly (loose bolts can cause significant consequential damage, which is not covered by the warranty). -
Page 17: Tine Safety
Many parts of the Grassland Combi are made of steel or spring steel (such as the frame, tine section, tines, ...) and can be accepted and recycled by a waste disposal plant. Technical data Type designation: GK 400 M1 Levelling with leaf springs with wear plate Mode of operation: 2 rows of aggressive round spring tines... -
Page 18: Hydraulic Diagram
Sensor set GPSa + top link linkage sensor Pneumatic seeder 120-500 with electric and hydraulic Combination options: Hydraulic diagram Hydraulic roller adjustment of the GK 400 M1: 1: Control unit 2: Hydr. couplings 3: Hydr. roller cylinder 4: Hydr. locking block Fig. -
Page 19: Road Transport Of The Gk 400 M1
3 m is maintained. After field operation, the roller of the GK 400 M1 must be cleaned to prevent soil residues adhering to the roller from falling on the road. - Page 20 Specifications: Tractor net weight Front axle load of the empty tractor Rear axle load of the empty tractor Total weight of the rear-mounted implement Total weight of the front-mounted implement Distance from the centre of gravity of the front-mounted implement to the centre of the front axle Wheelbase of the tractor Distance from the centre of the rear axle to...
-
Page 21: Lighting Circuit Diagram
6. Tyre load capacity: Enter the doubled value (two tyres) for the permissible tyre load capacity (see e.g. tyre manufacturer documents) in the table. 14.3.1 Table for the weight ratios Double the Permissible value Actual value permissible tyre acc. to operating acc. -
Page 22: Decommissioning, Storage And Disposal
Grassland Combi GK 400 M1 with 2 tine rows. Together with the reconsolidation with a roller, three working procedures are accomplished in one field pass. With its thorough and effective mode of action, the GK 400 M1 can be optimally integrated in your overall management concept. -
Page 23: Accessories
With the GK 400 M1, we counteract this disadvantage with a roller that presses down the seed and therefore improves soil contact. This allows the seed to germinate more rapidly and the risk of desiccation is reduced. -
Page 24: Accessories Kit For Dispersion Plate Installation On The Harrow Of The Gk
17.3 Accessories dispersion plate installation on the harrow of the GK Items included: 1 hollow profile 30 x 20 mm, 8 clamping plates for dispersion plates, installation material Order number: 06023-2-030 Fig. 16 17.4 Pneumatic seeder mounting kit for the harrow of the GK (Please note that the pneumatic seed drill must be mounted in compliance with ISO 4254-1.) -
Page 25: Sensor Set - Gpsa + Linkage Sensor Top Link
Please keep your product number / serial number at hand. You can also view our online spare parts catalogue on our website www.apv.at in the Service area. If you have any questions regarding spare parts or your order, our Customer Service (see point 3 for contact data) is also happy to assist you. -
Page 26: Index
Index Accessories ..........23 Mounting on the tractor ....... 11 Accident prevention regulations ....7 operating manual ......10, 11, 20 Aggressiveness adjustment ......14 Permissible axle loads ........ 19 Air pressure ..........11 Plug and cable assignment ......21 Bearing .......... - Page 27 Notes Tranlation of the original operating manual Page 27...
- Page 28 Web: www.apv.at Company details APV - Technische Produkte GmbH, Managing Director: Ing. Jürgen Schöls, Markus Alschner, Dallein 15 AT-3753 Hötzelsdorf, Austria, marketing@apv.at, www.apv.at, VAT ID no.: ATU 5067 1107 Photo credits: Company photos © APV Concept & text: Mag. Michaela Klein, Julia Zach, M.A., Claudia Redl Graphics: Jürgen Undeutsch, M.A.
