Version: 2.0 EN / Item no.: 00601-3-374
Operating manual RH 600 M1
Please read carefully before initial operation!
ORIGINAL OPERATING MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RH 600 M1 and is the answer not in the manual?

Questions and answers

Summary of Contents for APV RH 600 M1

  • Page 1 Version: 2.0 EN / Item no.: 00601-3-374 Operating manual RH 600 M1 Please read carefully before initial operation! ORIGINAL OPERATING MANUAL...
  • Page 2: Table Of Contents

    Accident prevention ......................4 Basic information ........................ 4 Transport on public roads (most important specifications) .......... 4 Operating manual for the APV roller hoe RH 600 M1 ............5 Mounting on the tractor ....................5 Safe parking ....................... 5 Roller hoe test flaps ....................5 Layout and mode of operation ...................
  • Page 3: Ec Declaration Of Conformity

    EC Declaration of Conformity In compliance with Directive 2006/42 EC The manufacturer APV-Technische Produkte, Dallein 15, A-3753 Hötzelsdorf, hereby declares that the product Roller hoe RH 600 M1 Implement type designation / serial no. (see handover declaration and title page)
  • Page 4: Provisions

    Provisions Dear customer! We are pleased and congratulate you on your purchase and wish you lots of fun and success in working with this implement! Please be sure to read all the instructions in this operating manual before operating the implement! Warranty Please check the implement for any transport damage immediately upon receipt.
  • Page 5: Operating Manual For The Apv Roller Hoe Rh 600 M1

    When driving on roads after field operation, the implement should be cleaned of field residues (soil, grass, etc...). Operating manual for the APV roller hoe RH 600 M1 Mounting on the tractor The implement must be mounted on the 3-point linkage of the tractor.
  • Page 6: Layout And Mode Of Operation

    Pivot point of the folding These 2 + 2 arms must ALWAYS be in working position before they are folded up! Figure 3: Layout and mode of operation 1. Star rings with a diameter of 500 mm Figure 4: 2. Feeler wheels 3.
  • Page 7: Working Position And Setting The Working Depth And Pitch

    Thanks to its robust and compact design, the RH 600 roller hoe is ideal for breaking up crusted soils and designed for controlling weed grasses in various crops. The rotating hoe rings bury or uproot the weeds, promote tillering of the crop, incorporate oxygen into the soil and break up hard soil crusts.
  • Page 8 Figure 6: 1 = Quick locking mechanism, 2 = Preload plate with comfort handle Figure 7: Pitch for both rings 30° 1 = Arm holder 2 = Locking notch Figure 8: Pitch of 30° and 0° 3 = Quick locking plate Page 8...
  • Page 9: Quick Lifting Device (Installed As A Standard)

    Quick lifting device (installed as a standard) 1 = Arm, 2 = Pin for quick lifting device Figure 9: Figure 11: Quick lifting device activated Figure 10: Parking position 1 = Lifted position 1= Pin in parking position Page 9...
  • Page 10 Limitation of the negative range Figure 12: Using the quick lifting (available as an accessory), the implement can be adapted to the crop without using tools, only the folded-up arm must be fixed with the pin in the top hole. If the quick lifting device is not active, the pin can be stored in the parking position in the last hole.
  • Page 11: Maintenance And Care

    Maintenance and care To maintain the implement in good condition even after a long service life, the following instructions must be observed: In the supplement "For your safety…" you will find some basic safety regulations for maintenance work. Original parts and accessories are designed especially for the machines or implements. Please note that spare parts and accessories not supplied by us have also not been tested and approved by us.
  • Page 12: Technical Specifications

    1 row of star rings Working width: Transport width: 2.85 m Dimensions (W x H x D in m): RH 600 M1: 2.85 x 2.75 x 1.55 (folded) Working speed: 2 - 25 km/h (depending on the crop) Working depth: 0 - 30 mm...
  • Page 13: Combination Options

    Combination options TD combination options RH 600 M1 – PS Parts required for PS120 E PS120 H PS200 E PS200 H PS300 E PS300 H PS500 E PS500 H PS800 mounting Dimensions Dimensions Dimensions Dimensions LxWxH Dimensions Dimensions Dimensions Dimensions...
  • Page 14: Hydraulic Diagram

    Hydraulic diagram Control unit Coupling sleeve BG2 Coupling connector BG 2 Throttle disc Stop tap Folding cylinder Figure 15 Page 14...
  • Page 15: Exchanging The Star Rings/Bearings

    Exchanging the star rings/bearings To be able to exchange worn or broken star rings, you only have to loosen the hexagonal bolt (Figure 16) and remove the ring including the bearing and the black attachment discs. To exchange broken bearings, loosen the 6 hexagonal bolts, remove the black attachment discs and press out the bearing (Figure 17).
  • Page 16: Calculation Of The Weight Ratios

    13.3 Calculation of the weight ratios If you want to drive with an implement that is attached to the 3-point linkage, you must ensure that you do not exceed the tractor's permissible axle loads and tyre load capacities with the mounted implement. The front axle of the tractor must be loaded with at least 20 % of the net weight of the tractor.
  • Page 17 3. Calculation of the actual front axle load T v tat If the required minimum front ballast (G ) is not reached with the front-mounted implement (G ), the weight V min of the front-mounted implement must be increased to the weight of the minimum front ballast! Now enter the calculated actual front axle load and the permissible front axle load specified in the tractor operating manual in the table.
  • Page 18: Lighting Circuit Diagram

    Thanks to its successful use in cereals, maize, beets, squash, oil rape seed, vegetables, peas, soy, and horse beans, the APV roller hoe makes a significant contribution to soil cultivation. It covers everything from the crop rotations to fertilisation, and soil tillage to mechanical weed control. The objective of its concept will be to keep the weed population so small that the weeds cannot cause any qualitative or quantitative damage to your crops.
  • Page 19: Hitting The Right Growth Phase

    15.1 Hitting the right growth phase • Measures that are performed before the crop emerges are particularly effective. For this reason, weed control must be coordinated as precisely as possible with the soil tillage and seeding dates. • "Blind harrowing" (before the cereals emerge) often achieves very good results. This can be performed until the cereal starts tillering.
  • Page 20 Beets Use at a growth height of 3 – 4 cm (light to medium aggressiveness) Vegetables Use for cuttings and seeds: At a growth height of 4 to 5 cm (light aggressiveness), cuttings – approx. 14 days after planting (light aggressiveness) Use depending on the weed pressure and soil conditions Peas Use: Blind harrowing...
  • Page 21: My Idea

    My idea The RH 600 M1 was extensively developed and tested. It took a long time from the initial idea to serial production. It required lots of commitment from individual employees and the entire development team. We collaborated with universities, specialists from the field and initiated research projects.
  • Page 22: Safety Instructions

    Safety instructions For your safety… This supplement to the operating manual contains general rules of conduct for the intended use of the implement and safety-related information that should always be observed for your personal safety. The list is very extensive, and some of the information does not apply exclusively to the delivered implement.
  • Page 23: Mounted Implements

    • The user should wear close-fitting clothing. Avoid wearing loose clothes! • Keep the implements clean to reduce the risk of fire! • Check the surrounding area before starting up and operating the implement! (Children!) Ensure sufficient visibility! • It is not allowed to carry passengers on the implement during operation and transport! •...
  • Page 24: Hydraulic System

    17.5 Hydraulic system • The hydraulic system is under high pressure! • When connecting hydraulic cylinders and motors, the specified connection of the hydraulic hoses must be observed. • When connecting the hydraulic hoses to the tractor hydraulic system, make sure that the hydraulic system on the tractor and implement side is unpressurised! •...
  • Page 25: Tyres

    Misprints, errors and omissions excepted! Accessories The following parts are available as accessories: • Mounting kit for PS 120 – 300 on RH 600 To attach the pneumatic seeders PS120/200/300 on the RH 600 M1. Item no.: 07009-2-050 Figure 20 Page 25...
  • Page 26 • Dispersion plate assembly RH600 accessories kit For the attachment of the baffle plates of the PS120/200/300 on the RH 600 M1 Item no.: 07009-2-022 Figure 21 • Access platform for RH 600 M1 For easier filling of the PS implement, if equipped.
  • Page 27 • Operating hours counter A vibration sensor detects the vibrations of the implement and starts the operating hours counter. Item no.: 00602-3-659 Figure 24 • Tractor linkage upper bar sensor accessories kit MX Item no.: 00410-2-074 Figure 25 • Sensor set – Radar sensor + tractor linkage upper bar sensor Item no.: 00202-2-553 Figure 26...
  • Page 28: Safety Signs

    Safety signs Pay special attention to these stickers on the implement, as they warn you of specific dangers! Read and observe the Do not stand on the operating manual before implement while driving! operating the implement! Never reach into the Always switch off the crushing danger zone as engine and remove the key...
  • Page 29 Be careful with escaping Standing in the danger high-pressure liquids! zone (swivelling range) is Observe the instructions forbidden. in the operating manual! Loading hooks; when Danger due to thrown loading the machine, parts; observe the safety attach the ropes or chains distance! to these points! Lift the implement off the...
  • Page 30 Notes Page 30...
  • Page 31 Notes Page 31...
  • Page 32 APV – Technische Produkte GmbH HEADQUARTERS Dallein 15, 3753 Hötzelsdorf, Austria Telephone: +43 (0) 2913 / 8001 Email: office@apv.at Fax: +43 (0) 2913 / 8002 Web: www.apv.at Photo credits: Company photos © APV Page 32...
