- Page 1 Version: 2.2 EN / Item no.: 00601-3-374 Operating manual RH 600 M1 Please read carefully before initial operation! TRANSLATION OF THE ORIGINAL OPERATING MANUAL...
-
Page 2: Table Of Contents
Table of Contents EC Declaration of Conformity ..................... 3 Warranty..........................4 Service ..........................4 Location of the type plate ....................4 Safety instructions ......................5 Intended use ......................5 General safety-related instructions and accident prevention regulations ....5 Mounted implements ....................6 Towed implements ..................... -
Page 3: Ec Declaration Of Conformity
Product designation: Rotary hoe RH 600 M1 Number: RH 600 M1 Serial number: all serial numbers for the Rotary hoe RH 600 M1 Legal authorised person for the technical documents: APV-Technische Produkte GmbH, Headquarters, Dallein 15, AT-3753 Hötzelsdorf, Austria Conformity procedure:... -
Page 4: Warranty
For spare parts orders • To order maintenance and repair work • Service address: APV - Technische Produkte GmbH Telephone: +43 (0) 2913 8001 HEADQUARTERS Fax: +43 (0) 2913 8002 Dallein 15 Email: service@apv.at AT-3753 Hötzelsdorf Web: www.apv.at... -
Page 5: Safety Instructions
Safety instructions This chapter contains general rules of conduct for the intended use of the implement and safety- related information that should always be observed for your safety. The list is very extensive, and some of the information does not apply exclusively to the delivered implement. -
Page 6: Mounted Implements
Transport equipment - e.g. lighting, warning signs and any protective equipment, must be checked • and mounted! Triggers for fast couplers must be hanging loosely and must not trigger themselves when lowered. • Never leave the driver's platform while driving! •... -
Page 7: Towed Implements
For three-point mounting, the mounting categories of the tractor and the implement must match or be • adapted! There is a risk of injury due to crushing and shearing points in the area of the three-point linkage! • Do not stand between the tractor and the implement when actuating the external controls for the •... -
Page 8: Tyres
• For universal joint shafts, pay attention to the prescribed tube covers in transport and working position. • The universal joint shaft may only be mounted and dismounted when the PTO shaft and the motor are switched off and the ignition key is removed. •... -
Page 9: Safety Signs
Safety signs Pay special attention to these stickers on the implement, as they warn you of specific dangers! Read and observe the Do not stand on the operating manual before implement while driving! operating the implement! Never reach into the Always switch off the crushing danger zone as engine and remove the key... - Page 10 Be careful with escaping Standing in the danger high-pressure liquids! zone (swivelling range) is Observe the instructions forbidden. in the operating manual! Loading hooks; when Danger due to thrown loading the machine, parts; observe the safety attach the ropes or chains distance! to these points! Lift the implement off the...
-
Page 11: Technical Data
1 row of star rings Working width: Transport width: 2.85 m Dimensions (W x H x D in m): RH 600 M1: 2.85 x 2.75 x 1.55 (folded) Working speed: 2 – 25 km/h (depending on the crop) Working depth: 0 – 30 mm... -
Page 12: Road Transport
Road transport General The axle load and the total weight of the towing vehicle may not be exceeded. The mounted implement must be identified with warning signs or stickers with red and white slanted lines (according to DIN, ÖNORM or respective STANDARDS) according to the regulations of the specific country. Any part posing a traffic hazard or dangerous parts must be covered and additionally identified with warning signs or stickers. - Page 13 Weight calculations Calculation of the minimum front ballast for rear-mounted implements G V min This result is entered in the table below. Calculation of the minimum rear ballast for front-mounted implements G H min This result is also entered in the table. Calculation of the actual front axle load T v tat If the required minimum front ballast (GV min) is not reached with the front-mounted implement...
-
Page 14: Layout And Mode Of Operation
PLEASE NOTE! The minimum ballast must be attached to the tractor as a mounted implement or ballast weight! The calculated values may not be higher than the permissible values! Layout and mode of operation Figure 4: 1. Three-point linkage 2. Parking support 3. -
Page 15: Working Position And Setting The Working Depth And Pitch
Working position and setting the working depth and pitch The aggressiveness of the star rings is adjusted using the feeler wheels (Figure 5) as well as using the lifting unit and the top link. The downforce is hydraulically infinitely variably adjusted from the tractor by extending the hydraulic top link. -
Page 16: Quick Lifting Device (Installed As A Standard)
Figure 7: Pitch for both rings 30° 1 = Fastening lever 2 = Locking notch Figure 8: Pitch of 30° and 0° 3 = Ring holder Quick lifting device (installed as a standard) Using the quick lifting (available as an accessory), the implement can be adapted to the crop without using tools, only the folded-up arm must be fixed with... - Page 17 Figure 10: Pin in parking position Figure 11: Quick lifting device activated – lifted position Figure 13: Installed plates to prevent misapplication Figure 12: Limitation of the negative range The installed plate (see Figure 13) serves to prevent misapplication. As a result, the quick lifting device cannot be used for securing the work elements.
-
Page 18: Operation
Operation 10.1 Mounting on the tractor The implement must be mounted on the 3-point linkage of the tractor. The lifting links must be adjusted to the same height on the left and on the right. Mount the top link so that it slants down towards the tractor during operation. (Observe the specifications from the tractor manufacturer.) Adjust the side rods so that the implement can swing freely on the field, but is fixed when the implement is lifted. -
Page 19: Maintenance And Care
Pivot point of the folding mechanism Figure 15: These 2 + 2 arms must ALWAYS be in working position before they are folded up! Maintenance and care 11.1 Maintenance and care instructions To maintain the implement in good condition even after a long service life, observe the following instructions: All bolted connections should be re-tightened at the latest after 3 operating hours and again after 20 •... -
Page 20: Changing The Star Rings/Bearing
constructional properties of your implement. The manufacturer rules out any liability for damages resulting from the use of non-original parts and accessories. The manufacturer is not liable for any unauthorised modifications and the use of components and • auxiliary parts. 11.2 Changing the star rings/bearing Replace worn or broken star rings (Figure 16):... -
Page 21: Hydraulic Diagram
Hydraulic diagram Control unit Coupling sleeve BG2 Coupling connector BG 2 Throttle disc Stop tap Folding cylinder Figure 18 Page 21... -
Page 22: Lighting Circuit Diagram
Lighting circuit diagram 12 V plug, 7-pin Rear light, right Turn signal RIGHT Rear light Brake light Rear light, left Brake light Rear light Turn signal Plug and cable assignment: No. Desig. Colour Function Yellow Turn signal, left White Earth Green Turn signal, right Brown... -
Page 23: Combination Options With Ps
Combination options with PS Technical data: Combination options RH 600 M1 – PS Parts RH / PS PS120 E PS120 H PS200 E PS200 H PS300 E PS300 H PS500 E PS500 H PS800 required for mounting Dimensions LxWxH Dimensions... -
Page 24: Crop Cultivation Tips When Using The Rotary Hoe
Thanks to its successful use in cereals, maize, beets, squash, oil rape seed, vegetables, peas, soy, and field beans, the APV Rotary Hoe makes a significant contribution to soil cultivation. It covers everything from the crop rotations to fertilisation, and soil tillage to mechanical weed control. The objective of its concept will be to keep the weed population so small that the weeds cannot cause any qualitative or quantitative damage to your crops. -
Page 25: Applications
15.2 Applications 15.2.1 Winter cereals Uses in the fall: Use for soil aeration: Eliminating germinating weeds, breaking the soil crust Use for early seeding: Light use at the 2- to 3-leaf stage (very effective against silky bent grass) Uses in the spring: Use with light to medium setting as early as possible Objective: Strengthening of the stalks, stimulation of tillering, soil loosening and aeration Use at 30 –... -
Page 26: Accessories
PS120/200/300 on the RH 600 M1. Item no.: 07009-2-050 Figure 22 Dispersion plate installation RH600 • accessories kit For the attachment of the dispersion plates of the PS120/200/300 on the RH 600 M1. Item no.: 07009-2-022 Figure 23 Page 26... - Page 27 Access platform • For easier filling of the PS implement, if equipped. Item no.: 07000-2-019 Figure 24 Lighting with warning signs (on • both sides) Is required when the RH is transported on public roads. Item no.: 07009-2-073 Figure 25 Operating hours counter •...
- Page 28 Tractor linkage upper bar sensor • accessories kit MX Item no.: 00410-2-074 Figure 27 Sensor set – Wheel sensor + tractor • linkage sensor top link Item no.: 00202-2-553 Figure 28 Page 28...
-
Page 29: Index
Index Access platform ..........27 Peas .............. 25 Accessories ............ 26 Pitch ............... 15 Accident prevention regulations ......5 Preload force ..........15 Beets .............. 25 Production number ........... 4 Calculation of the weight ratios ....... 12 Quick lifting device ......... 16 Changing the bearing ........ - Page 30 Notes Page 30...
- Page 31 Notes Page 31...
- Page 32 +43 (0) 2913 / 8002 Web: www.apv.at Company details APV - Technische Produkte GmbH, Managing Director: Ing. Jürgen Schöls, Dallein 15, AT-3753 Hötzelsdorf, Austria, marketing@apv.at, www.apv.at, VAT ID no.: ATU 5067 1107 Photo credits: Company photos © APV Concept & text: Mag. Michaela Klein, Julia Zach, M.A., Ing. Peter Bauer, Claudia Redl Graphics: Jürgen Undeutsch, M.A.
