- Page 1 English Bucket Broom 2024 1 Operator's Manual for Attachment Bucket Broom Product number Bucket broom 1100 mm A35945 Bucket broom 1100 mm with water spraying system A36023 Bucket broom 1500 mm A35689 Bucket broom 1500 mm with water spraying system A36024 www.avanttecno.com...
- Page 2 Bucket Broom 2024 1...
-
Page 3: Table Of Contents
Bucket Broom 2024 1 CONTENTS 1. FOREWORD ............................4 Warning symbols used in this manual ........................... 5 2. DESIGNED PURPOSE OF USE......................6 3. SAFETY INSTRUCTIONS ........................7 Personal protective equipment ..........................9 Safe shutdown procedure ............................10 4. TECHNICAL SPECIFICATIONS ....................... 11 Safety labels and main components of the attachment .................. -
Page 4: Foreword
If you sell or transfer the equipment, be sure to hand over this manual to the new owner. If the manual is lost or damaged, you can request a new one from your Avant dealer or from the manufacturer. -
Page 5: Warning Symbols Used In This Manual
5 (36) Warning symbols used in this manual The following warning symbols are used throughout this manual. They indicate factors that must be taken into account to reduce the risk of personal injury or damage to property: WARNING SAFETY ALERT SYMBOL This symbol means: “Warning, be alert! Your safety is involved!”... -
Page 6: Designed Purpose Of Use
Using the broom is allowed only by using the controls of the loader while sitting on the driver’s seat of the loader. For cleaning large yard or road areas we recommend the Avant Collecting Broom. The Bucket broom is not designed for any other use than what is specified in this manual and it must not be used for any other purposes than what it is intended for. -
Page 7: Safety Instructions
7 (36) 3. Safety instructions Please bear in mind that safety is the result of several factors. The loader-attachment combination is highly powerful and improper or careless use or maintenance may cause serious personal injury or property damage. Due to this, all operators must carefully familiarise themselves about correct use and the operator's manuals of both the loader and the attachment before starting operation. - Page 8 8 (36) Pay attention to the surroundings and any other persons and machines moving in the vicinity. Pay attention to the contours of the terrain and other hazards, such as branches and trees that can reach to the driver's area, loose rocks, and slippery surfaces.
-
Page 9: Personal Protective Equipment
9 (36) Entanglement and severing hazard - Never go near a running attachment. The powerful rotating shaft can cause serious injuries to anyone too close to it. Always stop the attachment following the safe stopping procedure before going near the attachment. If WARNING being near a running attachment is absolutely necessary to determine the condition of the attachment watching from a distance, or fault finding operation, never wear loose... -
Page 10: Safe Shutdown Procedure
10 (36) 3.2 Safe shutdown procedure Safe stopping of the attachment, before going near the attachment: Always stop the attachment following safe stopping procedure before leaving the driver's seat. Safe stopping procedure prevents all unintentional movements of the attachment. Note that the loader boom can move down even if the engine of the loader is turned off. -
Page 11: Technical Specifications
Recommended input of hydraulic 20-35 l/min 25-40 l/min energy: 50 l/min, 70 l/min, Maximum input of hydraulic energy: 22,5 MPa (225 bar) 22,5 MPa (225 bar) Suitable AVANT loader: See Table 1 Options Water spraying system: A35956 A35807 Rubber blade brush: A436108 A433868... -
Page 12: Safety Labels And Main Components Of The Attachment
A46806 A452800 A452802 Attachment identification plate (A35945 only) (A35689 only) A418386 / A418387 To apply a new label: Clean the surface thoroughly to remove all grease. Allow it to dry completely. Peel off the protective film of the label and press firmly to apply. Take care not to touch the glue of the label. - Page 13 Beware also of entanglement of clothes, jewellery or long hair. A418386 / Attachment identification plate A418387 Table 4 - Bucket Broom - Main components Avant quick coupling plate, floating Bucket frame with collector box Bristle discs Broom protective cover Broom height adjustment Broom lifting cylinders...
-
Page 14: Lifting
14 (36) 4.2 Lifting Make sure that the attachment is properly secured against unintended movements during lifting operation. Use appropriate type of lifting accessories, lifting straps, chains or hooks, for example. Do not use lifting accessories if there are signs of damage, deformation, or otherwise unsafe conditions. -
Page 15: Assembling The Attachment
Do not stay in the area between the attachment and the loader. Mount the attachment only on level surface. WARNING Never move or lift an attachment that has not been locked. Avant quick coupling system: Step 1: Lift the locking pins of the quick coupling plate of the loader up, and turn them backwards into the slot, so that they are locked in the upper position. -
Page 16: Connecting And Disconnecting Hydraulic Hoses
5.1 Connecting and disconnecting hydraulic hoses On Avant loaders the hydraulic hoses are connected using the multi connector system. If you have an older model Avant 300-700 series loader with the conventional quick couplers, and you want to change to the multi connector system, contact your Avant dealer or service point for instructions or installation services. - Page 17 17 (36) Keep all fittings as clean as possible; use the protective caps on both the attachment and the loader. Dirt, ice, etc. may make using the fittings significantly more difficult. Never leave the hoses hanging on the ground; place the couplings onto the holder on the attachment.
-
Page 18: Electric Connection
18 (36) 5.2 Electric connection Electric plug must be connected only when the attachment is equipped with the water spraying system. If water spraying system is not not installed, you can skip this part of the manual. Electric functions of the attachment: The electric water pump of the Water spraying system can be controlled with the standard electric harness that is supplied with the attachment, Opticontrol , or the Attachment control switch pack of the loader. - Page 19 19 (36) If your loader is equipped with the Opticontrol ®, the Attachment control switch pack, and the loader is manufactured after 2016: electric socket integrated multiconnector, electric harness attachment is connected when the multiconnector is coupled. Clean both multiconnectors before connecting the multiconnector.
-
Page 20: Using The Broom
20 (36) 6. Using the broom Check the attachment and the operating environment once more before starting to work, and that all obstacles have been removed from the operating area. Quick inspection of the equipment and the operating area before use are parts of ensuring safety and the best performance of the equipment. -
Page 21: Safety Distance
21 (36) 6.1 Safety distance The minimum safety distance from the attachment is 2 metres. Stop the attachment immediately if bystanders get within the safety distance. Do not let bystanders get any closer than 2 metres from the attachment. Rotating broom can throw material at very high speed, creating serious risk of injury to bystanders. -
Page 22: Checks Before Use
22 (36) 6.2 Checks before use Before starting work, remove large items that can’t be collected with the broom from the working area. Drive carefully on uneven terrain and note the effect of heavy load at the front of the loader to the ... -
Page 23: Operating The Broom
23 (36) 6.4 Operating the broom The bucket broom is operated with the auxiliary hydraulics of the loader, using either the auxiliary hydraulics control lever of the loader or the electric buttons of the joystick (optional equipment for loaders). Move the auxiliary hydraulics control lever of the loader towards its locking position (or use the electric buttons of the joystick) to lower the broom down and start rotating it. -
Page 24: Broom Position Support Pins
24 (36) Broom floating system and correct operating position: During operation the broom should be kept in similar position as shown in the adjacent figure. The broom and the edge plate of the bucket should be in light contact with the ground, or the edge just slightly off the ground. -
Page 25: Emptying The Collector Bucket
25 (36) 6.4.2 Emptying the collector bucket To empty the bucket, the broom is lifted hydraulically from the front of the bucket by turning the auxiliary hydraulics control lever opposite direction from the locking position. Empty the broom as a normal bucket, but keep in mind the movement made possible by the floating attachment bracket when tilting the bucket... -
Page 26: Installing The Water Spraying System
26 (36) 6.5.1 Installing the water spraying system The installation points for the watering system are on the broom as standard and the watering system can be installed later. The installation includes necessary components and the electric harness to operate the watering system. The numbering shown in figures correspond with the numbering of the instructions. -
Page 27: Using The Water Spraying System
27 (36) 6.5.2 Using the water spraying system To operate the water spraying system (if fitted), the electric harness for the water pump must be connected to the loader. The pump of the water spraying is operated with the electric switch, Opticontrol , or the Attachment ®... -
Page 28: Transport Position
28 (36) 6.6 Transport position When driving with the loader, keep the attachment in the position shown in adjacent figure. Risk of tipping over - Keep the loader stable. Always transport the attachment as low and close to the ground as possible. Keep the telescopic boom retracted during transport drive. - Page 29 29 (36) To prevent freezing of the watering system, ensure that during cold seasons all water is drained from the system. The pump of the watering system will get damaged if water gets frozen inside it. Disconnect the water hoses to drain the system completely.
-
Page 30: Maintenance And Service
Finding any fault means that the hydraulic hose or component must be replaced and the equipment must not be used until it is repaired. Spare parts are available from your nearest AVANT retailer or authorised service point. Leave the repair work to professional service technicians, if you don’t have adequate knowledge and... -
Page 31: Cleaning And Lubrication
31 (36) 7.2 Cleaning and lubrication Clean the broom as soon as possible after use, so that it is easier to remove all dirt. A pressure washer and mild detergent can be used. Avoid using solvents or spraying directly at the bristles or hydraulic parts at high pressure. -
Page 32: Bucket Edge Plate
32 (36) 7.4 Bucket edge plate The edge plate of the bucket can be replaced as needed. The spare part code for Bucket broom 1100 is A416775 and for 1500 A416406. Replace also the fasteners of the plate. Replace the plate before the frame of the bucket gets in contact with the ground. -
Page 33: Warranty Terms
33 (36) 8. Warranty terms Avant Tecno Oy grants a warranty of one year (12 months) from the date of purchase for the attachment it manufactures. The warranty covers repair costs as follows: Work costs are covered, if the repair is not performed at the factory. - Page 34 2006/42/EC as amended). The following harmonized standards have been applied: SFS-EN ISO 12100, SFS-EN ISO 4413 Mallit / Modeller / Models Avant Hydraulitoiminen harjalaite; Avant-kuormaajan työlaite Hydraulisk sopvals; arbetsredskap för Avant lastare 1100 A35945 Hydraulic broom; attachment for Avant loaders 1500 A35689 6.5.2024 Ylöjärvi, Finland...
