Narrative Standing Desk
V2 C-Frame
UPL980
Attention: For Narrative Standing Desk assembly, discard
the instruction manual included with the UPLIFT V2 Standing
Desk Frame and use this instruction manual instead.
For assembly assistance, visit upliftdesk.com/contact, call 800-349-3839, or email support@upliftdesk.com
©2023 UPLIFT Desk®. All Rights Reserved. Patented
Work Better. Live Healthier
Two person
Scan QR code for
assembly
product webpage

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UPL980 and is the answer not in the manual?

Questions and answers

Summary of Contents for Uplift Desk UPL980

  • Page 1 UPLIFT V2 Standing Desk Frame and use this instruction manual instead. Two person Scan QR code for assembly product webpage For assembly assistance, visit upliftdesk.com/contact, call 800-349-3839, or email support@upliftdesk.com ©2023 UPLIFT Desk®. All Rights Reserved. Patented...
  • Page 2 WARNING: Never use the desk if the power cord or plug becomes damaged as this can cause a risk of fire and electric shock. Contact UPLIFT Desk for a replacement power cord if it is damaged in any way. WARNING: Risk of serious injury or death.
  • Page 3 Desk image is for reference only and may not match your desk style. > 1” vertical gap Max height > 1” horizontal gap Min height Do not place feet on items below the desk where they can be injured. © UPLIFT Desk • 800-349-3839 • info@upliftdesk.com • upliftdesk.com...
  • Page 4: Package Contents

    Package Contents Package Contents F500 Frame Box Components Crossbar End Crossbar Rail Control Box Keypad qty 2 qty 2 qty 2 Type varies Power Cable Anchor Plate Wire Extension Cable qty 2 Management Tray F500 C-Frame Feet & Side Brackets Box Components Foot Side Bracket Logo Plate...
  • Page 5 Parts Diagram Side Bracket Crossbar End Crossbar Rail M8 x 8 Set Screw M6 x 10 Screw M6 x 14 Screw Logo Plate Foot © UPLIFT Desk • 800-349-3839 • info@upliftdesk.com • upliftdesk.com...
  • Page 6: Step 1 - Inventory Of Parts

    Assembly Instructions Step 1 - Inventory of Parts A. To avoid damage to your floor or desktop, assemble the desk on a clean carpet or blanket. B. Lay out all parts from each box and ensure you have everything listed in the package contents of this manual before throwing away any packaging.
  • Page 7: Step 5 - Attach Feet

    Tighten screws very thoroughly. IMPORTANT: Retighten each screw again to ensure that all screws are VERY tight before proceeding. Tightening these screws has a noticeable impact on desk stability. Assemblies created in this step. © UPLIFT Desk • 800-349-3839 • info@upliftdesk.com • upliftdesk.com...
  • Page 8: Step 8 - Frame Attachment

    Step 6 - Insert Crossbar Rails A. Position the Leg assembly shown with Side Bracket on the left and the long end pointing in the direction shown. B. Insert a Crossbar Rail (P6) into each of the two openings at the end of the Crossbar End (P5). C.
  • Page 9 4mm Allen Wrench (H6). IMPORTANT: Ensure that all eight set screws are making contact with the Crossbar Rails inside the Crossbar Ends and are tight before proceeding. © UPLIFT Desk • 800-349-3839 • info@upliftdesk.com • upliftdesk.com...
  • Page 10 Step 10 - Attach Keypad There are two sets of Keypad mounting holes pre-drilled into the left and right side on the bottom of the Narrative desktop, shown circled. Choose the side of the desktop where you would like the Keypad located.
  • Page 11: Step 12 - Connect Cables

    C. If your Casters have a hex nut between the threaded stem and wheels, you can use a 1⁄2” (12mm) or adjustable wrench (not included) to assist with the Caster installation process. © UPLIFT Desk • 800-349-3839 • info@upliftdesk.com • upliftdesk.com...
  • Page 12 Attach Cable Mounts Ten Cable Mounts (H9) are provided with your desk to attach under the desktop and organize cables. Organizing cables improves the appearance of your desk and prevents cables from snagging on anything while the desk is moving up and down.
  • Page 13 B. Carefully lift while rotating the desk toward the back so the Keypad is facing up as shown. C. Readjust your grip and continue to rotate the desk until it is rightside up. © UPLIFT Desk • 800-349-3839 • info@upliftdesk.com • upliftdesk.com...
  • Page 14 Position Desk Position the desk where you would like it to be located. Don’t drag the desk or lift the desk by just the desktop; doing so may put undue stress on the attachment screws and threaded inserts. A. If your desk has Casters, moving is easy. If the Casters include locks, unlock them to roll the desk to the desired location.
  • Page 15: Keypad Lock

    If you have an Advanced Keypad, see the Programming section below for further information on how to use your Keypad. Programming (Advanced Keypads only) These UPLIFT Desk programming instructions are compatible with all UPLIFT Advanced Keypads except the Advanced Paddle Keypad.
  • Page 16: Units Of Measurement

    Units of Measurement One-Touch, Constant-Touch, or Double-Tap Switch between inches and centimeters on your display: One-touch is the default setting of the control box and 1. Hold the down button until the desk reaches its lowest requires only a single touch of a keypad button to move position.
  • Page 17: Starting And Stopping

    If the error message persists after performing the reset procedure or if there is a height difference between the Legs of more than 1.5”, email us at support@upliftdesk.com or call 800-349-3839. Perform the desk reset procedure any time the desk is unplugged or loses power. © UPLIFT Desk • 800-349-3839 • info@upliftdesk.com • upliftdesk.com...
  • Page 18 Notes...
  • Page 19 Notes © UPLIFT Desk • 800-349-3839 • info@upliftdesk.com • upliftdesk.com...
  • Page 20 Study this manual carefully. If this product is sold, please provide this manual to the buyer, installers, or support personnel operating the product. Copyright Notice: This manual is a component of this UPLIFT Desk product. This manual is a ©...
