UPLIFT 4-Leg Height Adjustable Standing Desk
DIRECTIONS FOR ASSEMBLY AND USE
Any user or installer of desk base must study this manual carefully. If this desk is sold,
please provide the manual to the buyer, installers, or support personnel operating the product.
© UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com
90.014.01.0146v.D
TABLE OF CONTENTS
1
Safety and Warnings
2
Usage
3
Parts List
4
Assembly Instructions
5
Desk Placement
6
Programming
7
Troubleshooting
8
Technical Specifications
SAVE THESE INSTRUCTIONS:
PAGE
2
2
3
4
7
7
8
9
®
UPL940/R01
Advertisement
Table of Contents
Related Manuals for Uplift Desk UPL940
Summary of Contents for Uplift Desk UPL940
- Page 1 Technical Specifications SAVE THESE INSTRUCTIONS: Any user or installer of desk base must study this manual carefully. If this desk is sold, please provide the manual to the buyer, installers, or support personnel operating the product. © UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com 90.014.01.0146v.D UPL940/R01...
-
Page 2: Safety And Warnings
These desks are designed only for the purposes included in this manual. They should not be used in environments with high humidity or dampness. Any other use is at user’s risk. Do not move around, crawl, or lie under the desk frame. Do not sit or stand on the desk frame. Children should never use the desk unless they are supervised by adults. Liability: Under no circumstances does the manufacturer accept warranty claims or liability claims for dam- ages caused from improper use or handling of the desk frame other than that which is described in this operation manual. © UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com... -
Page 3: Parts List
For ease and safety, we recommend two people for assembly. Part # Description Small Foot Zero Crossbar Bracket Adhesive Pads Control Box Keypad Leveling Studs Cables (power & connector cables) M6x14 Screw M5x16 Wood Screw Cable Clips © UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com... -
Page 4: Assembly Instructions
Place five (5) self-adhesive Adhesive Pads (part 4) on each of the four (4) Zero Crossbar Brackets (part 3) as shown. Place each Zero Crossbar Bracket (part 3) on the underside of the desktop. Carefully measure from all sides and attach the Zero Crossbar Brackets (part 3) to the underside of the desktop with twenty-four (24) Pan Head Screws (part 10), six (6) per bracket. Double-check that the wood screws are not too long for the desktop and won’t puncture the surface when screwed all the way in. If your desktop is not pre-drilled, we recommend that you pre-drill the holes for connecting the Brackets (part 3) to the desktop. Drill 1/2’’ deep (max) with a 1/8’’ drill bit. Never use countersunk screws. © UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com... -
Page 5: Do This So You Can Place The Keypad
Using the supplied allen wrench, insert four (4) Machine Screws (part 9) through the holes in each Zero Crossbar Bracket (part 3) going into the Leg (part 1) and rotate each screw just a few turns. When all machine screws are threaded, go back and tighten all four (4). Attach the four (4) Small Feet (part 2) to the four (4) Legs (part 1), each with four (4) Machine Screws (part 9). Using the cables, connect the Legs (part 1) to the Control box (part 5) and the Keypad (part 6) as per the diagram below. Do this so you can place the Keypad and Control Box in such a way so that the cables can reach them. © UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com... - Page 6 You must RESET the desk prior to use! Press and hold the DOWN button on the Keypad until the desk reaches its lowest height. Release the DOWN button. Press and hold the DOWN button again until the LED display reads “RST” or about 10 seconds on non-LED handset models. Release the DOWN button. Press and hold the DOWN button again until the desk lowers a little bit more, slightly rises and stops. Release the DOWN button. Your desk is now ready to use. To program up to four presets: Use the up/down buttons to find a desired height, then press “M” followed by a number 1 – 4. © UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com...
-
Page 7: Desk Placement
6. PROGRAMMING: SETTING THE LED RETRACTED HEIGHT If you’ve purchased an UPLIFT Desk and the Advanced 1-touch digital keypad, press the DOWN button on the Keypad until the frame reaches its lowest position. Measure the height of the frame from the floor to the underside of the desktop and if the number on the LED display does NOT match your measure- ment, follow these steps: Press and hold the DOWN button again until the LED display reads “RST”... -
Page 8: Troubleshooting
Release the DOWN button. Press and hold the DOWN button again until the desk lowers a little bit more, slightly rises and stops. Release the DOWN button. Your desk is now ready to use. • The Keypad will then display the current height, and you should be able to operate it now. • You may need to do this if the desktop is ever unplugged or loses power. If the Leypad displays error messages “Er1” through “Er13”, confirm that all wired connections are secure (legs to cables, cables to control box). Then perform the reset procedure above. If the error message per- sists after the reset procedure or if the height between the legs exceeds 1.5’’ stop the reset procedure and contact The Human Solution (800.531.3746 or info@thehumansolution.com). If the Keypad displays “Hot”, let the base cool down for 20 minutes. If the desk seems to be uneven, try the reset instructions above. If that does not work you may need to adjust the levelers at the bottom of the foot. © UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com... -
Page 9: Technical Specifications
There is a danger of electric shock Keep all electrical components away from liquids Copyright Notice: This guide is a component of the UPLIFT Desk™. This guide is a part of the scope of delivery, even if the item is resold. This guide is also available on the UPLIFT Desk website: upliftdesk.com. Excerpts or copies may not be forwarded to third parties or used in any other published form without ©...
