Uplift Desk UPL127 Quick Start Manual

Package contents

Track
Front bumper
Back bumper
© UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com
5/8''
Wood screws
(qty 8)
Machine screws
(qty 4)
Mechanism
Acorn nuts
(qty 4)

Step 1

Take the Track and place underneath your desktop, in order to figure out
where to place it. If there are pre-drilled holes in your desktop, line the
track up with the holes, or you can pre-drill your own 1/8" pilot holes. Be
sure to leave about 1/2" from the front edge of the desk.
Use eight (8) Wood screws to attach the track to the desktop, and one more
screw to attach the rear bumper as shown.

Step 2

With the desk right side up, line up the mechanism with the grooves on the
track and slide it in.
Please note: the mechanism will not adjust up or down until the tray has
been attached and the shipping pin is removed (see steps 3 and 4).

Step 3

Attach the tray to the mechanism by lining up the holes in the tray with
the holes on the mechanism, and secure by inserting the four (4) Machine
screws through the holes, and screwing the four (4) Acorn nuts onto them
from below.

Step 4

Lift up on the front of the tray and lower the back to relieve pressure on
the shipping pin and remove it.
®
Large Keyboard Tray
UPL127
Keyboard tray
Palm support
Mousepad
Cord catcher
Adhesive pads
(optional. qty 4)
UPL127/R02
