Rolling Elevated garden Planter with Under Shelf

Installation Guide

Thank You!

You're only a few steps away from your perfect vegetable

garden or elevated planter. We hope you enjoy!

Before You Start

Please read the instructions carefully to familiarize

yourself with every detail and step involved. Keep this

manual for future reference. Find a suitable space to

assemble your new Elevated Garden Bed.

You need at least 37" x 19" (94 x 49 cm) for the finished

product. A flat and firm area (like a garage floor or flat

yard space) is perfect! The only tools you may need are

a rubber mallet and a scissor.

Important Notes

Small parts are included; we advise you to keep

them away from children and pets.

We also suggest having another person help you

assemble. Maximum Load capacity: approximately

2.2 cu. ft. of soil

Subscribe at www.everbloom-garden.com

for extra savings and upgrading information!

Everbloom-Garden.com

Questions or Comments?

Email us at service@everbloom-garden.com

Model# E333618WU

Dimensions 36" L x 18" W x 36" H

Need help?

Do you have a question about the E333618WU and is the answer not in the manual?

Questions and answers

Summary of Contents for Everbloom E333618WU

Page 1 We also suggest having another person help you assemble. Maximum Load capacity: approximately 2.2 cu. ft. of soil Subscribe at www.everbloom-garden.com for extra savings and upgrading information! Everbloom-Garden.com Questions or Comments? Email us at service@everbloom-garden.com Copyright © 2023 Dynaforge Trading LLC.
Page 2: Parts List
Parts List 1 Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H Left Corner Right Corner Long Support Steel Wire Short Panel Post Post Board Board 380mm Bottom Bottom 35.4 x 15in 900mm (900 x 380mm)
Page 3 Parts List 2 Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H Bottom Tray Black Post Cap with End Caps Tape + 2pc replacement Connector Caster Wheel Bolt Nut Driver Hex Key Washer...
Page 4 Assembly Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H Start by making sure each corner post is oriented correctly, as shown in Image 1. Slide one short board into the corner brackets from above. Note: The short boards need to be placed in the inward “U”...
Page 5 Assembly Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H Slide another short board into the other two corner brackets from above, as shown in Image 2. IMAGE 2 Right Corner Post Left Corner Post Short...
Page 6 Assembly Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H With the help of another person holding the 2 assembled parts, slide the 2 long supporting boards into the brackets from above. Make sure that one support board goes straight to the bottom, while the other one stays in the middle of the way (don’t push to the bottom), with the bottom edge between the 2nd and 3rd holes of the post, as shown in Image 3.
Page 7 Assembly Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H Put the bottom trays on lower slots of long support boards. Make sure the 2 ends of these bottom trays go into the lower slots and rest in them with enough contact as shown in Image 8. Adjust the height of the higher long support board slightly to hold these bottom trays if necessary.
Page 8 Assembly Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H Push down the higher long support board to the bottom, as shown in Image 9. IMAGE 9 IMAGE 9 Long Support Board...
Page 9 Assembly Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H Carefully flip over the planter so that it lays flat with the short boards pointing towards the sky, as shown in Image 10. IMAGE 10 IMAGE 9...
Page 10 Assembly Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H Open all the steel connector washers, as shown in Image 11. Then, clamp the connector washers onto the steel wire panel, as shown in Image 12. Note: Pay attention to the position and direction of the connector washer on the panel.
Page 11 Assembly Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H Align the steel wire panel to four post brackets and fasten a connector washer on the steel wire panel to post bracket with bolts and nuts, as shown in Image 14. Note: Pay attention to the direction of the connector washer on the panel.
Page 12 Assembly Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H fasten the other three connector washers on the steel wire panel to post brackets with bolts and nuts, as shown in Image 15. IMAGE 15 IMAGE 9...
Page 13 Assembly Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H Insert caster wheels into corner brackets, as shown in Image 16 and Image 17. IMAGE 16 IMAGE 17...
Page 14 Assembly Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H Fix the wheels with bollts and nuts, as shown in Image 18. IMAGE 18...
Page 15 Assembly Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H Fasten bolts and nuts with nut driver and hex key which are included in pack , as shown in Image 19. IMAGE 19 Hex key...
Page 16 Assembly Self-Watering Mobile Elevated Garden - 36" L x 18" W x 36" H Flip over the planter again so it stands upright, as shown in Image 20. IMAGE 20...
Page 17 Assembly Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H Seal the small gaps between reservoirs and the gaps between reservoir and short boards with black tape, as shown in Image 21. IMAGE 21...
Page 18 Assembly Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H Bottom trays come with 18 drainage holes each with end caps, enabling adjustable drainage settings. Take off some end caps in advance according to different climates and watering needs as you wish, as shown in Image 22.
Page 19 Assembly Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H Cover the holes with liners, as shown in Image 23. IMAGE 23 Liner x3...
Page 20 Assembly Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H If necessary, use your rubber mallet to ensure the boards are tightly in place. Cover the brackets with the 4 end caps, as shown in Image 24. IMAGE 24 Rubber Mallet...
Page 21 Assembly Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H Now you get an EverBloom Rolling Elevated Garden Planter with Under Shelf, as shown in Image 25. Then, enjoy your gardening time! IMAGE 25...
Page 22 Note Rolling Elevated Garden Planter with Under Shelf - 36" L x 18" W x 36" H Sometimes there might be a misalignment of the Corner Posts as shown in Image 26 and Image 27, which may result in difficulty of sliding boards into the brackets. Please adjust them to the right position so that they are parallel to each other, and perpendicular to the ground.
Page 23 Bloom On. Everbloom-Garden.com US Patent Pending Subscribe at www.everbloom-garden.com for extra savings and upgrading information! Distributed by: Dynaforge Trading LLC St. Paul, MN55101 Email: service@everbloom-garden.com...
